Panasonic NR-BV360Q Operating Instructions Manual

Contents

● Safety precautions .................................................................................................................. 2

● Usage precautions ................................................................................................................. 4

● Installation .............................................................................................................................. 6

● Parts identification .................................................................................................................. 7

● ECONAVI operation ............................................................................................................... 8

● Temperature control ............................................................................................................... 8

● Temperature control (Fine adjustment mode) ........................................................................ 9

● Quick Freezing ....................................................................................................................... 9

● Prime Fresh+ ....................................................................................................................... 10

● Prime Fresh room ................................................................................................................. 10

● Food storage in the Freezer room ........................................................................................ 10

● Usage tips ............................................................................................................................ 11

● How to clean the refrigerator ................................................................................................ 12

● Troubleshooting .................................................................................................................... 14

● Specifications ....................................................................................................................... 15

■

NON-CFC

This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for

insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth's ozone layer.

Thank you for purchasing the Panasonic product.

• Please read these instructions carefully and follow safety precautions on page 2-5 before using

this product.

• Please make sure the date and name of store of purchase are stamped in warranty card and

keep it with this operating instructions.

Operating Instructions

NR-BV360Q, NR-BV320Q, NR-BV280Q

Model No.:

Refrigerator

For Household Use

ARAH1E202360

Printed in Vietnam

P0920-0

Table of Contents

Summary of Contents for Panasonic NR-BV360Q

Page 1: Table Of Contents
This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth’s ozone layer. Thank you for purchasing the Panasonic product. • Please read these instructions carefully and follow safety precautions on page 2-5 before using this product.
Page 2: Safety Precautions
Safety precautions Please be sure to follow these instructions. WARNING CAUTION This sign means: It may lead to a serious This sign means: It may results in injury or injury or death. property damage. These signs mean prohibited action. This sign means required action. iso-butane This sign means the appliance must Risk of fire / flammable materials...
Page 3 Otherwise it may WARNING cause a fire, injury, electrical shock. When using... ● Do not damage the cooling circuit (piping on the back). ● Do not touch the compressor and pipes, because of high temperature, that there is a risk of burn injury. ●...
Page 4: Usage Precautions
CAUTION Otherwise it may cause injury, accidents. When opening/closing the doors... ● Do not put your hand in the gap between the doors. ● Do not open and close the doors forcefully. (Otherwise the food may be fallen and you may be injured.) When storing food...
Page 5 Usage precautions When using... ● When the plug is disconnected, leave it for 5 minutes before 5 mins plugging again. If not, the compressor may not work. ● Adjust the temperature according to the actual operating condition for energy saving. ●...
Page 6: Installation
●The refrigerator LED lamp, specially designed for this refrigerator, does not function on individual replacing. If you need replacement, please contact Panasonic Service Center. ●If there is no grounding wiring plug in refrigerator, it should be connected with grounding connection to prevent electrical hazard from electric leakage.
Page 7: Parts Identification
Parts identification FRIDGE ROOM PRIME FRESH ROOM FREEZER ROOM 1 LED Lamp 2 PC Glass tray 3 Control Panel 4 Glass tray crisper 5 Vegetable case 6 -3 C cold storage case 7 1-2 Glass tray 8 Ice maker 9 Ice cube tray 0 Ice box a FC Glass tray b Freezer case...
Page 8: Econavi Operation
ECONAVI operation Detect opening and closing of door and brightness around refrigerator, and automatically controls operation to save energy ECONAVI operation ●This refrigerator will learn the lifestyle patterns of your family from opening and the time periods of infrequent use to perform ECONAVI operation. ●The refrigerator learns your lifestyle pattern from the previous 3 weeks, and uses what it has learned from the 4 th week onwards.
Page 9: Temperature Control (Fine Adjustment Mode)
Temperature control (Fine adjustment mode) The refrigerator is specially designed for approriate use, which can adjust the temperature level to detailed 9 levels with the following details. How to operate the fine adjustment mode For the Freezer room 1. Press the button “Select” until LED “Freezer” turns on. 2.
Page 10: Prime Fresh
Prime Fresh+ How to operate the “Prime Fresh+” mode ●Press the button “Select” until the LED “Prime Fresh” turns on, then press “Temp Control” until the LED “Prime Fresh+” turns on. Remark: ●If you want to stop the operation immediately, repeat the procedure until the LED “Prime Fresh+”...
Page 11: Usage Tips
How to make ice cubes with ice maker STEP 1. Fill water in the ice cube tray till the water WATER LEVEL LINE level line. 2. Put ice cube tray inside Freezer room, wait until ice is made. ICE CUBE TRAY 3.
Page 12: How To Clean The Refrigerator
How to clean the refrigerator Interior cleaning Wipe off the stain with warm water. When stains can not Use lukewarm be removed easily, wipe them with warm water and soap water! by using a soft cloth. Then wipe the soap off using damp soft cloth. Exterior cleaning Cleaning by using soft cloth with warm water and soap.
Page 13 How to clean the refrigerator Removing PC glass tray for cleaning Removing FC glass tray for cleaning  Removing  Removing 1. Unhook the 1 . Unhook the protrusion at the protrusion at the back by lifting back by lifting it it upward and upward and pulling pulling the tray...
Page 14: Troubleshooting
Troubleshooting Before you call for service, please check the following items: ●Check that the plug and its socket are in good condition. ●Check if there is any problem on main fuse and electrical system of The refrigerator the house. does not operate. ●Check by unplug and wait for 5 minutes before plugging it back in.
Page 15: Specifications
The sound becomes more quiet after cooling fully. Lamp does not ●Please contact Panasonic service center. turn on. Specifications Model No. NR-BV360Q...

This manual is also suitable for:

Nr-bv320q Nr-bv280q
