EMA

EPU

EVD

DISPLAY - ELEGANCE

VELA

instruction manual for user - ENGLISH

Table of Contents

Need help?

Do you have a question about the EMA and is the answer not in the manual?

Questions and answers

Summary of Contents for Vela EMA

Page 1 DISPLAY - ELEGANCE VELA instruction manual for user - ENGLISH...
Page 2: Read Carefully
Read carefully all parts of this manual before using the product. The espresso coffee machine that you have purchased has been designed and manufactured with innovative methods and technology which ensure long lasting quality and reliability. This manual will guide you in discovering the advantages of selecting this product. You will find information on how to get the best out of your machine, how to always keep it efficient and what to do if you should have any problems.
Page 3 When using the electrical appliance, several safety standards must be observed: - do not touch the appliance when hands or feet are wet or damp; - do not use the appliance in bare feet; - do not use extensions in rooms where there are showers or baths; - do not pull on the power cord to disconnect the appliance from the power outlet;...
Page 4: Warnings For The Installer
GUARANTEE 15 months on all components except electrical and electronic components and expendable pieces. Presentation This product has been manufactured in compliance with the regulations for foodstuff ma- chinery according to par. 2.1 of Directive 2006/42/EC. The espresso coffee machine is strictly for professional use only. It is designed for the prepara- tion of hot drinks such as tea, cappuccinos and long, short and espresso coffee, etc.
Page 5 Hydraulic connections The installer must carry out the hydraulic connections in accordance with the hygiene norms and the hydraulic safety norms for environmental protection in force in the place of installation. Installation report When installation is complete, the appliance has to be started, brought to the nominal working condition and left for 30 minutes in the "ready to operate"...
Page 7 1. Machine description ..............page 148 2. Group EMA ................page 148 3. Preparation of the machine .............page 148 4. Grinding and dosing coffee .............page 149 5. Turning on the machine ............page 149 6. Making coffee ................page 150 7. Hot water delivery ..............page 150 8.
Page 8: Machine Description
2. Boiler level-check window 3. Steam knob 4. Steam nozzle 5. Filter holder 6. Hot water nozzle 7. Group EMA 8. Heating element power supply switch 9. Service on switch 10. Boiler / pump pressure gauge 11. Cup heater switch 12.
Page 9: Grinding And Dosing Coffee
Grinding and dosing coffee Place the grinder-doser in a convenient place near the machine. Grinding and dosing of coffee must take place in accordance with the instructions of the manufacturer of the grinder-doser. To achieve good quality espresso coffee we suggest the following: the producer;...
Page 10: Making Coffee
Making coffee Put the coffee cup under the dispensing spout; Praise the lever: the coffee starts pouring and can be stopped bend the lever, when the desired amount of coffee has been delivered. Hot water delivery To dispense hot water, turn the tap knob counter-clockwise(1): the hot water coming out of the nozzle (2) will be proportional to the opening of the tap..
Page 11: Cup Heater
Cup heater To activate or deactivate the cup heater, turn the cup heater switch placed above the turn on machine switch (1) to ON. To adjust the cup heater proceed as follows: (2); (3); (4), the temperature will be in proportion to the value indicated on the thermostato.
Page 13 1. Machine description ..............page 154 2. Push button panel ..............page 154 3. Preparation of the machine .............page 154 4. Grinding and dosing coffee .............page 155 5. Turning on the machine ............page 155 6. Making coffee ................page 156 7. Hot water delivery ..............page 156 8.
Page 14: Push Button Panel
Machine description 1. Cup heater surface 2. Boiler level-check window 3. Steam knob 4. Steam nozzle 5. Filter holder 6. Hot water nozzle 7. Push button panel 8. Heating element power supply switch 9. Service on switch 10. Boiler / pump pressure gauge 11.
Page 15 Grinding and dosing coffee Place the grinder-doser in a convenient place near the machine. Grinding and dosing of coffee must take place in accordance with the instructions of the manufacturer of the grinder-doser. To achieve good quality espresso coffee we suggest the following: the producer;...
Page 16 Making coffee Dispensing coffee Put the coffee cup under the dispensing spout; Press the desired delivery switch. You will have the delivery which can be stopped by means of the same switch once the desired amount of coffee in the cup is obtained. Hot water delivery To dispense hot water, turn the tap knob counter-clockwise(1): the hot water coming out of the nozzle (2) will be proportional to the opening of the tap..
