Dynamax SAPIP-LTE Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

SAPIP-LTE Quick Start Guide

Table of Contents

Section 1 Connect to SapIP-LTE through TeraTerm.......................................................................................2
Section 2 Verify SapIP Status..............................................................................................................................3
Section 3 Verify LTE Status...............................................................................................................................4
Section 4 Verify Log & LTE communication....................................................................................................5
Appendix: SAPIP-Cell-LTE Message Explanations...................................................................................6-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAPIP-LTE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dynamax SAPIP-LTE

  • Page 1: Table Of Contents

    SAPIP-LTE Quick Start Guide Table of Contents Section 1 Connect to SapIP-LTE through TeraTerm……………….……………...……………………………..….……..2 Section 2 Verify SapIP Status……….………………………………………………………...……………………………..….……..3 Section 3 Verify LTE Status..………………………………………………………………...……………………………..….……..4 Section 4 Verify Log & LTE communication…………………………..……………...……………………………..….……..5 Appendix: SAPIP-Cell-LTE Message Explanations………………………………...……………………………..…..6-10...

  • Page 2: Section 1 Connect To Sapip-Lte Through Teraterm

    Section 1 — Connect to SapIP-LTE through TeraTerm  Connect antenna to SapIP and lay antenna vertically next to a window.  Power on SapIP-LTE then connect it to PC using provided black USB cable.  When looking down from top of the enclo- sure, left window will show a yellow LED blinking.

  • Page 3: Section 2 Verify Sapip Status

    Section 2 — Verify SapIP Status  Type *** to enter USB command mode.  There is a list of USB commands available and can be downloaded from here.  Type “STAT” to check battery status, date/time, battery level, and logging status. ...

  • Page 4: Section 3 Verify Lte Status

    Section 3 — Verify LTE Status  Reboot SapIP by typing in “rboot”.  During the reboot, pay close attention to the following messages:  Version  Signal strength — ATDB  Date/time  There is a list of LTE commands available and can be downloaded from here.

  • Page 5: Section 4 Verify Log & Lte Communication

    Send SMS to Device (or send a single letter from cellphone to the listed SapIP number)  SapIP-LTE doesn’t wake up on demand. By sending 2 consecutive remote commands, SapIP-LTE will en- ter debug mode and stay awake for 20 minutes. During “No Sleep” period, SapIP-LTE will response to any remote command immediately. ...

  • Page 6: Appendix: Sapip-Cell-Lte Message Explanations

    Appendix: SAPIP-Cell-LTE Message Explanations CPU RESET, V535 (LTE NOSLEEP) CPU (central processor unit) Power-on message with the firmware version number (535) and options (LTE NOSLEEP). Possible options are LTE - 4G LTE network NOSLEEP - Digi module never goes to sleep Wait for power up…...
  • Page 7 ATSM1 The CPU is commanding sleep mode 1 (pin sleep). ATD51 The CPU is commanding D5=1 (associate light controlled by I/O line 5) ATAP1 The CPU is commanding API mode ATWR The CPU want the module to write the new settings ATAC The CPU wants to write all registers to non-volatile memory.
  • Page 8 4 min delay The next call to CheckForCommands to poll the web server will happen in 4 minutes LTE send... The CPU has called the LTESend function to send data through the LTE network GET /ServiceInterface.asmx/GetCommands?ID=ZZ00890015 HTTP/1.1 The HTTP (hyper text transfer protocol) request. The address of the SAPIP (serial number) is 890015 in this example.
  • Page 9 Skipping CFC Due to an upcoming measurement cycle (in <90 seconds), the CPU is skipping the call to CheckForCommands CheckforCommands... The CPU is about to check the web server for new commands 00567,04/15/2019,15:30,12.2,+0.2206,+0.2222,+0.2225,+0.0083,+0.2229,+0.2228,+0.2229,+0.0087,00.0470,000 00,+30.3,5.07,0000,0000.0,T,F,KKKKKKKKKUK Sample data record (number 567) to be sent for this unit with date, time, analog and digital readings SENDING DATA The CPU has initiated the SendData function PUT /service/putData/TEST/sapDataGSM.XML HTTP/1.1...
  • Page 10 WEB DEBUG NO SLEEP, secs left = 1800 The CPU is keeping the LTE module awake because the webserver sent an SMS for a diagnostic com- mand. After "secs left" gets to zero, the module may go back to sleep SLEEP_RQ HI The CPU is putting the module to sleep LTEwakeup...
