Summary of Contents for Dualtools OS 3000
- Page 1 MULTI-TOOL OS 3000 OWNERS’ MANUAL WARNING: Read, understand and follow all safety rules and operating instructions in this manual before using this product. SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Maintenance ...................... 15 Parts List ......................17 Customer Service ....................18 INTRODUCTION The DUALTOOLS® OS 3000 Dual-Blade Multi-Function, Oscillating Tool has special features that make it different from other oscillating tools. Please read and understand this manual before using this product WARRANTY DUALTOOLS®... -
Page 3: Product Registration
PRODUCT REGISTRATION To get information on product updates, special offers, and warranty claims, register your DUALTOOLS® OS 3000 on our website www dualtools.com. Here is what you will need: • Sales Receipt • Machine Serial Number (see the product information decal located on the underside of the OS 3000). - Page 4 Note: The extension cord must have adequate wire size AWG (American Wire Gauge) for safe, efficient use. Smaller gauge wires have greater capacity (16 gauge wire has more capacity than 18 gauge wire). DUALTOOLS OS3000 manual_10-30-14.indd 3 10/30/14 2:55 PM...
- Page 5 • Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may effect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. DUALTOOLS OS3000 manual_10-30-14.indd 4 10/30/14 2:55 PM...
-
Page 6: Specific Safety Rules
• Keep the tool rests firmly tightened. Inspect and retighten tools rests before each use. WARNING Do not let familiarity with your OS 3000 make you careless. Remember that a careless fraction of a second is sufficient to cause severe injury. DUALTOOLS OS3000 manual_10-30-14.indd 5... - Page 7 • Do not use sandpaper intended for larger sanding pads. Larger sandpaper will extend beyond the sanding pad causing snagging, tearing of the paper or kick- back. Extra paper extending beyond the sanding pad can also cause serious lacerations. DUALTOOLS OS3000 manual_10-30-14.indd 6 10/30/14 2:55 PM...
-
Page 8: Symbols
Warning Indicates a potentially hazardous situation, which, if not avoided may result in serious injury. Caution Indicates a potentially hazardous situation, which, if not avoided may result in minor injury. DUALTOOLS OS3000 manual_10-30-14.indd 7 10/30/14 2:55 PM... -
Page 9: Features
Before attempting to use this tool, familiarize yourself with all operating features and safety rules. Your OS 3000 features dual blades that allow for cleaner cuts, greater stability, and ensures precise control. The variable speed knob (1-6) provides exact speed of oscillation of the accessory you choose for the specific application. - Page 10 FEATURES Dual-Action Accessories The OS 3000 oscillating tool provides better control when using a full range of tool accessories. The dual-action blades offer you more accuracy for precise, clean cuts. With interchangeable accessories, your OS 3000 provides smoother operation, greater stability, and better control.
-
Page 11: Assembly
• Floating washer spacer • Owner’s Manual WARNING! • If any parts are missing or damaged, do not operate the OS 3000 until the missing parts are replaced. Failure to do so could result in serious personal injury. • Do not attempt to modify the 0S 3000 or attempt to adapt accessories not recommended for use with it. - Page 12 AC household current. A voltage drop of more than 10 percent will cause a loss of power and the motor will overheat. If your OS 3000 oscillating tool does not operate when plugged into the outlet, check the power supply.
- Page 13 ASSEMBLY INSTALLING ACCESSORIES The OS 3000 has an integrated accessory quick-change mechanism that allows you to install and remove accessories without the need of a wrench or hex key. The quick-change mechanism eliminates the worry about losing a clamping screw, nut, or washer.
-
Page 14: Operation
Intended Use The OS 3000 is intended for sawing wood, plastic, and soft metals; dry sanding surfaces, corners, and edges; scraping; and removing grout. An assortment of blades comes with the tool so that you can complete a variety of tasks. In... - Page 15 Note: If you are experiencing a strong vibration, it indicates too much pressure on the tool. Back off on the pressure and let the speed of the tool do the work. DUALTOOLS OS3000 manual_10-30-14.indd 14 10/30/14 2:55 PM...
-
Page 16: Maintenance
All of the bearings in this tool are lubricated with a sufficient amount of high grade lubricant for the life of the tool under normal operating conditions. Therefore, no further lubrication is required. DUALTOOLS OS3000 manual_10-30-14.indd 15 10/30/14 2:55 PM... - Page 17 PARTS LIST DUALTOOLS OS3000 manual_10-30-14.indd 16 10/30/14 2:55 PM...
-
Page 18: Parts List
5x30 tapping screw ST4.2x16 screws M4x14 cable clamp quick-release trigger lamp cap cylindrical pin 4x14 chassis cover rubber column (2) quick-release lever switch circuit board quick-release spring rubber column (1) spacer key DUALTOOLS OS3000 manual_10-30-14.indd 17 10/30/14 2:55 PM... -
Page 19: Customer Service
Customer Service at 1-855-382-5729. Be sure to provide all pertinent facts when you call. Also, you can check our website www.dualtools.com for a list of frequently asked questions or e-mail us at customerservice@infusionbrands.com. The model and serial number of this saw will be found on the bottom of the OS3000 housing on the product information decal. - Page 20 While your new DualTools mutil-tool works best with our patented dual blades, you can aways go with a single accessory of your choice. The OS3000 accepts most major brand multi-tool accessories. See the full line of innovative DualTools at: www.DualTools.com...
