Note: The most current version of these instructions can be found online at
WARNING: Important! Read and understand these instructions before assembling the
Versacart. If you do not understand any part of these warnings, cautions or instructions,
contact a healthcare professional for direction in the use of this product.
WARNING: If components are damaged or missing, contact your dealer immediately. DO
NOT use substitute parts. Use only Lumex
parts could cause personal injury and damage to the Versacart.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly or use of this product.
ASSEMBLY
Unpacking
1. Check for any obvious damage to the carton or its contents. If damage is evident, notify the car-
rier or your authorized Graham-Field Dealer.
2. Remove all loose packing from the carton.
3. Carefully remove all the components from the
carton.
Versacart Assembly
1. Position Versacart frame in upright position on
casters as shown at right. It may be necessary to
first pull Versacart lower legs apart so it can stand
upright.
WARNING: Take care not to be pinched by mov-
ing parts while opening Versacart.
2. Open handles and push down on upper and lower
locking bars to secure Versacart frame in open,
locked position as shown at right.
BASKET INSTALLATION
Lower basket: Slide basket between legs onto lower
locking bars. Position basket securely between stops
as shown at lower right.
Upper basket: Position basket on upper locking bars
securely between stops as shown at lower right.
WARNING: Ensure that Versacart and Wire Bas-
kets are assembled as described before use.
OPERATION
WARNING: The Versacart's maximum weight
capacity is 200 lb. Do not exceed this limit.
7010A-INS-LAB-RevA10
7010A: VERSACART FOLDING UTILITY CART AND
7020A / 7021A VERSACART WIRE BASKETS:
ASSEMBLY AND OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
replacement parts. Non-Lumex
®
www.grahamfield.com
upper locking bars
stops
legs
caster
unlocked position
7010A Versacart assembly
7010A Versacart
assembled
replacement
®
handles
folding
frame
lower
locking bars
locked position
7020A Versacart
small wire basket
7021A Versacart
large wire basket
1
