Summary of Contents for OnReal G1
- Page 3 Contents Live Camera Wireless Camera User Manual...
- Page 4 Viscose Clip Magnet Sucker...
- Page 5 Get to Know Your Live Camera micro-USB micro SD Port Slot...
- Page 6 Shutter Button Charger Status Camera Status LED Lens Power/Wi-Fi Button Buzzer...
- Page 7 Setting up your camera for the first time in two steps. Step1. Charging the battery Note: Please charge for at least 2 hours (2.1A) to make sure your device is fully charged.
- Page 8 1. Connect your camera to a power source using the supplied Micro USB cable. 2. The “Charger Status LED” turns green, when your camera is fully charged. While it's charging, “Charger Status LED” turns orange.
- Page 9 Step2. Inserting the micro SD card 1. Find the micro SD slot located at the bottom of the camera. Note: Please use brand Micro SD and class 10.(for example,16GB SanDisk class 10)
- Page 10 2. Insert a micro SD card with the gold-plated side facing the same direction as the lens. 3. The card will make a slight clicking sound, when it’s securely inserted.
- Page 12 Powering on your camera 1. Simply press the “Power/Wi-Fi Button” to power on your camera. 2. The “Camera Status LED” will keep flashing green. How to take photo 1. Press the “Shutter Button”. 2. The “Camera Status LED” will flash red, and your camera will beep.
- Page 13 How to record video 1. Press the "Shutter Button"about 2 seconds, till the "Camera Status LED" flash red,also beep. 2. Shortly press the"Shutter Button" to stop recording, the "Camera Status LED" will be flashing green...
- Page 14 How to connect wifi Note:Please do not attempt to connect to your mobile device (wi-fi) when the battery is low. 1.Camera app 1. Open the App store or the Playstore on your Mobile phone. 2. Search for the app "NeoMe" and install it.
- Page 15 2.On your camera 1. Be sure the camera is powered 2. Short press"Power/Wi-Fi Button", the “Camera Status LED” will keep flashing for 3 seconds,then wifi is on. 3.On your phone 1. Press the Home button, and then tap Settings > Wi-Fi. 2.
- Page 16 4..Find and open the App "Neome" on your phone , enjoy the live video . You can also download the video to your phone and review it. 5. Note: the wifi will be disconnected if you dont use it for a long time.
- Page 17 LED indicator 1. Camera Status LED Status LED behavior Power on and Flashing green Standby Taking photo Flashes red once Recording video Flashing red Flashing blue Enabling Wi-Fi for 3 seconds System error (As: SD memory full, Turns yellow no SD card, etc.) Removable USB driver Turns white mode(Link to PC)
- Page 18 2. Charger Status LED Status LED behavior Charging Turns orange Turns green Full charge Low battery Flashing red...
- Page 19 CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRENT TYPE. DISPOSE OF USED BATTERY ACCORDING TO THE INSTRUCTIONS.
- Page 20 Specifications Model: G1 Color: Black Weight: 25g Dimension: 42mm x 42mm x 20mm Chipsets: NTK 96658 Sensor: SONY IMX179 Image Sensor Resolution: 8 Mega Pixels Wireless: 802.11b/g/n Lens: 6G(Glass) 120° Viewing Angle Photo Resolution: 8M/5M/2M Image Format: JPG Video Resolution: 1080P(30fps),...
- Page 21 Video Format: MOV Video Compression Format: H.264 Shooting Mode: Single Shot Time Lapse Record: 1s/ 5s / 10s / 30s / 60s Connections: USB 2.0 Language: Alternative Storage: Up to 64GB micro-SD card (not included) Power Supply: Li-ion Battery 400mAh Battery Life: about 70 Mins (WIFI Function off) Charging time: 2 hours Interface: Micro-USB, Micro-SD...
- Page 22 Functions support: Gapless Recording , Cycled Recording, WIFI Function, Selfie automatically Operating Temperature: 32°F to 104°F (0°C to 40°C) Storage Temperature: -4°F to 176°F (-20°C to 80°C)
Need help?
Do you have a question about the G1 and is the answer not in the manual?
Questions and answers
In use, a new TF card (Great Wall, 32g, fat32 format, class10) cannot be recognized properly. Switching to another TF card can still not be recognizable. After inserting the card, the green light first and the yellow light first, cannot be used 在使用中使用了一个新的tf卡（长城，32g，fat32格式，class10）无法正常识别，换用其他的tf卡任然无法识别，插入卡后，先亮绿灯再亮黄灯，无法使用
The OnReal G1 may not be recognizing the TF card due to one of the following reasons:
1. Incompatible Card Brand: The manual specifies using a "brand Micro SD" card. The Great Wall brand may not be fully compatible.
2. Card Formatting Issue: Although the card is FAT32 formatted, reformatting it using a different method (such as on a PC or another device) may help.
3. Card Not Properly Inserted: Ensure the gold-plated side of the card faces the same direction as the lens and clicks into place.
4. System Error Indication: The yellow LED suggests an issue such as "SD memory full" or "no SD card detected." Try a different brand (e.g., SanDisk) of Class 10 micro SD up to 64GB.
5. Device Malfunction: If multiple TF cards are not recognized, the camera’s micro SD slot may be damaged.
Try using a different recommended brand of micro SD card and reinsert it properly. If the issue persists, the camera may need servicing.
This answer is automatically generated
