Summary of Contents for momoDESIGN MD-E26MTBF CAPRI26FAT

  • Page 2 CAPRI 26FAT MD-E26MTBF-W 26” ELECTRIC FAT BIKE USER MANUAL - ORIGINAL INSTRUCTIONS PAGE 3 PAGE 25...
  • Page 3 CAPRI 26FAT MD-E26MTBF BICICLETTA MTB ELETTRICA MANUALE D’USO Leggere attentamente il manuale di istruzioni prima dell’uso. Conservare per utilizzi futuri. Riporre il manuale in un luogo sicuro e trasferirlo ad eventuali nuovi proprietari. ATTENZIONE L’utilizzatore è responsabile di tutte le conseguenze causate da un utilizzo improprio del prodotto. Chi non rispetta il manuale di istruzioni rischia di non controllare il prodotto e rischia di cadere con conseguenze anche gravi.
  • Page 4 PARAMETRI TECNICI ED INDICATORI DI PRESTAZIONE Parametri principali: Autonomia per ricarica: ≤ 50km Carico minimo: 30kg Carico massimo: 100kg Pneumatico: 26 pollici × 4.0inch Velocità massima: ≤ 25km/h Consumo energetico: < 1.2kwh/100km Distanza tra ruota anteriore e ruota posteriore: 108 cm circa Specifiche tecniche principali della batteria: Tipo: Batteria al litio Capacità: 8,8Ah...
  • Page 5 PREPARAZIONE ALLA GUIDA Leggere attentamente il manuale in tutte le sue parti. Prima di guidare la bicicletta bisogna assicurarsi che il livello della batteria sia carico. Attenersi al manuale per non incorrere in problemi tecnici. Controllare lo stato dei pneumatici. Utilizzare il prodotto solo se in buone condizioni.
  • Page 6: Caratteristiche Tecniche Del Prodotto

    CARATTERISTICHE GENERALI DEL PRODOTTO Le nostre biciclette elettriche sono sicure, di bell’aspetto, ecologiche, alla moda e popolari, speciali per lo sport, il tempo libero e gradite a chi rispetta l’ambiente. I modelli di questa serie sono leggeri e comodi per rilassarsi e muoversi. Ecologica: Non usa carburante, non emette scarichi, il motore è...
  • Page 7 QUADRANTE LCD Tasto su Tasto on/off Tasto giù Livello pedalata assistita (PAS) Livello batteria Funzione CRUISE (non disponibile in questo modello) Funzione PAS Durata singola tratta (TM) / Durata totale (TTM) Indicazione THROTTLE (non disponibile in questo modello) Funzione spingibici (6km/h) Velocità...
  • Page 8 Visualizzazione display all’accensione: Dalla visualizzazione numero 1, premendo leggermente il tasto on/off si passerà alla seconda visualizzazione del display (dopo 5 secondi in modalità pedalata, il display tornerà automaticamente alla schermata principale numero 1).
  • Page 9 Dalla visualizzazione numero 2, premendo leggermente il tasto on/off si passerà alla terza visualizzazione del display (dopo 5 secondi in modalità pedalata, il display tornerà automaticamente alla schermata principale numero 1). ● Livello pedalata assistita Durante la guida, premere leggermente i tasti su e giù per cambiare il livello di assistenza del motore (da 1 a 5). Il rapporto 1 è la potenza minima, mentre il rapporto 5 è...
  • Page 10 malfunzionamento sensori di velocità; 06: malfunzionamento motore o centralina. I codici di errore appaiono sul display lampeggiando. Una volta che il problema è risolto, il display tornerà alla schermata principale. Nota: A causa delle continue migliorie apportate ai nostri prodotti, il contenuto delle istruzioni potrebbe differire dal prodotto stesso.
  • Page 11 SENSORE DI VELOCITA’ Diagramma installazione sensore (asse centrale e guarnitura meccanica nel mezzo). Sensore di velocità (coppia) Sensore stent Disco segnale sensore...
  • Page 12 REGOLAZIONE PEDALI “L” è il pedale sinistro, “R” è il pedale destro; avvitare e serrare entrambi saldamente nella posizione corretta. REGOLAZIONE DEL SELLINO Fare attenzione alla distanza tra la seduta ed il pedale nella posizione più bassa. L’altezza del sellino è corretta quando il ginocchio è leggermente piegato nel momento in cui il piede si trova nel punto più...
  • Page 13: Pressione Pneumatici

