Summary of Contents for Guardian Telecom AG17
- Page 1 Alarm Tone Generator Model AG17 Installation & Operation P005089 Rev. C 150930 9/30/2015 12:25 PM Ph: 403.258.3100 \ email:info@guardiantelecom.com \ www.guardiantelecom.com...
-
Page 2: Table Of Contents
Installation and Operation Model AG17 Table of Contents Package Contents ..................2 Overview....................3 AG17 Tone Generator Models ..............3 Features ....................3 Front Panel ................... 4 Rear Panel .................... 5 Installing the AG17 ..................7 Unit Operation ................... 8 ... -
Page 3: Overview
Installation is simple. An audio override facility also allows voice-paging announcements. The AG17 Tone Generator is one component in Guardian Telecom's full line of paging system products, which include amplifiers and signal and switch conditioning equipment. -
Page 4: Front Panel
Guardian Telecom Inc. Installation and Operation Model AG17 Front Panel LED Indicators, Clear and Reset Switches 1. Power LED Illuminates when the unit is on. 2. Alarm LEDs Illuminates when the alarm is active. 3. Clear Switch Activates the 3-Beep Clear tone. -
Page 5: Rear Panel
Guardian Telecom Inc. Installation and Operation Model AG17 Rear Panel The rear panel of the AG17 is where all the connections are made. 1. Clear/Reset Terminals Connect Clear and Reset switches. 2. Alarm Logic Outputs Trigger external devices. 3. Audio / Logic Output Connect external devices. -
Page 6: Figure 3 - Typical Installation
Guardian Telecom Inc. Installation and Operation Model AG17 AG-17 Alarm Tone Generator POWER ALARM RELAY CONTACTS RELAY CONTACTS NORMALLY OPEN COMMON NORMALLY CLOSED CLEAR RESET OUTPUT VOLUME INPUT ALARM LOGIC OUT ALARM LOGIC IN INPUT / OUTPUT AUDIO LOGIC + - + -... -
Page 7: Installing The Ag17
Ensure all devices that will be connected to the AG17 are turned off. Plug the AG17 into the power source but do not apply power to the AG17 before connecting input and output devices. See: Unit Operation for Use the following sequence when wiring connections: more details. -
Page 8: Unit Operation
Plug the connector back into the unit. See: Unit Operation and When connections are complete, apply power to the AG17. The AG17 Programming the AG17, operates with default settings as soon as power is applied. If customized below. -
Page 9: Alarm Logic Outputs
Tip: The Timer To enable the Timer, program the unit. Timer duration on the AG17 can determines the length of time the alarm sounds be programmed for tones operating from 30 seconds to 30 minutes. -
Page 10: Override Audio / Logic Inputs
The AG17 is preset for 60 dB attenuated alarm tones. To select attenuation, Setting Triggering and program the unit. The AG17 can be programmed so that the alarm tone is Attenuation, below. completely muted by the Override or attenuated by 10dB, 20dB, or 60dB. -
Page 11: Programming The Ag17
Follow the Setting Tables below and use the touch-tone telephone keys to below. program the AG17. When programming is complete, disconnect the telephone from the AG17. Setting Input Channel Alarm Tones Press the # key, then the Channel Number (1-8), then the Alarm Tone Number (0-9). -
Page 12: Setting Triggering And Attenuation
Guardian Telecom Inc. Installation and Operation Model AG17 Setting Triggering and Attenuation Press the # key, then the number 0, then the Triggering and Attenuation Number (1-9). Triggering and Attenuation 1 - 9 Level triggered inputs 10dB Tone attenuation... -
Page 13: Setting The Timer For Pulse-Triggered Logic Inputs
Guardian Telecom Inc. Installation and Operation Model AG17 Setting the Timer for Pulse-Triggered Logic Inputs Press the key, then the Timer Duration Number (1-9). Timer Duration 1 - 9 1 = 30 seconds 2 = 1 minute 3 = 2 minutes... -
Page 14: Displaying All Parameters Stored In Non-Volatile Ram
Guardian Telecom Inc. Installation and Operation Model AG17 Displaying All Parameters Stored In Non-Volatile RAM See: LED Display Press the key, then the number 0. Pattern Table. LED Display Pattern Table SEQUENCE #1 Input Triggering Mode and Attenuation On = LED Flashing... -
Page 15: Product Specifications
Guardian Telecom Inc. Installation and Operation Model AG17 Product Specifications LECTRICAL EQUIREMENTS 120VAC O 240VAC A NPUT OLTAGE VAILABLE ACTORY RDER 50/60H NPUT REQUENCY 12VA AXIMUM URRENT ONSUMPTION 1/2A; 3AGC, 250V LARM OGIC NPUTS CTIVATING EVICE ONTACT ELAY 5V @ 1mA M... - Page 16 Guardian Telecom Inc. Installation and Operation Model AG17 PTIONAL LARM ELAY UTPUTS ONTACTS VAC: 120 VAC @ 1 A M . , VDC: 30 VDC @ 2 A M AXIMUM UTPUT ONTACT APACITY RJ11 ROGRAMMING ECHANICAL ONSTRUCTION TEEL OWDER OATED 77 MM (16.5...
-
Page 17: Warranty
Warranty Guardian Telecom warrants your product to be free of defects in material and workmanship for a period of one year. Guardian Telecom will repair or replace any defective unit that is under warranty free of charge. This warranty is null and void if any non-authorized modifications have been made to this product, or if it has been subjected to misuse, neglect, or accident. -
Page 18: Guardian Product Return
When a product has been installed following user manual instructions, and the unit fails to operate, the user must contact Guardian Telecom to obtain authorization to return the product. After providing information on the product, the owner and the nature of the problem, Guardian will issue a RMA number, to be shown on documentation returned with the product. - Page 19 Guardian Telecom Inc. Installation and Operation Model AG17 Notes: Model No. Part No. Serial No. Date of Purchase Page 19...
- Page 20 Guardian Telecom Inc. Toll-free 1-800-363-8010 Phone (403) 258-3100 Fax. (403) 253-4967 http://www.guardiantelecom.com E-mail: mailto:sales@guardiantelecom.com (Click to open message box) CONNECTED. PROTECTED. © Guardian Telecom Inc. 2015...
