R R Y

Please check contents before assembly. If any items are missing or damaged,

Do not take unit back to store. Call 416-597-2291 for customer sevice and we will save you

the time by correcting the problems directly.

NOTE:

* Read all instructions before starting

* Assemble on rug or cardboard to prevent scratches tothe floor and product.

* To ensure proper assembly we have included the following guides:

Reference this guide when assembling all Locking Bolts .

MPCB006 CAT WASHROOM BENCH

COMPONENTS

HARDWARE

Insert threads of Locking Bolts

completely, and stop once threads

are no longer visible.

Do NOT overturn.

Page 1

Only slight turn of

Cams required.

Do NOT overturn.

Reference this guide when assembling all

Cam Locks

v.1.

Table of Contents

Need help?

Do you have a question about the CAT WASHROOM BENCH MPCB006 and is the answer not in the manual?

Page 1 R R Y MPCB006 CAT WASHROOM BENCH Please check contents before assembly. If any items are missing or damaged, Do not take unit back to store. Call 416-597-2291 for customer sevice and we will save you the time by correcting the problems directly. COMPONENTS HARDWARE NOTE:...
Page 2 STEP 1 Insert 7 Locking bolt (J) and 6 Wooden Dowels (K) into Bottom Board (A2) K - Wooden Dowel (x6) STEP 2 Insert 4 Locking Bolts (J) into side panels (C1, C2) as shown below. (2 on each panel) J - Locking bolt (x4) STEP 3 Insert 4 Wooden Dowels (K) to connect Back Panel (B)
Page 3 STEP 4 With the help of another adult, carefully lower Back Panel B and sides C1 and C2 onto Bottom Board A2. STEP 5 Insert and tighten 11 Cams (I) being careful not to overturn. Apply 11 Covers (L) to installed Cams I - Cam (x11) L - Cover (x11) Only slight turn of...
Page 4 STEP 6 Insert 7 Locking Bolts (J) into Top Panel A1 J - Locking Bolt (x7) STEP 7 Insert 6 Wooden Dowels (K) into Top Panel (A1) and carefully lower onto assembled bench base. Insert 7 Cams (I) and tighten carefully. Place Covers (L) over installed Cams K - Wooden Dowel (x 6) I - Cam (x7)
Page 5 CARE INSTRUCTIONS Thank you for choosing MERRY PRODUCTS’™ PET HOUSES AND PET BEDS. With little care and maintenance, MERRY PRODUCTS’™ PET HOUSES AND PET BEDS will provide your pet with comfort and enjoyment for many years to come! •...
