1
Introduction..........................................................1-1
1.1
Unpacking the DA280 .......................................1-1
1.2
Package Checklist ............................................1-2
2
External Appearance of DA280 ..............................2-1
3
Verification ...........................................................3-1
3.1
Unpacking the DA280 .......................................3-1
3.2
Package Checklist ............................................3-1
3.3
Power Supply and Battery Pack..........................3-2
3.4
Running a Power On Self Test ............................3-3
4
User Interface .......................................................4-1
4.1
User Keys .......................................................4-1
4.2
Front Panel Indicators.......................................4-2
4.3
Interface and Menu Management .......................4-3
5
Setup ....................................................................5-1
5.1
Entering Setup Mode ........................................5-1
5.2
Beep Setup .....................................................5-1
5.3
View CPU firmware version................................5-2
5.4
IP Ping Params Setup .......................................5-2
5.5
ADSL Mode Setup ............................................5-2
5.6
Viewing Modem firmware Version .......................5-3
5.7
Loading Default ...............................................5-3
5.8
Pass/Fail function .............................................5-3
Contents
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DADI DA280 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atel Electronics DADI DA280

  • Page 1: Table Of Contents

    Contents Introduction............1-1 Unpacking the DA280 ........1-1 Package Checklist ..........1-2 External Appearance of DA280 ......2-1 Verification ............3-1 Unpacking the DA280 ........3-1 Package Checklist ..........3-1 Power Supply and Battery Pack......3-2 Running a Power On Self Test ......3-3 User Interface ............4-1 User Keys ............4-1 Front Panel Indicators........4-2 Interface and Menu Management .......4-3 Setup ..............5-1...
  • Page 2 ADSL Test .............6-1 Connecting to an ADSL Line ......6-2 ADSL physical layer Test ........6-2 6.2.1 Viewing Test Results ........6-4 6.2.2 Saving Test Results........6-6 6.2.3 Alarm Indicators and Messages ....6-6 ADSL upper layer test........6-7 6.3.1 PPPoE/PPPoA &IP Ping test......6-7 6.3.2 RFC1483 Bridge/Route Static IP Ping test ..6-10 6.3.3 DHCP &...
  • Page 3: Introduction

    1 Introduction The DA280 is a handheld tester, which provides a quick accurate evaluation parameters ADSL /ADSL2/ADSL2+. These parameters include max bit rate, noise margin, power attenuation, and much more. With a four hour rechargeable lithium battery and many applied functions, it is the ideal tester for initial installations, maintenance, and troubleshooting.
  • Page 4 Fully automatic range DMM test function, include Loop resistance test, Capacitance test, Insulation resistance test and AC/DC voltage test. Critical line parameters value limitation setup. 1.2 Key Features Power-up ADSL Acceptance Test. • Auto Synchronize with DSLAM ATU-C. • Verify level of service: bit rates and noise margin. •...
  • Page 5: External Appearance Of Da280

    2 External Appearance of DA280...
  • Page 7: Verification

    3 Verification Verification is necessary before you begin using the DA280 tester. This chapter provides an overview of your tester. Unpack the tester • Accessories checklist • Check the capacity of battery pack • Running a self-test • 3.1 Unpacking the DA280 Check for any damage to the container and packaging, and inspect everything according to the equipment list in Section 2.2.
  • Page 8: Power Supply And Battery Pack

    RJ11 to Alligator cable PS/2 serial cable Cross-over cable Cat5 User manual CD (with StreamViewII-ez) Carrying case 3.3 Power Supply and Battery Pack A 8.4V AC-DC power supply and internal rechargeable lithium battery pack are included with the DA280 tester. The internal rechargeable lithium battery pack will last for four hours after it is fully charged.
  • Page 9: Running A Power On Self Test

    3.4 Running a Power On Self Test DA280 will run a self-test every time the power is turned on. This is done to insure that it is ready to operate properly. Step Operation Explanation Power on Press the button once. The LCD display will start to run initialization and then display the model of tester if self-test passed.
  • Page 10: User Interface

