Genesis Cyclone Maintenance

Cyclone Grinder Pick Replacement

Pick Replacement

The instructions below must be carefully followed. Failure to do so may void the warranty. Contact the Genesis
Service Department for assistance.
Thoroughly clean the Cyclone prior to performing maintenance.
‡
Position the Cyclone so the cutting drums can be easily rotated.
‡
WARNING
!

Disassembly of a Pick with Retaining Ring

Installation and disassembly tools

Wedge
‡
Installation/disassembly tool
‡
Reaming tool
‡
Break up the C-retaining
ring using a hammer. Use
the installation tool for the
securing ring.
WARNING
!

Pick Installation

Before installing a new pick, clean the hole in the pick holder. Slide the
‡
pick into the holder.
Before installing used picks, clean the shank.
‡
Do not use lubricant, grease or oil, when installing the picks.
‡
This document is a quick reference only. It does not replace the product safety and operator's manuals, which must be followed
© 2019 Genesis Attachments, LLC
Crushing hazard - secure the Cyclone to prevent from sliding and falling.
Knock the pick out of the
holder using a hammer and
a reaming tool.
Repeat the process to remove all picks.
Always wear eye protection when performing maintenance.
by all operators and maintenance personnel.
1000 Genesis Drive, Superior, WI 54880
888-SHEAR-IT (743-2748)
GCGPR 8/19 Rev. B
Maintenance
– –
Tel: 715.395.5252 genesisattachments.com
Minute
Loosen any stuck picks by
driving the wedge into the
gap between the pick and
the holder.
