ART. TRI-WBxxx
MONTAGGIO / MOUNTING / MONTAGE / MONTAJE
215
140
CABLAGGIO / WIRING / CÂBLAGE / CABLEADO
MP39695
120
MAX PG 21
POWER SUPPL
L
L
N
PE
2,5÷6 mm²
SERIAL LINE
A+ A-
0,5 mm²
ES. BELDEN 9841
(dimensioni in mm) / (dimensions in mm)
(dimensions en mm) / (dimensiones en mm)
-1-
Y
OR
L1 L2 L3
N P E
7,5÷10 mm²
TCP/IP LINE
RJ45
CA T5
ZP91049-1