    4 User Interface The DA280 tester is very easy to use. The LCD display will show all of the related information for your operation. To take full advantage of all the features and benefits of the DA280, be sure to read this chapter thoroughly. In this Chapter: User Keys •...
  • Page 11: Front Panel Indicators

    Generally, this key used for moving the cursor up. In upper layer parameters setup, ∧ this key is used for special functions, such as to delete a parameter. This key is used for moving the cursor down. In upper layer parameters setup, this key is ∨...
  • Page 12: Interface And Menu Management

    Type Label Meaning The brighter the LED is the higher Battery Power remaining capacity Indicator lithium battery pack. ¤ : The tester has successfully connected to the Ethernet. ¤ Working : The tester has successfully Indicators connected to the DSLAM. ¤...
  • Page 13 Menu Function ADSL Enter ADSL test status including ADSL Physical Test test and ADSL upper layer test. Record View or delete a record or all records. Setup each test condition, View firmware Setup version, date and time. Execute DMM test, includes loop resistance test, insulation resistance test, AC/DC voltage test Test and capacitance test.
  • Page 14: Setup

    5 Setup There are only a few parameters that need to be configured on the DA280 tester. In this Chapter: Entering Setup Mode • Loading Modem Default • Setup Test Parameters • Adjusting LCD contrast • Changing Date and Time •...
  • Page 15: View Cpu Firmware Version

    5.3 View CPU firmware version Press the ∨ key to choose “2.CPU firmware ver” then press the OK key to view CPU firmware version. 5.4 IP Ping Params Setup There are two parameters in IP Ping Parameters Setup mode: No. of sent means the number of ping packets sent. Packet size means the size of each ping packet.
  • Page 16: Viewing Modem Firmware Version

    5.6 Viewing Modem firmware Version Press the ∨ key to select “5.Modem version” then press the OK key to view modem firmware version. Modem ver: 1104586 5.7 Loading Default Press the ∨ key to select “6.Load default” then press the OK key to Load default configuration of the inside modem.
  • Page 17 ►1. No Pass/Fail 2. Pass/Fail 1 3. Pass/Fail 2 Select option 1, 2 or 3 via ∧ or ∨ key for different Pass/Fail mode. 1. No Pass/Fail: This option means the unit doesn’t do any pass/fail. 2. Pass/Fail 1: This option is letting user set reference values for DSLAM port.
  • Page 18 parameter, using the ∨ key to move to next parameter. The number key 0-9 will be used to input the number, while F1 key is used to save the setting. The Pass/Fail indication will be shown like below if all parameters are passed: Pass/Fail 1 result Pass!...
  • Page 19 UpRate: Pass 512 SNR marg: Pass 6 Attenuat: Pass 40 Capacity: Pass 80% From above first result page, it is easy to find the fail is caused by downstream noise margin and capacity because the reference value for noise margin is 15 and the test value is 13.5 (less than the threshold) and the capacity is 85% and the reference value is 80%.
  • Page 20: Adsl Test

    6 ADSL Test The DA280 tester can perform ADSL physical layer and ADSL upper layer tests including a LAN Ping test. Each test will be explained in detail in this chapter. Testing with the DA280 tester is very easy. After connecting it to the ADSL line, power up the DA280 unit.
  • Page 21: Connecting To An Adsl Line

    6.1 Connecting to an ADSL Line The DA280 operates in terminal testing mode and connects anywhere between the DSLAM and the ATU-R device. This is illustrated in the following figure: 6.2 ADSL physical layer Test After Power On, the DA280 immediately attempts to connect with the Central Office (ATU-C).
  • Page 22 Waiting for Connection... The “DSL” LED indicates the status of the ADSL line. If the LED blinks slowly, this indicates that the unit is “waiting for initialization.” blinks rapidly, this signifies “initializing.” If the LED stays on, this signifies “Showtime.” When the connection is successful, the tester will beep several times, the status will display “Open success!!,”...
  • Page 23: Viewing Test Results

