Alibaba Cloud SAG-100WM Manual

Smart access gateway
Hide thumbs Also See for SAG-100WM:
Table of Contents

Advertisement

Quick Links

Download this manual
Alibaba Cloud
智能接入网关
Smart Access Gateway
Issue: 20200611

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAG-100WM and is the answer not in the manual?

Questions and answers

Related Manuals for Alibaba Cloud SAG-100WM

Summary of Contents for Alibaba Cloud SAG-100WM

  • Page 1 Alibaba Cloud 智能接入网关 Smart Access Gateway Issue: 20200611...

  • Page 2: Legal Disclaimer

    Alibaba Cloud-authorized channels. 4. This document serves only as a reference guide for your use of Alibaba Cloud products and services. Alibaba Cloud provides the document in the context that Alibaba Cloud products and services are provided on an "as is", "with all faults"...
  • Page 3 智能接入网关 Smart Access Gateway /  Legal disclaimer 5. By law, all the contents in Alibaba Cloud documents, including but not limited to pictures, architecture design, page layout, and text description, are intellectual property of Alibaba Cloud and/or its affiliates. This intellectual property includes, but is not limited to, trademark rights, patent rights, copyrights, and trade secrets.
  • Page 4 智能接入网关 Smart Access Gateway /  Legal disclaimer Issue: 20200611...

  • Page 5: Document Conventions

    智能接入网关 Smart Access Gateway /  Document conventions Document conventions Style Description Example A danger notice indicates a Danger: situation that will cause major Resetting will result in the loss of system changes, faults, physical user configuration data. injuries, and other adverse results. A warning notice indicates a Warning: situation that may cause major...
  • Page 6 智能接入网关 Smart Access Gateway /  Document conventions Style Description Example {} or {a|b} This format is used for a required switch {active|stand} value, where only one item can be selected. Issue: 20200611...
  • Page 7 智能接入网关 Smart Access Gateway /  Document conventions Issue: 20200611...

  • Page 8: Table Of Contents

    Document conventions..............I 1 Features of Smart Access Gateway devices....... 1 2 SAG-100WM configurations............. 5 2.1 SAG-100WM overview.................... 5 2.2 Web configurations for SAG-100WM devices............10 3 SAG-1000 usage instructions..........19 3.1 SAG-1000 overview....................19 3.2 Install an SAG-1000 device..................22 3.3 Web configurations for SAG-1000 devices............26...

  • Page 9: Features Of Smart Access Gateway Devices

    Wi-Fi support Local devices √ × connect to Alibaba Cloud through Wi-Fi connections. Static routing Existing private √ √ networks connect to Alibaba Cloud through static routing. OSPF Supports the Open √* √ Shortest Path First ( OSPF) protocol. Issue: 20200611...
  • Page 10 (ZTP) deployment of SAG. Deployment Inline mode New private √ √* modes of networks connect SAG devices to Alibaba Cloud through SAG devices. All traffic is transmitted through SAG devices. One-arm mode Private networks √ √ connect to Alibaba...
  • Page 11 智能接入网关 Smart Access Gateway /  1 Features of Smart Access Gateway devices Feature Function Description SAG-100WM SAG-1000 Supports active and An SAG device uses √ Available standby networks broadband or 4G soon : WAN and 4G networks to access networks the Internet.
  • Page 12 智能接入网关 Smart Access Gateway /  1 Features of Smart Access Gateway devices Feature Function Description SAG-100WM SAG-1000 Link monitoring Notifications are sent √ √ when an SAG device is online. Issue: 20200611...

