- Page 1 WF-OL – Automatic Device QUICK INSTALLATION GUIDE customersupport@solem.fr +33 467 592 425 SOLEM www.solem.fr P-21...
- Page 2 INTRODUCTION WF-OL products are used to control the Automatism or garden lighting from a smartphone or tablet. The Automation programs are transmitted in modules from the SolemWF free application available on the App Store or Google Play (Play Store). The user must first establish a connection between their smartphone or tablet and the WF product.
- Page 3 ❶ - DOWNLOAD THE SolemWF App Make sure your device is connected to Internet (Wi-Fi or 3G Minimum), then download the SolemWF App on the App Store or Google Play (Play Store) ❷ - CONFIGURATION DU RESEAU Wi-Fi When you power the irrigation Wi-Fi module, it starts in install mode. In less than 30 seconds, the network module will be visible in the settings of your wireless smartphone or tablet.
- Page 4 ❸ CONNECT THROUGH A ROUTER ‘’Client mode via a router’’ You can connect one or more products on your internet router. Your network product will be visible and programmable entirely from your Smartphone or Tablet just by connecting on your Router. A / Apple iOS Smartphone or Tablet Version.
- Page 5 Press on the product identification number in yellow. This product code is the default SSID number printed on the back of the module. See the Default SSID number Select : “ configurate as a client of another Wi-Fi network’’ Select your router network. In this example, we choose “ solem visiteurs”. P-25...
- Page 6 Enter the router network password Send informations to the product Exit the App, wait until the LED of the product turns green. P-26...
- Page 7 If the phone does not reconnect to the router go back to the settings to reactivate your Wi-Fi connection (See screens below). Connect to your route In this example, we connect to ‘’Solem-visiteurs’’. Enter the router network password The smartphone is connected to your router...
- Page 8 2 - Internet function access activation’’ The ‘’access internet’’ function is accessible only when connected to your router. Open the App and enter the product On the screen shot above, the products listed under ‘’Local’’ are directly connected to the router. The products listed under the Site ‘’Olivier’’...
- Page 9 3 - Assign the product to a “ site” This will allow you to access the module via Internet. ▶ ▶ Select the Internet access and download the instructions to the module. To check that the Internet mode is activated, desactivate the WiFi in the settings of your phone.
- Page 10 B/ Android version . 1- Connection of the product to a router Once step ❷, is completed, open SolemWF,. One or the other of the 2 following pages will appear: First time you connect You have already connected a WF or a BL module a WF or BL module 1 –...
- Page 11 Press on the product identification number in yellow. This product code is the default SSID number printed on the back of the module. See the Default SSID number Select : “ configurate as a client of another Wi-Fi network’’ Select your router network. In this example, we choose “ solem-visiteurs” P-31...
- Page 12 Enter the router network password Send informations to the product ▶ Then press on OK to validate Push on ‘’Logo Send’’ Exit the App, wait until the LED of the product turns green P-32...
- Page 13 If the phone does not reconnect to the router go back to the settings to reactivate your Wi-Fi connection (See screens below). Connect to your router In this example, we connect to ‘’Solem-visiteurs’’ ▶ Router Connected Enter the router network password...
- Page 14 2 - ‘’Internet Access’’ Activation Open the App and select the product Press on ‘’Internet Access’’ Select the ‘’internet Access’’ option. Go to next step P-34...
- Page 15 3 - Assign the product to a site. Enter the site name In this example, the site is called ‘’ SOLEM’’. By pressing “OK” you download the information in the product. To check that the Internet mode is activated, desac- tivate the WiFi in the settings of your phone.
- Page 16 ❹ CONNECTING in «DIRECT MODE» ‘’Independant Network’’ Or ‘’Access Point’’ After having completed step ❷, open the App - Select the Icon of your product (ex : WF-OL) The installation menu will appear : - Select the product code number in orange...
- Page 17 Go back to the App, your product is now ready to be used and can be programmed. ❺ PROGRAMMATION The automation program is intuitive and simple, you can create your automation schedules. If you encounter problems, contact SOLEM to answer your questions at customersupport@solem.fr P-37...
- Page 18 ❻ MOUNTING AND WIRING MODULE The WF case must be installed indoor use only. It can be fixed against a wall with the screws supplied with the product. Cabling of the transformer to the power supply: -The WF case must be installed the nearest possible of the electric plug. The power plug must be accessible at all time in order to unplug the device in case of emergency.
- Page 19 W, we recommend using a power contactor to absorb the peak current. To get the installa- tion diagram, you can visit our website www.solem.us in the heading ‘’Outdoor Automation’’, click on ‘’learn more’’ on the WiFi Series’’ Then Click on ‘’Learn More’’...
- Page 20 INFORMATIONS System Requirements Apple iOS 7 Minimum Android 4.0 Minimum Troubbleshooting Difficulties Solutions No action 1/ Verify power supply 2/ Verify wiring No communication Verify proper network is selected in your smart- phone settings. Schedules Shifted Controller had lost time after a long period of power failure and need to be resynchronize with the App.
- Page 21 DECLARATION OF CONFORMITY WITH EUROPEAN GUIDELINES Solem Electronics said that the Irrigation module sector type WF-OL Complies with the essential requirements of the R&TTE 1999/5/CE. This product meets the following standards RADIO Standard: ETSI EN 300 328 v1.8.1 EMF Standard : EN 62311 (2008) and recommendation 1999/519/CE CEM Stan- dard : ETSI EN 301 489-1 v.1.9.2 et ETSI EN 301 489-17 v2.2.1...