    REGOLAZIONE FRENO Durante la regolazione del freno, assicurarsi di mantenere una distanza uniforme tra pastiglia e disco. Durante la regolazione del freno, assicurarsi che le pastiglie tocchino in maniera decisa il rotore del disco quando la leva del freno viene tirata. Assicurarsi che la leva del freno tirata abbia una distanza minima di 20mm dalla manopola del manubrio.
  • Page 14 REGOLAZIONE DEL DERAGLIATORE POSTERIORE 1. La vite A regola la tensione della molla del bilanciere. 2. La vite B regola finemente la tensione del filo del cambio. 3. La vite C blocca il filo nella sua sede. 4. La vite H è il registro che regola il finecorsa inferiore. Permette di allineare le pulegge del deragliatore al pignone più piccolo, evitando che la catena fuoriesca sul telaio.
  • Page 15 Il cambio Shimano di questa bicicletta ha 8 velocità. POTENZA PEDALATA La bicicletta è dotata di un sistema combinato di pedalata con e senza energia elettrica. Il sistema elettrico funziona in combinazione con la velocità della pedalata. Più veloce si pedala, più potente sarà l’aiuto elettrico, sempre nel limite dei 25km/h massimi.
  • Page 16: Ricaricare La Batteria

    LA BATTERIA Questa bicicletta usa batterie agli ioni di litio, il cui ciclo vitale dipende dal suo corretto utilizzo. A differenza da altre batterie, le batterie agli ioni di litio non subiscono il cosiddetto effetto “memoria” per cui possono essere ricaricate anche se non completamente scariche.
  • Page 17 ATTENZIONE La batteria contiene sostanze pericolose. Non aprire la batteria e non inserire oggetti al suo interno. Non lasciare in carica durante la notte. Non caricare la batteria mentre non si è in grado di controllare la bicicletta. Procedere con la carica della batteria in ambienti asciutti, lontano da combustibili ed elementi infiammabili. Utilizzare la batteria solo se completamente carica, per non ridurne il ciclo vitale.
  • Page 18: Rimozione Batteria

    PRECAUZIONI Non utilizzare la bicicletta se il caricabatteria è ancora inserito. Interrompere la ricarica in caso di odore di surriscaldamento elettrico. Interrompere la ricarica e non utilizzare la bicicletta in caso di perdita di liquido dalla batteria. Non toccare qualsiasi sostanza che fuoriesca dalle batterie. Le batterie contengono sostanze pericolose all’interno. Non lasciare che bambini o animali tocchino la batteria.
  • Page 19 DISTANZA La distanza massima percorribile con la bicicletta è di circa 50 km. L’autonomia della carica della batteria (e quindi della distanza massima di percorrenza) può variare in funzione di vari fattori, quali: 1. Condizioni del suolo (superfici sconnesse riducono l’autonomia di carica). 2.
  • Page 20 5. La centralina della bicicletta dispone di una protezione contro il sovraccarico, che spegne automaticamente il motore, per poi riaccenderlo una volta che il sovraccarico è stato eliminato. 6. Il carico massimo della bicicletta è di 100 kg, e si consiglia di non eccederlo durante la guida. Superare il peso massimo potrebbe essere pericoloso per il conducente 7.
  • Page 21: Dati Tecnici

    Si consiglia di conservare la bicicletta in luoghi chiusi, freschi e asciutti. IMPORTANTE Si ricorda che è assolutamente vietato aprire il veicolo. Diversamente l’utente si assume i rischi che ne potrebbero derivare. DATI TECNICI Nome prodotto MD-E26MTBF CAPRI26FAT Soglia massima di carico 100 kg Altezza utente consigliata 150-190cm Velocità...
  • Page 22: Dichiarazione Di Conformita

    della richiesta di intervento. Il prodotto non conforme dovrà essere riconsegnato nell’imballo originale, completo di tutti gli accessori. Termine di garanzia della batteria: mesi 6. La garanzia non si applica in caso di danni provocati da incuria, uso o installazione non conformi alle istruzioni fornite, manomissione, modifiche del prodotto o del numero di matricola, danni dovuti a cause accidentali o a negligenza dell’acquirente con particolare riferimento alle parti esterne.
  • Page 23 Le immagini presenti in questo manuale sono puramente a scopo illustrativo. L’Azienda declina ogni responsabilità per l’utilizzo improprio del prodotto. L’Azienda si riserva il diritto di effettuare modifiche nella tecnologia, nelle attrezzature e nel manuale d’uso senza preavviso. MADE IN TAIWAN Importato e Distribuito da Consumer Electronics Spa Piazza G.F.Ferré...
  • Page 25 CAPRI 26FAT MD-E26MTBF ELECTRIC MTB BIKE USER MANUAL - ORIGINAL INSTRUCTIONS WARNING his appliance can be used by children aged from 12 years old and above, and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instructions concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 26 TECHNICAL PARAMETERS AND PERFORMANCE INDICATORS Main parameters: Range per charge: ≤ 50km Minimum loading capacity: 30kg Loading capacity: 100kg Tire: 26inch × 4.0inch Max speed: ≤ 25km/h Power consumption: < 1.2kwh/100km The distance of the front and the rear wheel: 108 cm approx Battery main technical parameters: Type: Lithium battery Capacity: 8.8Ah...
  • Page 27 AT FIRST Carefully read this user manual before using the bike. Keep this user manual for future references. In order to avoid damage, carefully read and follow the instructions of this user manual. The Retailer and the Distributor are not responsible of damages to objects and/or people caused by the incorrect use of the bike. Please check whether the tires are damaged.
  • Page 28 PRODUCT FEATURE INTRODUCTION Our electric bicycles are safe, beautiful, environmental, fashion and popular, special for sports, relax and environmental user. This series is light and convenient for relax and travel. Environmental: It does not use gas, it does not end gas, motor is without noise, it is a perfect environmental vehicle. Safe: Appropriate speed, good brake.
  • Page 29 LCD DISPLAY UP button Power on/off button DOWN button PAS level (assistance-level indication) Battery capacity indicator CRUISE function (not available with this model) Power-assisted function (PAS) Single trip time (TM) / Total trip time (TTM) Throttle display (not available with this model) 6km/h push power assistance Speed indicator: Riding speed unit (km/h or MPH) / Max speed (MXS) / Average speed (AVS)
  • Page 30 Display look at start: From display look number 1, shortly press the on/off button to get display look number 2 (in the riding condition, the display will return to look number 1 after 5 seconds).
  • Page 31 From screen number 2, shortly press the on/off button to get screen number 3 (in the riding condition, the display will return to the main screen number 1 after 5 seconds). ● Assist ratio gear When riding, press the UP or DOWN keys to modify the power/speed gear (from 1 to 5). Gear 1 is for minimum power.
  • Page 32 abnormality; 06: motor or controller has short circuit abnormality. Error codes flashes on the display. Once the fault is removed, the display will exit from the fault code display interface and return to main screen look. Note: Because of the continous upgrading of the Manufacturer, the content of the manual could differ from the real product, but it will not affect your normal use.
  • Page 33 SPEED SENSOR (imitation torque type) Sensor installation drawing (central axis and crank set between).
  • Page 34: Pedal Adjustment