    6.2.1 Viewing Test Results After making the connection with the DSLAM, Press ∧ or ∨ key to view the eight test result pages. Page one and two include parameters such as active bit rate, noise margin, output power, power attenuation, line capacity, max bit rate, etc.
  • Page 24 Page 5–8 indicates defect informations that occurred. Near-end Hist Curt LCD : LCDi: LOM : Near-end Hist Curt LCD : LCDi: LOM : Far-end Hist Curt LOS : LOF : LOP : Far-end Hist Curt LCD : LCDi: LOM : Press F2 key to view bits per tone of the 256(ADSL1/2) /512(ADSL2+) subchannels.
  • Page 25: Saving Test Results

    Ton: 64 F: 276 Bit:06 6.2.2 Saving Test Results Once the DA280 has successfully connected with the ATU-C, press the F1 function key to save the current test results. A message displays “Save to No. xxx, Yes/No?”. If you want to save the testing results, press the OK key; otherwise press the ESC key to cancel the save operation.
  • Page 26: Adsl Upper Layer Test

    6.3 ADSL upper layer test Press the OK key to enter the selection of the upper layer test mode. The menus will be displayed as shown below: 1. PPP Mode 2. Static Mode 3. DHCP Mode 4. Modem Mode You can perform a PPPoE/PPPoA & IP Ping test, RFC1483 Bridge/Route static IP Ping test, DHCP &...
  • Page 27 The parameters you must set are: VPI and VCI MUX encapsulation type: LLC-SNAP/VC-MUX AUTH (authentication): PAP/CHAP UsrN: PPP account name Pswd: PPP password ∨ key to select the parameter you want to set. ∧ key to delete the selected parameter’s value. <...
  • Page 28 If the PPPoE/PPPoA dial-up is successful,the LCD displays is shown below: PPPoE established! Assigned IP: 218.23.102.7 If you need, the ESC key will take you back to the Physical Layer screen and release the assigned IP address. Press F2 key to enter the IP Ping test mode: Assigned IP: 218.23.102.7 Target IP:...
  • Page 29: Rfc1483 Bridge/Route Static Ip Ping Test

    Target IP: 202.108.36.96 Ping OK! Rev Packs: 3 Min Delay: 290 Max Delay: 300 Avg Delay: 295 If IP Ping fails, the LCD will display ”Ping failed!”. Press F2 key to perform the IP Ping again. 6.3.2 RFC1483 Bridge/Route Static IP Ping test Select 2.
  • Page 30 Wan IP: 218.21.65.230 Target IP: 202.108.036.096 The parameters you must set are VPI, VCI, and MUX encapsulation type LLC-SNAP/VC-MUX ) , Gateway, Subnet mask, Wan IP, and Target IP in Static IP Ping test mode. ∨ key to select the parameter you want to set. For VPI and VCI, ∧...
  • Page 31: Dhcp & Ip Ping Test

    Rev Packs: 3 Min Delay: 290 Max Delay: 300 Avg Delay: 295 If IP Ping fails, the LCD will display ”Ping failed!” Target IP: 202.108.36.96 Ping failed! Press F2 key to perform the IP Ping again. 6.3.3 DHCP & IP Ping test Choose 3.DHCP Mode, then press the OK key to start DHCP &...
  • Page 32 have finished the setup. The LCD displays is shown below: DHCP dialing… If the DHCP dial-up is successful,the LCD displays is shown below: DHCP ok! Assigned IP: 218.23.102.7 Gateway:218.23.102.1 Press F2 key to enter the IP Ping test mode: Assigned IP: 218.23.102.7 Target IP: 218.108.36.96...
  • Page 33: Adsl Modem Simulation

    If IP Ping is successful the LCD displays is shown below: Target IP: 218.108.36.96 Ping ok! Rev Packs: 3 Min Delay: 290 Max Delay: 300 Avg Delay: 295 If IP Ping fails, the LCD will display ”Ping failed!”. Press F2 key to perform the IP Ping again. 6.3.4 ADSL Modem Simulation Choose 4.
  • Page 34: Lan Test

