4. Installation mechanical
Place your caravan or trailer on a level surface.
Preferably a lifting ramp or an assembly pit. If you
use a car-jack, please make sure that the caravan
or trailer is secured with adequate supporting
blocks.
Working under the vehicle without
support and security measures can
cause danger to your life!
Take all parts out of the packing and arrange
them on the floor in front of you.
M1 Determine ideal position
Fig. 8.1
Determine the ideal position in front of and
behind the axle. When doing this, please note the
following:
- the distance between the lower edges of the
chassis and the floor (min. 50 mm !)
- Frame bottom line and ground
(recommended ground clearance min. 120 mm)
- additional parts fixed on the trailer, such as
waste-water pipes, spare wheel, etc.
M2 Mounting frame and clamping plates
Fig. 4.1 to 4.5
Fasten the lower mounting plate + clamp at the
mounting frame by means of the screws M10x30
and the self-locking nuts M10 ISO7040. Please fix
the nuts only by hand.
Position the mounting frame at the chassis, as
shown in fig. 4.3. The distance from the centre of
the mounting frame to the tyre is approx. 200 mm.
Caution: Ensure that the short lateral projection
of the mounting frame is directed towards the
tyre!
Now, fasten the upper clamping plate using the
screws M10x60 mm and the appropriate self-
locking nuts M10 ISO7040.
Please fix the nuts only by hand.
GB4
M3 Mounting stabilizer bar
Fig. 5.1 + 5.2
ATTENTION!
The length of the stabilizer bar has to be adjusted
to the vehicle in accordance with the mounting
dimensions given under pic. 8.1 and 9.1.
If the stabilizer bar does not enter in the square
axle of the drive unit for at least 300 mm, you
must use a (optional available) longer stabilizer
bar. Otherwise the optimal function cannot be
guaranteed.
If the enclosed stabilizer bar is too long, it must be
shortened correspondingly.
Determine the exact centre of the stabilizer and
mark it.
Insert the stabilizer bar into the rectangular tube
of the mounting frame being already installed.
Place the other mounting frame above the other
end of the stabilizer rod and fasten also the
mounting frame to the vehicle chassis using the
clamping plates. Only tighten the screws finger-
tight.
Align the stabilizer bar centrically and tighten its
clamping screws finger-tight.
M4 Drive unit
Fig. 6.1 + 6.2
Ensure that the short lateral projection of the
mounting frame is directed towards the tyre (fig.
4.3).
Fasten the drive units at the mounting frame
using the self-locking screws M10x14 mm (can be
recognized by the red barrel) and use the
washers.