    PEDAL ADJUSTMENT “L” is the left pedal, “R” is the right pedal; both of them should tight together by forward position. SADDLE ADJUSTMENT For the riding height, please pay attention to the distance between the seat cushion and the pedal at the lowest position. The riding height has been well adjusted if your knee joint can bend slightly when your foot is placed on the pedal (at the bottom).
  • Page 35: Brake Adjustment

    BRAKE ADJUSTMENT When adjusting the brake, make sure that the brake surface contacts the brake disc tightly when the handlebar is clenched to the middle. If you feel the brakes are not working well, you can use the brake cable tension adjusting screw to adjust the brake stroke. This screw is located at the brake handle (see “A”).
  • Page 36 direction of the bike. 6. The function of “L” is adjusting the chain moving to the left when limiting of the low gear. That means limiting the range to the left of derailleur (left and right side are according to the forward direction of the bike).
  • Page 37 This is the Shimano controller on the handlebar. The bike has 8 speeds PEDALLING POWER The bike is equipped with a set of electric/pedalling power system. The motor will help you a lot. The electric power system is working according to the speed of your pedalling. The faster you’re pedalling, the stronger the electric power will be within its limit speed of 25km/h;...
  • Page 38: About Battery Charging

    ABOUT BATTERY This bike is using lithium-ion batteries as power supply. In contrast to other lithium batteries, the lithium-ion batteries are free of “memory effects” and can be recharged even if the power is not completely exhausted. Battery life is closely related to the correct way to use: Start or uphill with pedal power.
  • Page 39 WARNING The battery contains dangerous substances. Do not attempt to open the battery and do not insert objects inside it. Do not charge overnight or when you are not able to observe the bike. Charge and store in an open dry area, away from combustibles (meaning items that can catch fire). Use the battery only if fully charged, otherwise the battery life will be shorter.
  • Page 40: Battery Removal

    CAUTIONS Unplug the charger before riding the bike. Stop using the bike in case of burning smell. Stop charging and do not use the bike if anything leaks out from the battery. Do not touch anything leaking out from the battery. Do not let children or animals touch the battery.
  • Page 41 DISTANCE The maximum range of the bike is approx. 50 km. The battery charge (and therefore the maximum distance) is affected by some factors like: 1. Ground condition (when ground is not flat, the discharge is increased). 2. Weight of the user and of the loading weight. 3.
  • Page 42 WARNING Turn off the power switch when you get off the bike, to prevent from suddenly started accidents (involuntary rotation of speed handlebar). WARNING Avoid stationary with frequent starting of the bike speed control; it would reduce battery life and motor life and would damage electrical switches. SAFETY RIDE Wear a helmet.
  • Page 43: After-Sale Service

    PARAMETERS Model name MD-E26MTBF CAPRI26FAT Maximum loading 100kg Suggested user height 150-190cm Maximum speed 25 km/h Gear 8 speeds Shimano Motor power 250W brushless Endurance mileage 50 km (depending on ground, inclination, speed, driving style) Power supply AC 100-240V, 50/60Hz...
  • Page 44: Correct Disposal Of The Product

    CORRECT DISPOSAL OF THE PRODUCT According to the European Directive 2006/66/CE This marking on battery indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.
