Summary of Contents for legate SMART CAMERA
- Page 1 SMART CAMERA Manual Guide Legate Smart Home Security System...
-
Page 2: Let's Get Started
Let’s Get Started. Install the app Download the Legate Smart Home from Google Play or the App Store on a compatible phone or tablet. Register and login Register on the app by using your contact number or Email address. Connect to wifi Make sure that your mobile phone and smart device are connected to 2.4 GHz... - Page 3 Legate Smart Camera to Legate Smart Home App...
- Page 4 (note: You’ll hear “Camera Start” voice which indicates the Smart Camera is ready to connect to Legate Smart Home app. If there’s no voice, press and hold the Reset Button until a voice audio comes out) Legate Smart Camera - Connecting the Smart Device to Legate Smart Home app...
- Page 5 Add Smart Device Open Legate Smart Home app, Under “Security & Sensor” tab Click “+” or Add Device. Click “Smart Camera”. Legate Smart Camera - Connecting the Smart Device to Legate Smart Home app...
- Page 6 Network Configuration Click “Next Step” button. Enter your Wifi Password. Then click “Confirm” button. (note: Only 2.4 GHz Wifi network are supported) Legate Smart Camera - Connecting the Smart Device to Legate Smart Home app...
- Page 7 Follow the instruction and click After scanning the QR to the Smart “Continue” button. Camera, you will hear a beep sound. Then click “I Heard a Prompt” Legate Smart Camera - Connecting the Smart Device to Legate Smart Home app...
- Page 8 Network Configuration Wait for the Smart Device Click “Done” button when the Smart connects to the app. Device is successfully added. (note: You can change the device’s name) Legate Smart Camera - Connecting the Smart Device to Legate Smart Home app...
- Page 9 Legate Smart Camera Features...
-
Page 10: Main Function
Main Function 7. Play or Pause 1. Preview Mode 4. Settings 8. Video Timeline 2. Camera Volume 5. Connection Signal 9. Playback 3. Live Preview 6. Full Screen Legate Smart Camera - Features... -
Page 11: Motion Detection
Motion Detection Enable to set the sensitivity level of the Smart Camera’s motion detection. Click “Alarm” button. Select the Sensitivity level Push Notification will be sent to your of motion detection. phone once the Smart Camera detects any movements. Legate Smart Camera - Features... -
Page 12: Recording Mode
Recording Mode Enable to set the mode of video recording. Click “ ” button on upper Click “Memory Card Settings” Select the Recording Mode. right corner of Smart Camera tab. main page. Legate Smart Camera - Features... -
Page 13: Push Notification
Push Notification Enable to turn off the notification. Click “Me” button on Legate Click “Push Notification” Can turn on or turn off the Smart Home app. Then click tab. “Enable notification” “Settings”. Legate Smart Camera - Features... - Page 14 Remove Device from Legate Smart Home app The device will restore to default settings. Click “ ” button on upper Click “Remove Device” Click “Confirm” button to right corner of Smart Camera tab. completely remove the device main page. from the Legate Smart Home app.
- Page 15 Legate Smart Camera Configuration & Specifications...
- Page 16 Cord Reset Power USB Port Camera Mounting Button Adapter Bracket Factory Setting Reset: Press and Hold the Reset Button for 10 seconds until “Factory Reset” voice audio comes out from the Smart Camera. Legate Smart Camera - Configurations & Specifications...
- Page 17 Wireless Encryption WEP/WPA/WPA2 Encription Power Input 5V 1.6A Total Power Consumption 3.5W (Max) Wireless Standard 2.4G 802.11 b/g/n Support systems IOS 7.0 or above, Android 4.0 or above Free App Legate Smart Home Legate Smart Camera - Configurations & Specifications...
- Page 18 Your one stop shop for all your Smart Home needs www.legate.com.sg...