Page 17 Cup heater To activate or deactivate the cup heater, turn the cup heater switch placed above the turn on machine switch (1) to ON. To adjust the cup heater proceed as follows: (2); (3); (4), the temperature will be in proportion to the value indicated on the thermostato.
Page 19 1. Machine description ..............page 160 2. Push button panel ..............page 160 3. Preparation of the machine .............page 161 4. Grinding and dosing coffee .............page 161 5. Turning on the machine ............page 161 6. Making coffee ................page 162 6.1 Programming coffee doses ..........page 162 6.2 Delivery of coffee doses ............page 162 7.
Page 20 Machine description 1. Cup heater surface 2. Boiler level-check window 3. Steam knob 4. Programming key 5. Steam nozzle 6. Filter holder 7. Push button panel 8. Hot water nozzle 9. Services push button panel 10. ON switch 11. Pressure gauge 12.
Page 21 Preparation of the machine The preparation of the machine and the installation operations must be carried out by qualified personnel only. The installer must strictly follow the indications provided in chap. "Warnings for the Installer". Use of the machine without all the installation operations having been carried out by technical personnel could damage it seriously.
Page 22: Programming Coffee Doses
Making coffee 6.1 Programming coffee doses 1) to ON ; button panel, and turn the programming key (1) to OFF. For models with 2-3-4 groups it is possible to program simultaneously all machine push button panels using only the right push button panel. It is however advisable to check the programming of the other push button panels.
Page 23: Hot Water Programming
Hot water delivery 7.1 Hot water programming 1) to ON ; (4); Press the of the right push button panel until the LEDs of the key the push button panel comes on ; Press the hot water delivery key When the desired dose has been attained, confirm by pressing the Upon completion of programming, turn the programming key (1) back to OFF.
Page 24 Steam delivery To dispense steam, turn the tap knob counter-clockwise (1): the steam coming out of the nozzle (2) will be proportional to the opening of the tap. The use of the steam dispensing point (steam nozzle), must always be preceded by the performance of the condensation draining operation for at least 2 seconds.
Page 25 DISPLAY - ELEGANCE 1. Machine description ..............page 166 2. Push button panel ..............page 167 3. Preparation of the machine .............page 168 4. Grinding and dosing coffee .............page 168 5. Turning on the machine ............page 169 6. Making coffee ................page 170 7.
Page 26 Machine description DISPLAY ELEGANCE Cup heater surface Boiler level-check window Steam knob Programming key Steam nozzle Filter holder Push button panel Hot water nozzle Display + Service on switch 10. ON switch 11. Autosteamer 12. Steam nozzle autosteamer 13. Temperature probe 14.
Page 27 Push button panel DISPLAY ELEGANCE 2.1 Services push button MANUAL MANUAL coffee coffee DISPLAY water 2.2 Services push button MANUAL DISPLAY AUTOSTEAMER with coffee water AUTOSTEAMER 2.3 Push button USE / PROGRAMMING PROGRAMMING Espresso coffee Mode Espresso coffees Enter Medium coffee Increase Medium coffees Decrease...
Page 28 Preparation of the machine DISPLAY ELEGANCE The preparation of the machine and the installation operations must be carried out by qualified personnel only. The installer must strictly follow the indications provided in chap. "Warnings for the Installer". Use of the machine without all the installation operations having been carried out by technical personnel could damage it seriously.
Page 29 Turning on the machine DISPLAY ELEGANCE (1) of the machine; please wait for test result functional test - ok - Boiler pressure Boiler temperature Day of the week 1 - Monday 1,0 Atm 120°C 2 - Tuesday 09:16 09-02-04 1 3 - Wednesday 4 - Thursday 5 - Friday...
Page 30 Making coffee DISPLAY ELEGANCE 6.1 Programming coffee doses 1) to ON ; button panel, and turn the programming key (1) to OFF. For models with 2-3-4 groups it is possible to program simultaneously all machine push button panels using only the right push button panel. It is however advisable to check the programming of the other push button panels.
Page 31 Hot water delivery DISPLAY ELEGANCE 7.1 Hot water programming 1) to ON ; (3); Press the of the right push button panel until the LED of the of the push button panel comes on; Press the hot water delivery key When the desired dose has been attained, confirm by pressing the Upon completion of programming, turn the programming key (1) back to OFF.
Page 32 Autosteamer DISPLAY ELEGANCE 9.1 Use The autosteamer system makes it possible to make the milk foamy and to bring it up to a programmable temperature. 1) Immerge the ends of the autosteamer into the beverage to be heated; 2) Press the autosteamer key; 3) Wait for steam delivery to be completed.
