User Manual
HDR HDMI Audio Extractor
Model No：AA6087

Advertisement

loading
Need help?

Need help?

Do you have a question about the AA6087 and is the answer not in the manual?

Questions and answers

Related Manuals for Aus Electronics Direct AA6087

Summary of Contents for Aus Electronics Direct AA6087

  • Page 1 User Manual HDR HDMI Audio Extractor Model No：AA6087...
  • Page 2 INTRODUCITON Picture 1.0 front panel showing Picture 1.1 rear panel showing...

  • Page 3: Device Install

    Connection and operation: Device install To use HDMI cable to connect the HD source with the HDMI input port of device. To use HDMI cable to connect the HDMI output port of device with the display. To use optical cable to connect the Toslink output port of the device with the AV Receiver.
  • Page 4 ARC button again, the ARC function is closed and the ARC led light will go dark,and the Toslink port and L/R output port output the Extracted Audio from the HDMI Input. Spec: Model No AA6087 Model name HDR HDMI Audio Extractor Input channel HDMI port Output channel HDMI port、Toslink port、L/R port...
  • Page 5 2160P/AWG 26 ≤5m HDMI Input cable length 1080P/AWG 26 ≤10m 2160P/AWG 26 ≤5m HDMI Output cable length 1080P/AWG 26 ≤10m Power adapter specification Input: AC 100~240V Output: DC 5V/1A Max working current 700mA Working temperature range 0 ~ +40℃ Working humidity range 5 to 85%RH（No Condensation）...
