CHAD VALLEY BABY DELUXE SWING
Assembly Instructions - IMPORTANT! Keep for future reference
450/6177
Dimensions
Width - 72cm
Depth - 61cm
Height - 57cm
Suitable from birth to 9kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Argos CHAD VALLEY BABY DELUXE SWING
- Page 1 CHAD VALLEY BABY DELUXE SWING Assembly Instructions - IMPORTANT! Keep for future reference 450/6177 Dimensions Width - 72cm Depth - 61cm Height - 57cm Suitable from birth to 9kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800...
- Page 2 Safety and Care Advice IMPORTANT! – KEEP FOR FUTURE REFERENCE WARNINGS: TO PREVENT SERIOUS INJURY OR DEATH FROM CHILDREN FALLING OR BEING STRANGLED IN STRAPS: IMPORTANT! Read the instructions carefully before use and keep them for future reference.This product should be assembled by an adult •...
-
Page 3: Parts List
If you have damaged or missing components, 1.Parts List call the Customer Helpline: 03456 400 800 Please check you have all the parts listed below legs (2) seat pad assembly toybar toys (3) screws (2) Tools required（not included） Phillips Screwdriver... -
Page 4: Assembly Instruction
2. Assembly Instruction Step1 Assembly 2 legs until metal spring buttons lock into place (Figures A & A1). Metal Note: Swing arms should Spring Button be on the inside of the frame when assembled correctly. (see CORRECT view). Step2 Pull apart tubes on both frame assemblies until Button button pops out (Figure B... - Page 5 2. Assembly Instruction Step5 Assembling Seat to swing: Press swing arm connectors onto swing arms until spring button pops into place. (Figure E). Note: One side of swing arm has a notch (Figure E1) which goes into swing arm notch connector with corresponing groove.
-
Page 6: Battery Installation
4. Battery Installation: Step1 Swing Motion & Sound Unit Battery Installation: Unlatch battery door using a Phillips head screwdriver. Insert 4 “C” batteries making sure the + and - are facing the correct way. The battery compartment is engraved for clarity. Re-attach the battery door. - Page 7 5. To Use Swing: Repeat for other shoulder strap (Figure N). Fold over lap pad cover and fasten to cover restraint system (Figure O). To Adjust Shoulder Straps on Seat Pad: To adjust shoulder strap, feed shoulder strap through buckle on back side of seat pad and pull tightly to secure (Figure P).
- Page 8 5. To Use Swing : Swing & Sound Press the button to turn on/turn off the swing & music function 3 LED Display Press the button Swing consecutively to select the three Speed Button different speed setting. Music Button There are 3 LED indicators sit Volume side to show the 3 different wing Control...
- Page 9 6. To Fold: Press swing motion lock button (Figure R). Press both side buttons and push in both front legs to fold. (Figure S). press press both lock button side buttons Fold up footrest (Figure T). TO CLEAN: Headrest Remove headrest from seat pad. Machine wash in cold water - gentle cycle.
-
Page 10: Care And Maintenance
Care and Maintenance This product was designed and manufactured with quality materials and craftsmanship. 1. Inspect regularly for: Worn parts, torn materials or stitching. Loose screws, bent or broken frame parts. Broken, damaged or missing parts. Do not use the reclined cradle if any components are broken or missing. 2. - Page 12 Argos Avebury, 489-499 Avebury Boulevard, Milton Keynes, MK9 2NW www.argos.co.uk Customer Helpline: 03456 400 800...
