Quick Installation Guide
AirGo
Misting System
®
READ AND SAVE THESE INSTRUCTIONS
1. PREPARE PUMP
2. INSTALL BRACKET
3/8 in. Hex Bolt
3/8 in. Flat Washer
3/8 in. Nylock Nut
Save nuts for pump installation.
Bracket not needed for AirGo All Terrain.
3. INSTALL PUMP (AIRGO)
5/16-18 Nylock Nut
Advertisement
Table of Contents
Summary of Contents for BIG ASS FANS AirGo Misting System
- Page 1 Quick Installation Guide AirGo Misting System ® READ AND SAVE THESE INSTRUCTIONS 1. PREPARE PUMP 2. INSTALL BRACKET 3/8 in. Hex Bolt 3/8 in. Flat Washer 3/8 in. Nylock Nut Save nuts for pump installation. Bracket not needed for AirGo All Terrain. 3.
- Page 2 INSTALL PUMP (AIRGO ALL TERRAIN) 5/16-18 Nylock Nut 4. CONNECT HOSE 5. CONNECT WATER SOURCE OPERATION Water supply requirements: 15–60 PSI, 140°F (60°C) max 1. Turn off fan. Power Start 2. Plug in misting pump (20 A circuit). Switch Switch 3.