    Press F2 key to configure the DA280 as a ADSL Modem. The LCD displays is shown below: ADSL Modem Simulation Mode 6.3.5 LAN Test The LAN test allows the tester to be connected to the LAN as a terminal and Ping the IP address of other LAN ports. This can help discover any connection problems on the LAN.
  • Page 35: Dmm Test

    Local IP: <LAN Test> 192.168.000.200 Target IP: 192.168.000.088 key to select the parameter you want to set. > or > key to select the left or right number. Press F1 key to save as default target IP address. Press F2 key to perform IP Ping test. 6.3.6 DMM Test The DA280 has fully automatic range DMM.
  • Page 36 Test for the insulation resistance and AC/DC voltage: Line From the main menu, move the cursor to “4.DMM Test” and press the OK key to enter the DMM test mode. 1. Resistance 2. Capcitance 3. DC Voltage ▼ 4. AC Voltage ▲...
  • Page 37: Record Management

    7 Record Management The DA280 tester provides nonvolatile storage space.The records can be viewed and deleted. In this Chapter: Entering Record Mode • Viewing Records • Deleting Records • Saving Records to a PC • 7.1 Entering Record Mode From main menu, move the cursor to the “2.Record” menu item and then press the OK key.
  • Page 38: Deleting Records

    7.3 Deleting Records To delete the highlighted record, press the F1 key. The message “Delete No. xx, Yes/No” will display. If you want to delete the test results, press the OK key; otherwise press the ESC key to cancel the delete operation. Delete No.05, Yes/No? 7.4 Clear all records...
  • Page 39: Install Streamviewii-Ez Software

    7.5.1 Install StreamViewII-ez Software Insert the supplied CD and from “My computer”, double-click on “Setup.exe”. When setup is finished, connect the DA280 tester to the computer as shown in the following figure: PS/2 PS/2 Serial Com- munication Cable Serial Port 7.5.2 Start StreamViewII-ez Software Click on the Windows “Start”...
  • Page 40 1. Data Acquisition From the main window, data can be retrieved from the DA280 tester or an existing file. 1) Retrieve data from DA280 NOTE: The ADSL2+ez tester must be in the 2. Record window as blow: ►#01 F1 key to Delete Connect the DA280 handheld tester to a PC by a serial cable.
  • Page 41 record to the PC. All the retrieved records will be displayed in the record list on the left side of the window. The first record will be displayed on the right side of the window. Mouse click each record to view its data. 2) Retrieve data from file Pull down the File menu item and click on “Open”.
  • Page 42 To import records from an existing file, pull down the Edit menu and select an import file when the File Open dialog appears. 2) Export Record To export a record, select a record from the record list, pull down the Edit menu and select an export file name when the File Save dialog appears.
  • Page 43: Appendix A: Quick Start

    Appendix A: Quick start PPPoE dial up and IP Ping test (Non-Static IP): 1-Plug the ADSL line connector into the DA280 RJ11 port. 2-Choose 1. ADSL Test and then press OK key on the main menu. 3-Once the DA280 has successfully connected with the DSLAM, press OK key then choose 1.
  • Page 44 press F2 key then enter the target IP. 7-Press F2 key, it will give the IP Ping results. RFC1483 Bridge Static IP Ping test: 1-Plug the ADSL line connector into the DA280 RJ11 port. 2-Choose 1. ADSL Test and then press OK key on the main menu.
  • Page 45 DHCP dial up and IP Ping test (Non-Static IP): 1-Plug the ADSL line connector into the DA280 RJ11 port. 2-Choose 1. ADSL Test and then press OK key on the main menu. 3-Once the DA280 has successfully connected with the DSLAM, press OK key then choose 3.
  • Page 46 DMM test: 1-Plug the ADSL line connector into the DA280 RJ11 port. 2-Choose 4. DMM Test and then press OK key on the main menu. 3-Select the test mode you want and press the OK key to perform the test.
