  • Page 1 User Manual One V9 PF1.0 1K/1.5K/2K/3K Online UPS for Rack- and Tower-Systems Version: 1.2...
  • Page 2 ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 3: Table Of Contents

    3-7. Faults Reference Code ..................22 3-8. Warning indicator ..................... 22 4. Troubleshooting ....................23 5. Storage and Maintenance ................... 24 6. Specifications ..................... 25 7. Serviceinformations.................... 27 ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 4: Important Safety Warning

    In order to fully disconnect the UPS system, first press the OFF/Enter button to ⚫ disconnect the mains. Prevent no fluids or other foreign objects from inside of the UPS system. ⚫ ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 5: Maintenance, Service And Faults

    12 V dc, 9.0 Ah UXW360-12/FR 12 V dc, 7.0 Ah CSB Battery Co Ltd GP1272 12 V dc, 7.2 Ah UPS 12460 F2 12 V dc, 9.0 Ah ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 6 ⚫ WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 7: Installation And Setup

    3. AC input 4. Network/Fax/Modem surge protection 5. USB communication port 6. RS-232 communication port 7. SNMP intelligent slot 8. EPO: Emergency power off 9. External battery connection ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 8: Operating Principle

    This UPS can be either displayed on the desk or mounted in the 19” rack chassis. Please choose proper installation to position this UPS. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 9: Setup The Ups

    3. It’s required to maintain maximum altitude of 1000m to keep UPS normal operation at full load UPS. If it’s used in high altitude area, please reduce connected load. Altitude derating power with connected loads for UPS normal operation is listed as below: ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 10 Follow the safety instructions to make external battery connection. Step 2: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 11 EPO function, remove two screws on EPO port and metal plate will be removed. NOTE: The EPO function logic can be set up via LCD setting. Please refer to program 16 in UPS setting for the details. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 12: Battery Replacement (Only For Rt Models)

    UPS and RS-232/USB port of PC. Then, follow below steps to install monitoring software. 1. Insert the included installation CD into CD-ROM (The newest Software, you can download to www.alltronic-net.de) drive and then follow the on-screen instructions to proceed software installation. If there no screen shows 1 minute after inserting the CD, please execute setup.exe file for initiating software installation.

  • Page 13: Battery Kit Assembly (Option For Rt Models)

    Step 4 Cover the other side of plastic shell as below chart. Then, battery kit is assembly well. Put assembled battery packs on one side of plastic shells. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 14 Then, battery kit is assembly well. Battery kit for 4 Batteries (4 BP-CH) Step 1 Step 2 Tapes Tapes Remove adhesive tapes. Connect all battery terminals by following below chart. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 15 Step 4 Put assembled battery packs on one side of Cover the other side of plastic shell as below plastic shells. chart. Then, battery kit is assembly well. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 16: Operations

    If it’s already in top menu, press these two buttons at the same time to exit the setting mode. 3-2. LCD Panel ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 17 Indicates the UPS is working in converter mode. Indicates the output is working. Battery information Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%. Indicates low battery. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 18: Audible Alarm

    Battery Low Over Load Over input current Battery no Connect Over Charge Site wiring fault Temperature Charger Battery fault Bypass out Range Bypass frequency unstable Battery Replace EEPROM Error ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 19: Ups Setting

    BAT 60: presents output frequency is 60Hz If converter mode is enabled, you may choose the following output frequency: CF 50: presents output frequency is 50Hz CF 60: presents output frequency is 60Hz ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 20 230-264: setting the high voltage point in parameter 3 from 230Vac to 264Vac. (Default: 264Vac) For 100/110/115/120/127 VAC models: 120-140: setting the high voltage point in parameter 3 ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 21 Set up backup time limits for programmable outlets. 0-999: setting the backup time limits in minutes from 0-999 for programmable outlets which connect to non-critical devices on battery mode. (Default: 999) ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 22 14: Charger boost voltage setting ⚫ Parameter 1 Parameter 2 Interface Setting Set up the charger boost voltage. 2.25-2.40: setting the charger boost voltage from 2.25 V/cell to 2.40V/cell. (Default: 2.36V/cell) ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 23 280/290/300: setting the high voltage point in parameter 2. (Default: 300Vac) For 100/110/115/120/127 VAC models: 140/145/150: setting the high voltage point in parameter 2. (Default: 150Vac) LLS: Bypass low voltage point ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 24: Operating Mode Description

    UPS is powered off and no output supply power, but still can charge batteries. Fault mode When a fault has occurred, the ERROR icon and the fault code will be displayed. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 25: Faults Reference Code

    Battery replacement Sounding every 2 seconds EEPROM error Sounding every 2 seconds NOTE: “Site Wiring Fault” function can be enabled/disabled via software. Please check software manual for the details. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 26: Troubleshooting

    The UPS shut down Remove excess loads from icon is lighting on LCD automatically because of UPS output and restart it. display. Alarm is continuously overload at the UPS sounding. output. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 27: Storage And Maintenance

    During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C - 40°C Every 3 months 1-2 hours 40°C - 45°C Every 2 months 1-2 hours ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 28: Specifications

    208VAC. For 100/110/115/120/127VAC system, the output power ratings are different based on different input voltage. Please check output power rating table for the details. ** Product specifications are subject to change without further NOTE. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...
  • Page 29 Please check output power rating table for the details. ** Product specifications are subject to change without further NOTE. ALLTRONIC GmbH, Raiffeisenstraße 11, 89438 Holzheim Service-Hotline +49 9075 95 88 3-28...

  • Page 30: Serviceinformations

    7. Serviceinformation You become Service from your Dealer or from ALLTRONIC. Your Way to ALLTRONIC: Headquarter to Germany ALLTRONIC GmbH Raiffeisenstr. 11 D-89438 Holzheim | Germany Telefon: +49 9075 – 95 88 328 Mail: service@alltronic-net.de CostumerCenter: https://portal.alltronic-net.de/portal Helpdesk: https://portal.alltronic-net.de/helpdesk/ FAQ and Wiki: https://portal.alltronic-net.de/helpdesk/FAQList.aspx...
