OMEGA AIR AWS-C Instructions Manual

Tyre inflation controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation and operating
manual
AWS-C Tyre inflation controller
Please read the following instructions carefully before installing tyre inflation controller
service. Trouble free and safe operating of the unit can only be guaranteed if
recommendations and conditions stated in this manual are respected.
3400760 - AWS-C_v1.00-OmegaAir_eng_ver03012013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWS-C and is the answer not in the manual?

Questions and answers

Summary of Contents for OMEGA AIR AWS-C

  • Page 1 Installation and operating manual AWS-C Tyre inflation controller Please read the following instructions carefully before installing tyre inflation controller service. Trouble free and safe operating of the unit can only be guaranteed if recommendations and conditions stated in this manual are respected.

  • Page 2: Technical Data

    AWS-C Installation and operating manual Technical data Type AWS-C Operating temperature -20°C do 45°C Voltage 230V; 50Hz Power 30VA Max. Operating pressure 0 do 10bar Recommended min. inlet pressure min 10 bar Inlet connection Push connection ø8 ( 1/4” ) Outlet connection Push connection ø8 ( 1/4”...

  • Page 3: Safety Instructions

    Use original spare parts only.  Use the device for the appropriate purpose only.  Appropriate use AWS-C tyre inflation controller is intended exclusively for the following purpose: Indication of pressure in tyres/pneumatics  Correction of pressure in tyres (fill/release pressure) ...
  • Page 4 AWS-C Installation and operating manual Description Picture 2: Bill of material 1 – Aluminium housing 8 - LCD 2 - LED light signal 9 - Silencer (Exhaust) 3 - Button + 10 – Outlet connection for compressed air 4 - Button - 11 –...

  • Page 5: Installation

    AWS-C Installation and operating manual Installation AWS-C controller can be installed in two ways .  Picture 3: Mounting on the wall Picture 4: Mounting in the housing MOUNTIN ON THE WALL To mount controller on the wall brackets have to be aligned to back side of the controller.

  • Page 6: Sleep Mode

    AWS-C Installation and operating manual Start up At start-up light and audible signal will appear for short time. On the display information about firmware appear for short time. Picture 5: Information display at start-up Inflation procedure / pressure correction Controller has three modes: Sleep mode.
  • Page 7 AWS-C Installation and operating manual SET TARGET PRESSURE MODE In this mode we can set target pressure in tyre by pressing + and – buttons. Target pressure value is located in right upper part of display. Picture 7: Set target pressure The lowest target pressure value is 0,5 bar.
  • Page 8 AWS-C Installation and operating manual Inflation / pressure correction During inflation / pressure correction controller is trying to equalize actual pressure with set target value. Actual pressure in tyre is displayed in the center of display during the inflation /pressure correction procedure. Small number in upper right corner of display is target pressure.
  • Page 9 AWS-C Installation and operating manual Language selection Information on display can be present in four preset languages (default + three additional languages). Language can be changed by pressing + button. When controller goes to »sleep mode« selected language goes to default language.
  • Page 10 AWS-C Installation and operating manual Flowchart Controller state Sleep – show logo Parameter No event in Target pressure sets back to 2bar last 2 minutes Language sets back to default Button pressed Set target pressure mode Target pressure between 0.5bar and 9.5bar or pressure 0.0bar is set by pressing buttons +/-.
  • Page 11 AWS-C Installation and operating manual Settings and operating data download To change settings or download operating data please contact manufacturer. Manufacturer can change settings or download operating data with »service network interface«. Service Network...

  • Page 12: Troubleshooting

    AWS-C Installation and operating manual Troubleshooting Problem Possible cause Solution LCD display is blank No el. Power. Check electricity.   or off Faulty PCB. Contact supplier or service.   Tyre inflation did Pressure in the tyre is below o,3 This is normal operation.
