Summary of Contents for KingCraft TAW-2030
-
Page 1: Air Compressor
8 GALLON OIL FREE AIR COMPRESSOR Item# 6923-05 Model # TAW-2030 PLEASE READ AND SAVE ALL INSTRUCTIONS TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL. -
Page 2: Table Of Contents
TABLE OF CONTENTS Index Important Safety Instructions Electrical Requirements General Safety Rules List of Main Parts, Tech. Specifications Contents of Packaging, Installation Operation Maintenance Trouble Shooting Service Center Warranty Information Warranty Card P. 1 P. 2-5 P. 6 P. 7,8 P. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL. Before working with this air compressor read and understand this instruction manual and safety instructions carefully. In case you notice any transport damage, when unpacking the air compressor, you must not start to work with it! The air compressor has to be checked and repaired by an authorized service station. - Page 4 READ ALL SAFETY WARNINGS BEFORE USING AIR COMPRESSOR! WARNING: TO REDUCE THE RISK OF EXPLOSION OR FIRE OR BURSTING Serious injury or death may occur from normal electrical sparks in motor and pressure switch. Serious injury may occur if any air compressor ventilation openings are restricted, causing air compressor to overheat and possibly ignite a fire.
- Page 5 WARNING: TO REDUCE THE RISK TO BREATHING, OF BURNS AND FLYING OBJECTS Serious injury or death could occur from inhaling compressed air. The air stream may contain carbon monoxide, toxic vapors or solid particles. Sprayed materials such as paint, paint solvents, paint remover, insecticides, weed killers, etc., contain harmful vapors and poisons.
- Page 6 Do not use the compressor without installed guards. Please note that the compressor will start automatically, when the pressure falls to the minimum designated pressure. Make sure the compressor is switched off and disconnected from the power supply before starting it. Check the compressor and the accessories carefully and follow their instructions for maintenance.
-
Page 7: Electrical Requirements
Electrical Requirements General Electrical Connections DANGER: To reduce the risk of electrocution: 1. Use only identical replacement parts when servicing. Servicing should be performed by a qualified service technician. 2. Do not use in rain or where floor is wet. This tool is intended for indoor residential use only. -
Page 8: General Safety Rules
GENERAL SAFETY RULES WARNING! Read, understand and save all instructions. Failure to follow all instructions listed below may result in electric shock, fire or serious personal injury. The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. - Page 9 3. Do not use tool if switch does not turn ON or OFF. Any tool that cannot be controlled with a switch is dangerous and must be repaired. 4. Place the switch in locked or OFF position before making any adjustments, changing accessories or storing the tool.
-
Page 10: Technical Specifications
1. pressure tank 2. drain valve 3. suction filter 4. pressure regulator 5. on-/off-switch 6. working pressure gauge TECHNICAL SPECIFICATIONS: Model Number TAW-2030 Rating Voltage 120V, 60 Hz Power Consumption 1.5 KW/2HP Motor speed 3400min Displacement 3.9 CFM @ 40psi 3.0 CFM @ 90psi... -
Page 11: Contents Of Packaging, Installation
CONTENTS OF PACKAGING a. Air compressor b. 25’ coiled air hose with female and male quick connector c. 2 brass quick female connectors d. 2 wheels e. 2 wheel bolts 2 lock nuts g. 2 screw nuts If any of the above items are missing, please contact our service department at 1-888- 367-7373 (http://wwwk.wk-usa.com) for replacement. -
Page 12: Before Each Use
OPERATION Before each use CAUTION: Serious injury or death may occur if electrical sparks from motor and pressure switch come in contact with flammable vapors, combustible dust, gases or other combustible materials. When using the air compressor for spray painting, place the air compressor as far away from the work area as possible. Use extra air hoses instead of extension cords. - Page 13 4. Set the pressure regulator to the required working pressure. (see FIG. 2) 5. Connect the air-hose to the pressure-hose connector (8). (see FIG. 3) 6. Connect the air-tool with the air-hose. 7. If you will not start to work immediately, switch the compressor off and disconnect from the power-supply.
- Page 14 Shutdown 1. Switch the compressor “OFF” (press switch down) never stop the air compressor by unplugging it from the power source. This could result in risk of electrocution. (see FIG. 1) 2. Drain air from the air tank by releasing air with an attached air tool or by pulling on the safety relieve vale ring.
-
Page 15: Maintenance
MAINTENANCE CAUTION: Before starting any maintenance or cleaning jobs, the compressor has to be switched off and disconnected from the power supply! Make sure the compressor accessories and air tools are relieved from pressure. Be sure that all safety and protection devices are operational after having finishing maintenance or cleaning jobs. -
Page 16: Trouble Shooting
TROUBLE SHOOTING Problem Cause Excessive tank • Pressure switch does pressure - safety not shut off motor valve pops off. when compressor reaches “cut-out” pressure. • Pressure switch “cut-out” too high. Air leaks at • Tube fittings are not fittings. tight enough. - Page 17 Air leaks in air • Damaged air tank. tank or at air tank welds. Air leaks between • Leaking ring. head and valve plate. Motor will not run • Tank pressure exceeds or restart. pressure switch “cut-in” pressure. • Wrong gauge wire or length of extension cord.
-
Page 18: Environmental Protection
Air leak from • Possible defect in safety safety valve. valve. Knocking Noise. • Malfunctioning check valve. Compressor is not • Prolonged excessive use of supplying enough air. air to operate • Compressor is not large accessories. enough for air requirement. •... -
Page 19: Limited Warranty
LIMITED WARRANTY Thank you for purchasing a top quality KingCraft product. This Oil Free Air Compressor item #6923-05 was tested and meets our stringent quality standards. This product is warranted to be free from manufacturing defects in original materials, including original parts, and workmanship until June 13 2006 or 1 year with proof of purchase. -
Page 21: Warranty Card
WARRANTY CARD KingCraft Oil Free Air Compressor, item # 6923-05 , model # TAW-2030 In case you find this product to be defective please send it within the warranty period to our service center. To avoid transport damages please send the product in the original packaging. In return you will receive your repaired item, a new product or a refund.
