Summary of Contents for Star systems Pyxis
- Page 1 Pyxis User Guide FCC ID:2AA7KPYXIS-HRD23000 Version 0.3.3...
-
Page 2: Table Of Contents
Barcode Scanner (Optional) ........................21 Restrictions: ..........................23 SAR Information ........................24 Simplified EU declaration of conformity ................... 24 Warranty ..........................25 WARRANTY ................................25 EXCLUSIONS .................................25 RMA PROCEDURE ..............................25 DISCLAIMER OF WARRANTIES ..........................25 LIMITATION OF LIABILITY .............................25 Pyxis User Guide - Version 0.3.3... -
Page 3: User Guide
Specifications are subjected to changes without prior notice. Disclaimer and limitation of liability Star Systems International Ltd. shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages about the furnishing, performance, or use of this material. - Page 4 Device Types HRD23001F (FCC ID: 2AA7KPYXIS-HRD23000) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use when properly worn on the body is1.168 W/kg and for head is 0.24 W/kg Pyxis User Guide - Version 0.3.3...
-
Page 5: Introduction
UHF scanning etc. It is configured with Android OS and it possesses high reliability and expansibility. With a set of advanced data acquisition options, PYXIS can be operated in various industries to acquire precise and abundant datum automatically. Meanwhile, the device can match the options with staffs accordingly. -
Page 6: Caution Read This Before Using Battery
Do not attempt to recharge it or to use it. Replace it with a new battery. • Store the battery at temperatures between 5 °C and 20 °C (41 °F and 68 °F). 1.3 Charger The charger model is GME10D-050200FGu, output voltage/current is 5V DC/2A. Pyxis User Guide - Version 0.3.3... -
Page 7: Notes
3. The suitable temperature range for this product and accessories is 0-10°C to 50°C. Caution risk of explosion if battery is replaced by an incorrect type. Dispose of any used batteries according to the instructions. Pyxis User Guide - Version 0.3.3... -
Page 8: Components And Features
Components and Features 2.1 Components and Buttons Pyxis has 4 side buttons, 4 main buttons and a trigger on handle, UHF scanning area, 2D scanning module (OPTIONAL), HD camera and flashlight locate on the top. Function Description 1. RGB LED Monitor Display Device 2. -
Page 9: Device Specifications
Supports up to 32 GB Micro SD card User environment Operating temp. -10℃ to 50℃ Storage Temp. 40℃ to 70℃ Humidity 5%RH – 95%RH non-condensing Sealing IP65, IEC sealing standard Drop Multiple 1.8m/4.0ft drops to the concrete specification Pyxis User Guide - Version 0.3.3... - Page 10 Bluetooth 4.0; max. power 6.16 dBm Data collection Barcode 2D CMOS scanning engine scanning (Honeywell N6603/Zebra SE4710) (Optional) RFID NFC 13.56Mhz 62.57 dBμV/m (3m) -14.23dBμA/m (10m) Developing Environment STAR Systems software develop kit Language Java Develop Eclipse/Android Studio Pyxis User Guide - Version 0.3.3...
-
Page 11: Micro Sd, Sim Card
By using a USB Type-C connector. Please, it is recommended to only use the original adaptor for charging the device. Charging the battery with a power supply adapter not provided/approved by Star Systems may damage your device and/or void your warranty. -
Page 12: Uhf Rfid
3. UHF RFID Open App Center in the Applications. Open “UHF” to read and write, kill and lock a UHF transponder/tag. Pyxis User Guide - Version 0.3.3... -
Page 13: Other Features
4. Other Features 4.1 PING tool 1. Open “PING” in App Center. 2. Setup PING parameters and select external/internal addresses. Pyxis User Guide - Version 0.3.3... -
Page 14: Bluetooth
4.2 Bluetooth 1. Open “BT Printer” in App Center. 2. In the list of detected devices, click the device that you want to pair with. 3. Select printer and click “Print” to start printing contents. Pyxis User Guide - Version 0.3.3... -
Page 15: Gps
4.3 GPS 1. Click “GPS” in App Center to open GPS test. 2. Setup GPS parameters to access GPS information. Pyxis User Guide - Version 0.3.3... -
Page 16: Volume Setup
4.4 Volume setup 1. Click “Volume” in App Center. 2. Setup volume per user requirements. Pyxis User Guide - Version 0.3.3... -
Page 17: Sensor
4.5 Sensor 1. Click “Sensor” in App Center. 2. Setup the sensor per user requirements. Pyxis User Guide - Version 0.3.3... -
Page 18: Keyboard
4.6 Keyboard 1. Click “Keyboard” in App Center. 2. Setup and test the main value of the device. Pyxis User Guide - Version 0.3.3... -
Page 19: Network
4.7 Network 1. Click “Network” in App Center. 2. Test WIFI/Mobile signal. Pyxis User Guide - Version 0.3.3... -
Page 20: Keyboard Emulator (Optional)
4.8 Keyboard emulator (optional) The keyboard emulator can be used in multiple operating background and output formats directly. And it includes Prefix/Suffix/Enter/TAB. Please check the Keyboard emulator manual for more details. Pyxis User Guide - Version 0.3.3... -
Page 21: Call Function
SMS and MMS 1. Click to open message window. 2. Click to input message recipient and contents. 3. Click to send out messages. 4. Click to add attachments, pictures or videos. Pyxis User Guide - Version 0.3.3... -
Page 22: Optional Features
2. Press the “SCAN” button or click the scan key to start scanning. “Auto interval” can be adjusted by the user as desired. Caution: Please scan codes in correct orientation otherwise the scanning may failed. 1D barcode: 2D code: Pyxis User Guide - Version 0.3.3... - Page 23 Max. radiant power: 0.6mW Wavelength: 655nM IEC 60825-1 (Ed.2.0). 21CFR 1040.10 and 1040.11 standard. Pyxis User Guide - Version 0.3.3...
-
Page 24: Restrictions
Restrictions: This device is restricted to indoor use where operated in the European Community using frequency in 5150MHz-5350MHz to reduce the potential for interference. Pyxis User Guide - Version 0.3.3... -
Page 25: Sar Information
SAR Information The SAR limit of Europe is 2.0 W/kg. Device types Pyxis has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.219W/kg and when properly worn on the body is 1.216 W/kg. This device was tested for typical body-worn operations with the back of the handset kept 0.5cm from the body. -
Page 26: Warranty
Prior to shipping a product to Star Systems International for warranty inspection, replacement or repair, an RMA number must be obtained from Star Systems International’s RMA department at +852 3691 9925 or by email at support@star-int.net. RMA forms can be downloaded from the Star Systems International website or the Customer can receive the form by email by contacting the RMA department. - Page 27 Electronic Tolling (ETC), Electronic Vehicle Registration (EVR), Fleet Management, Parking and Secure Access Control applications. STAR Systems International’s mission is to enable our partners and users to experience high- performance and reliable integrated solutions which are key elements of any modern Smart City initiatives.
