- Page 1 Solar bollards 2SPBL-Series Installation instructions 123 Town Square Pl., #333 Tel. +1.201.490.4499 Jersey City, NJ 07310 www.solarpathusa.com...
- Page 2 Contents Component List…………………………….…………………………………3 Installation………………………………………………………………………4 Picture 1 Picture 2……………………………………………….…………4 Picture 3 Picture 4………………………………………………….………4 Picture 5 Picture 6……………………………………………………….…5 Picture 7 Picture 8…………………………………………………..……..5 Picture 9 Picture 10…………………………………………………….….6 123 Town Square Pl., #333 Tel. +1.201.490.4499 Jersey City, NJ 07310 www.solarpathusa.com...
- Page 3 . Component list 2SPBL1, 2SPBL2, 2SPBL3, 2SPBL4, 2SPBL5, 2SPBL6, 2SPBL7, 2SPBL8, 2SPBL9, 2SPBL10, 2SPBL12 series: item component quantities image remark Solar bollard 1 PC Expansion bolt 3 PCS optional Metal holder 1 PC optional 2SPBL11 series: item component quantities image remark Solar bollard 1 PC...
- Page 4 2. Installation This product has two kinds of installation: 1. For cement ground: do not need anchor bolts, use expansion bolt fix solar lamp body directly. 2SPBL1, 2SPBL2, 2SPBL3, 2SPBL4, 2SPBL5, 2SPBL6, 2SPBL7, 2SPBL8, 2SPBL9, 2SPBL10, 2SPBL12 series prepare three mounting holes, diameter 0.55 in, depth 3.34 in. (see picture 1) 2SPBL11 series prepare four mounting holes, diameter 0.55 in, depth 3.34 in.
- Page 5 ② We are recommending for soft ground: use anchor bolts to install the bollard per to the below. 1. Dig a hole, size 13.77 in(L)*13.77in(W) *7.87in(H). 2SPBL1, 2SPBL2, 2SPBL3, 2SPBL4, 2SPBL5, 2SPBL6, 2SPBL7, 2SPBL8, 2SPBL9, 2SPBL10, 2SPBL12 series see picture 5，2SPBL11 series see picture 6. Picture 5 Picture 6 2.
- Page 6 2. Put bollard on the anchor bolts, lock it using M10 nut and gasket. 2SPBL1, 2SPBL2, 2SPBL3, 2SPBL4, 2SPBL5, 2SPBL6, 2SPBL7, 2SPBL8, 2SPBL9, 2SPBL10, 2SPBL12 see picture 9，2SPBL11 see picture 10。 Picture 9 Picture 10 Bury solar bollard using cement and have it on surface level. 123 Town Square Pl., #333 Tel.
