Summary of Contents for Langley Street Patterson Dining Set LGLY5352
- Page 1 Assembly Instructions Caution : You must read this before you proceed DINING TABLE Part List Label Picture Description Table Top（pre-attched screw base) Table Leg Table Leg Supporter Table Top Supporter Page 1 of 5...
-
Page 2: Assembly Preparation
Hardware Label Picture Description HEX NUT 5/16" ① SPRING WASHER 5/16" ② FLAT WASHER 5/16" ③ SPANNER 12.8 ④ JCBB M8 x 50mm + S/W 5/16" ⑤ + F/W 5/16" x 22mm ALLEN KEY M4 ⑥ Assembly Preparation Before Beginning Assembly: Page 2 of 5... - Page 3 Assembly Steps Overview Table Top Table Leg Table Table Top Supporter Supporter FRONT FACING This Table has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Table parts, the above picture is to help you put the various parts into perspective.
-
Page 4: Assembly Steps
Assembly Steps Step 2 Place the Table top (A) on a soft surface to avoid any scratches or damages to the product and place the Table Leg with the table supporter onto the of table top support with your adult partner. Fix the Table Top (A) with JCBB Bolt ⑤... -
Page 5: Care And Maintenance
Care & Maintenance Page 5 of 5... -
Page 6: Part List
Assembly Instructions Caution : You must read this before you proceed DINING CHAIR Part List Label Picture Description Chair Back Front Leg Side Stretcher (R) Side Stretcher (L) Side Rail (R) Side Rail (L) Cusion Seat Page 1 of 7... - Page 7 Hardware Label Picture Description JCBC M6 x 50mm + S/W ① M6 + F/W M6 x 13mm ② Allen Key M4 ③ FH Screw #8 x 32mm ④ L Bracket ⑤ CSK Screw M3.5 x 12mm Assembly Preparation Before Beginning Assembly: Page 2 of 7...
- Page 8 Assembly Steps Overview Cushion Seat (G) Chair Back (A) Front Leg (B) Side Stretcher (C) Side Rail (F) Side Rail (E) This Dining Chair has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Dining Chair parts, the above picture is to help you put the various parts into perspective.
- Page 9 Step 2 (2.2) (E) has a small hole for (2.1) identification. (2.1)Place the Side Rail (E) and Side Rail (F) on the Back Frame to. Side Rail (E) has a small hole for identification. (2.2) Then fix the Side Rail (E) and (F) with Screw ③ using Screwdriver (not provided).
- Page 10 Step 4 Place the Cushion Seat (G) on the table and put the chair on it as shown. Then, fix the Cushion Seat (G) with L-Bracket ④ and Screw ③ using Screwdriver (not provided). DO NOT FULLY TIGHTEN THE BOLT AND SCREWS. Step 5 ①...
- Page 11 Place the dining chair on a Level Surface to check if it wobbles. loosen the bolts and lift the dining chair some 30cm to 50cm high from the ground, keep your feet and toes well away from the drop zone, and drop the dining chair freely and vertically with the four legs, hitting the ground at the same time.
- Page 12 Care & Maintenance Page 7 of 7...