Page 33: Selection Count
9.3 MILK FOAMING adjustment To adjust milk foaming with the autosteamer, proceed as follows: 3) of the adjustment valve: - to reduce foaming turn clockwise - to increase foaming turn counter-clockwise To keep the steam dispensers in perfect working order, it is advisable to carry out a delivery dry run after each use.
Page 34 Cup heater DISPLAY ELEGANCE 11.1 Use 1) Place the cups to be heated on the appropriate surface (1); 2) Place the cup heater switch (2) in the ON l'interruttore scaldatazze. 11.2 Adjustment OFF position (3); total coffee 000000 message : cup heater 80°c dify the temperature of the autosteamer shown on the display;...
Page 35: Luminous Scrolling Messages
Luminous scrolling messages DISPLAY ELEGANCE 12.1 Characteristics (1) (maximum 50 characters) with dedicated programmer; Possibility to modify speed of text scrolling with dedicated programmer. 12.2 Message programming 2) and then power on; The display will show a flashing cursor on the first digit; To insert the character, press the "RIGHT ARROW"...
Page 36: Programming Of Parameters Of The Machine
Programming of parameters of the machine DISPLAY ELEGANCE (1) to the ON position flashes on the display); 1,0 Atm 120°C P have access to programming; 09:16 09-02-04 1 clock set-up menu (see alongside) use the MODE key 09:16 18-02-05 1 the next one within the same area;...
Page 37: Start-Up Programming
13.1 Programming of CLOCK and DATE clock set-up Change of hour, date and day of: 09:16 18-02-05 1 1) Enter programming until showing on the display; 2) keep the MODE key pressed for 3 seconds; 3) modify the parameter while flashing with the keys 4) to move to the next parameter press the key ENTER 5) to move to subsequent programming press the key MODE 13.2 START-UP programming...
Page 38 13.4 REST DAY programming To program machine shutdown for rest day(s), follow the instructions below: Days of the week Monday Tuesday Wednesday Thursday Friday Saturday Sunday Shutdown 1) Choose the day(s) for shutdown by scrolling with the keys 2) Use the key ENTER to set the dash "...
Page 39 13.7 LANGUAGE programming Programming of the language displayed: language 1) Enter programming until showing on the display : english 2) set the language with the keys 3) to move to the subsequent programming press the key MODE In English it is possible to choose between degrees Celsius (°C) and Fahrenheit (°F) 13.8 CUP HEATER programming Temperature programming and activation of cup heater: cup heater...
Page 40: Resetting Data To Zero
Resetting data to zero DISPLAY ELEGANCE 14.1 Resetting of dosers alarm doser alarm 021 007 000 1) Place the programming switch (1) in the ON position; 2) with the key MODE scroll the menu until the dispenser alarms; reset counting ? press + 3 sec.
Page 41 Signals DISPLAY ELEGANCE SIGNALS CAUSE SOLUTION Boiler filled with water when 1,1 Atm 121°C using the machine for the Wait for the boiler to be completely filled. BOILER FILLING first time or when refilling to reach the water level Make sure the mains cock is opened. Time for filling the boiler 1,1 Atm 121°C...
Page 42 Softener Mains water contains insoluble salts, which cause the build-up of lime scale deposits in the boiler and in other parts of the machine. The softener makes it possible to eliminate or substantially reduce the presence of these mineral salts. The resin softener has the property of retaining the calcium contained in the water.
Page 43: Cappuccino Maker
Cappuccino maker Put the suction tube inside the milk; place the jug under the spout of the cappuccino maker; turn the steam tap counter-clockwise, upon reaching the desi- red amount, close the steam tap; pour the foamed milk into the cups with coffee. To obtain delivery of warm milk without foam, lift the tab (1) upwards.
Page 44 Cleaning For perfect cleaning and efficiency of the appliance, several simple cleaning operations are necessary on the functional parts and accessories as well as the body panels. The indications given here are ap- plicable for normal use of the coffee machine. If the machine is used continuously, then cleaning should be performed more frequently.
Page 45: List Of Hazards
When cleaning, always use cloths that are completely clean and hygienic. To guarantee the correct operation and hygiene of the hot beverages dispenser, it is necessary to use the cleaning methods and products suitable for this purpose. Do not immerge the machine into water. Never use alkaline detergents, solvents, alcohol or aggressive substances.
Page 46: Checks And Maintenance
Checks and Maintenance Maintenance must be carried out in order to ensure perfect safety and efficiency of the machine over time. In particular, it is advisable to ask the Technical Service to carry out an overall check of the machine at least once a year. Intervention Weekly Monthly GAUGE...
