Orban iMix 5.1 Quick Start Manual

This guide references iMix 5.1 Headphone
Monitorand offers the quickest way to install and
begin using your new 5.1 Headphone Monitor.
WhileiMix's default settings are found to work in
most applications, please read through the
documentationto ensure you are getting the best
experience fromiMix. The full owner's manual
may be downloadedfrom our website at
www.Orban.com. Whileyou are there, please
take a few moments to complete the warranty
registration form.
1. Mount the unit into your rack or place on a
stable surface.
2. Connect your BNC AES input cables and
output cables.
3. Connect iMix 5.1 to a power source with the
supplied cables,
4. iMix 5.1 will automatically power up when AC
power is applied.
5. Connect any pair of headphones with a 3.5mm
TRS for monitoring.
iMix 5.1 has been designed with ease of use in mind. Most of the common settings are available for
modification right from the home screen - we call this featur home screen selection mode. When the unit
is at the home screen, press the HOME key to invoke this mode; a selection box will appear. Rotate the
selection knob to move the selection boc to the desired setting to be changed and press the ENTER key
to modify the selected value. Rotate the selection knob again to change the setting, andthen press the
ENTER key to confirm. Pressing the HOME or BACK keys exits this mode.
Rotate the knob right or left to change the headphone volume up or down. A sub-menu with 24 segment
volume control is displayed. Press ENTER to toggle to the monitor selector. L/R, C/LFE, Ls/Rs, LtRT
output, 5.1 Surroundoutput, and L/R inout are available for listening. Press HOME or Back to exit out.
sales@orban.com
FRONT PANEL FEATURES
INPUT LEVELS: Displays audio levels of the inbound audio stream
OVER TARGET: Red LED illuminates if the measured audio value is
over the user specificd target range
ON TARGET: Green LED illuminates when the measured audio value
is within the defined range Default +/-2 LU
UNDER TARGET: Blue LED illuminates if the measured audio value
drops below the user specified range
NETWORK: Green LED indicator will illuminate when a network
connection has been established
VACUUM FLORESCENT DISPLAY: Displays current operating status
of the unit and programming menus
ROTARY KNOB: Changes the headphone volume; Selects values
and navigates through the user interface
ENTER KEY: Used to enter a sub-menus or confirm/save selections
HOME KEY: Returns to the home screen or enters home screen
selection mode
BACK KEY: Returns to the previous menu or revert any selection
without saving
HEADPHONE JACK: Aceepts any headphone or monitor that has
a 3.5mm stereo mini-jack connection.
