Summary of Contents for BBK FSW-108

  • Page 1 FSW-108 SERVICE MANUAL...
  • Page 2: Table Of Contents

    CONTENT CHAPTER 1(ACOUSTIC) SPECIFICATIONS-------------------------------------------------------------------3 PRECAUTIONS----------------------------------------------------------------------3 GENERAL CHART-------------------------------------------------------------------4 BILL OF MATERIAL-----------------------------------------------------------------4 CHAPTER 2(ELECTRONIC) SPECIFICATION---------------------------------------------------------------------6 DISASSEMBLY INSTRUCTION---------------------------------------------------7 CIRCUITRY PRINCIPLE CHART--------------------------------------------------9 PROCESS CHART-------------------------------------------------------------------10 PCB BOARD-------------------------------------------------------------------------11 GENERAL ASSEMBLY ILLUSTRATION----------------------------------------12 BILL OF MATERIAL---------------------------------------------------------------13 Page 1...
  • Page 3 Chapter 1 (Acoustic) Page 2...
  • Page 4: Specifications

    SPECIFICATIONS Model Number FSW-108 Cabinet Type Subwoofer Component 100 woofer Speaker System Bass Reflex Speaker Terminals Spring Clip Dimensions 305x395x470 (WxDxH)mm Weight(net) 15.5 kg/pc PRECAUTIONS There are wires connected speaker with amplifier panel, when disassembling speaker, remember to unplug the connecting terminals.
  • Page 5: General Chart

    GENERAL CHART Bill of Material Page 4...
  • Page 6 Chapter 2 (Electronic) Page 5...
  • Page 7: Specification

    Amplifier main set Output Distortion factor...
  • Page 8: Disassembly Instruction

    DISASSEMBLY INSTRUCTION Please study the circuitry position well before any disassembly to ensure all wires locate as original. Rear panel - Take away the 11 pcs screw A (fig.1); - Move off the rear panel; - Pull down the speaker terminal; - Move off the rear panel.
  • Page 9 Fig.2 Amplifier board - Take away the 9 pcs screw B (fig.2); - Pull down the speaker terminal C; - Move off the amplifier board. Front panel - Take away the 1 pc screw D (fig.2); - Take away the 7 pcs screw F (fig.1); - Pull out the knob and disassembly the 2 nuts G under it (fig.1);...
  • Page 10: Circuitry Principle Chart

    CIRCUITRY PRINCIPLE CHART Page 9...
  • Page 11: Process Chart

    PROCESS CHART SIGNAL INPUT Page 10...
  • Page 12: Pcb Board

    GENERAL ASSEMBLY ILLUSTRATION øÃ∂» 1.000 Page 12...
  • Page 14: Bill Of Material

    PCB BOARD Page 11...
