Summary of Contents for StrongBond FNX800
- Page 1 User Manual Strongbond Grinder Model：FNX800 Flooring Wholesale Limited T/A Look Floors 9 Industry Road, Penrose, Auckland 1061, New Zealand...
- Page 2 Thank you for using Strongbond floor grinder Model FNX800 distributed by Flooring Wholesale Limited T/A Look Floors. This model FNX800 is a multi-functional floor grinder. It is used for grinding and polishing of old and new floor, which greatly improves the efficiency of construction, renovation and maintenance of concrete, Stone, and epoxy floor.
-
Page 3: Table Of Contents
Contents Chapter I Safety and Attention 1.1 Safety guidance 1.2 Precautions Chapter II Inspection, Technical Data and Product Description 2.1 Inspection 2.2 Technical Data 2.3 Product Description Chapter III Operational Instructions 3.1 Method of operation 3.2 Equipment relocation after use 3.3 Handling of equipment Chapter IV Equipment Connections and Reset of Inverter 4.1 Guide to wiring... -
Page 4: Chapter I Safety And Attention
Chapter I Safety and Attention To ensure the safety of your machine operator, equipment and property, please read this manual carefully before using the machine. Strictly follow and implement the manual in the process of handling, installation, debugging, operation and overhaul. 1.1 Safety guidance (1) Operators must wear waterproof and insulated work safety shoes and gloves, it is strictly prohibited to operate the machine barefoot. -
Page 5: Precautions
1.2 Precautions (1) After both dry or wet grinding, clean the dust or mud at the bottom of the gearbox. Also clean the bottom of the gearbox when the abrasive is changed, to improve the heat dissipation effect of the gearbox and increase the service life of the machine. -
Page 6: Technical Data
LOOK FLOORS in time to avoid any accidents. (4) Check the items are complete: one machine, two lifting rods, one water retaining belt, one industrial plug, one vacuum cleaner connector, and twelve abrasive switch discs. 2.2 Technical Data Model FNX800 Motor Power 11KW Inverter Capacity 11KW (15HP) -
Page 7: Product Description
2.3 Product Description ○ ○ ○ ○ ○ ○ 1 -Handle 2 -Hand shank 3 -Button 4 -Digital Panel 5 - Additional Weight 6 -Ventilation ○ ○ ○ ○ ○ ○ ○ 7 -Electric Box 8 -Water tank 9 -Pedals 10 -Support Wheel 11 -Water Valve 12 -Motor... - Page 8 (3) After the inspection is complete, install the grinder on the grinder installation plate. The basic steps are as follows: (a) Clean the surface of the abrasive mounting surface, pin and magnet. (b) Align the holes of the diamond abrasive matrix or the holes of the resin abrasive joint plate with the pins, insert them and be absorbed by magnets on the chassis, check for firmness, and note that the particle size of all abrasive tools in a set of processes must be the same.
- Page 9 forbidden to be used for rough grinding, and medium and high speed is used in fine grinding or polishing. (4) For emergency stops, first rotate the speed knob counterclockwise to zero speed, and then press the stop button. (5) Adjust the water valve to inject water. (6) The machine can be connected to the vacuum cleaner to ensure dust-free operation during dry grinding.
-
Page 10: Equipment Relocation After Use
c) Tilt up the additional weight: before upward the machine head, lock the additional weight to the hole on the lever, move the additional weight to the tilted position, fix the locking screw to the positioning bolt on the wheel leg, be careful not to move too fast and too hard. 3.2 Equipment relocation after use (1) Place the hand shank in a suitable position and disconnect the power cable. -
Page 11: Handling Of Equipment
(3) Clean the ventilation of inverter and motor. After the machine was used in a wet environment, pay attention to cleaning the surface of the machine. (4) Clean the dust of the inverter and the ventilation hole of the motor with a dry rag to avoid failure due to the backlog of dust in the next use. -
Page 12: Switch Boxes, Inverter And Electrical Wiring
(4) The grounding line of the equipment must be reliably connected to the ground line of the power supply system to prevent the operator from being subjected to electric shocks. (5) The power supply cable of this equipment shall use 3 wires and 1 grounding wire. Please insert the plug of the power supply cable into the suitable power socket. -
Page 13: Chapter Vi Quality Assurance
(3) Please change gear oil of 220 # regularly. The new machine grinds about 10,000 square meters and needs to change gear oil once. After 12 months of grinding period, change gear oil once. The FNX800 needs 11 liters of gear oil of 220 #. -
Page 14: Chapter Vii Simple Fault Removal
due to the wiring method, if it is necessary for the When the machine cannot run normally wrong manufacturer to send people to overhaul, if the non-machine fault is checked by the maintenance people, the customer must pay the travel expenses and working fee within the warranty period. Chapter VII Simple Fault Removal If there is a sudden shutdown during the operation of the machine, please check it as follows: (1) Check whether the connection wire screw of the power supply general switch is secure and the ammeter... - Page 15 Signature Note: 1. The warranty period of motor of FNX800 is one year and frequency converter has a warranty of 18 months. The warranty period of gearbox is one year. Other vulnerable parts which includes water supply switches, racks, handles, grinding disc has a warranty period of three months 2.
