- Page 1 DuTCH audio IM1.2(s) Insert Matrix manual...
- Page 2 (middle) and to the outputs (right side), basically how the device handles signals. The IM1.2 is available in 2 versions, the IM1.2 and the IM1.2s. The only difference is the output section. More on this, check the output section in this manual.
- Page 3 The IM1.2(s) has balanced inputs. Both inputs consist of gold-plated Neutrik XLR’s. Inserts: The IM1.2(s) has 6 balanced inserts connected on the back with industry standard Tascam DB25 analog connectors. Each connector holds 2 inserts corresponding with the frontpanel numbering.
- Page 4 Outputs: On the rearpanel you will find the output with balanced gold-plated Neutrik XLR’s. Power: The ‘power’ input is for connecting the external power-supply to the IM1.2. Technical: Hardware: This device is built around mostly passive circuits, but some sections need to be active, but always with transparency in mind.
- Page 5 (Power consumption depends on the amount of inserts, input, output etc activated) Unit size: standard 1u 19 inch, depth 25cm Weight: approx 2kg Specifications subject to change because always improving © DuTCH.audio 2019 Handmade in Holland on Solarpower info@dutch.audio https://dutch.audio...