  • Page 13: Sag-100Wm Configurations

    智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations 2 SAG-100WM configurations 2.1 SAG-100WM overview The SAG-100WM device is designed to connect small branches and outlets to Alibaba Cloud. As a plug-and-play device, SAG-100WM does not require Web configuration. Specifications Property SAG-100WM Specification...
  • Page 14 Smart Access Gateway /  2 SAG-100WM configurations • A power cable Note: If any component is missing or damaged, contact Alibaba Cloud after-sales personnel. Two types of SAG-100WM devices are available. Type 1 (dimensions: 180 mm × 110 mm × 30 mm) •...
  • Page 15 • Side panel • Rear panel Front panel and rear panel The front panel and the rear panel of a Type 1 SAG-100WM device are described as follows: • Front panel: There are five LED indicators on the front panel. LED indicator Description Indicates whether the device communication is normal.
  • Page 16 - Flashing: Data is being transmitted. - Off: The device is powered off. CLOUD Indicates whether the device is connected to Alibaba Cloud. - On: The device is connected to the CEN. - Off: The device is not connected to the CEN.
  • Page 17 The power interface is on the rightmost of the panel. The power supply must be 12 V Note: We recommend that you use the original power cable. Networking mode The SAG-100WM device connects local clients to Alibaba Cloud through inline mode, which means that the network topology is unchanged. Issue: 20200611...

  • Page 18: Web Configurations For Sag-100Wm Devices

    2.2 Web configurations for SAG-100WM devices This topic describes the steps that you must follow to complete Web configurations for SAG-100WM devices. Before you access Alibaba Cloud through Smart Access Gateway (SAG) devices, you must complete Web configurations for the SAG devices.
  • Page 19 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations • Windows client configuration 1. In the lower-right corner, right-click the network connection icon and then click Open Network and Sharing Center. 2. In the left-side panel, click Change Adapter Settings. 3. Right-click the connected network, and then click Properties.
  • Page 20 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations turns on when the network cable is connected), log on by using the first IP address in the first CIDR block configured in the console. For example, if the first CIDR block you specified is 192.168.0.0/16, the Web configuration address is 192.168.0.1.
  • Page 21 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations 4. Select whether to enable SNAT forwarding. If SNAT forwarding is enabled, packets sent to the WAN from the LAN are forwarded by using NAT by default. Select a connection mode: • Dynamic IP: Select this mode to allow access to the Internet by using an IP address allocated by a DHCP server from a router.
  • Page 22 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations Configuration Description Wireless Security If you enable Wi-Fi security, you can set a password. If you disable Wi-Fi security, no password is set and the Wi-Fi can be accessed by any device. Authentication...
  • Page 23 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations Configuration Description Password Set the Wi-Fi password. • Ethernet mode The LAN ports are used for connecting local clients. If you use network cables to connect the LAN ports, select a connection mode: - Dynamic IP address: The IP addresses used by the LAN ports are allocated from the first CIDR block...
  • Page 24 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations If your local clients directly access Alibaba Cloud by using an SAG device as shown in the following figure, use the default configurations. - Static IP address: If the IP address of the local client has been configured through the switch as shown in the following figure, use a static IP address.
  • Page 25 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations To use a static IP address, you must configure the static IP address and routes: ■ Static IP address: the IP address of the SAG device. Note: Issue: 20200611...
  • Page 26 智能接入网关 Smart Access Gateway /  2 SAG-100WM configurations Make sure the static IP address does not conflict with any network connected to the SAG device. ■ If the LAN ports are connected through static IP, you need to add a route to the SAG device and the switch separately.

  • Page 27: Sag-1000 Usage Instructions

    智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions 3 SAG-1000 usage instructions 3.1 SAG-1000 overview The SAG-1000 device is used to connect headquarters and large branches to Alibaba Cloud through one-arm mode. Specifications Property SAG-1000 Casing Metal, matte black, mountable...
  • Page 28 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions Type 1 (size: 250×193×44 mm) • Front panel • Rear panel Type 2 (size: 241×220×44 mm) • Front panel • Rear panel The following is an overview about the components of an SAG-1000 device of the Type 1 category.
  • Page 29 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions • Front panel There is a power LED indicator, an alarm LED indicator, and a cloud connection status LED indicator on the front panel of the SAG device: LED indicator Description Power On: The device is running normally.

  • Page 30: Install An Sag-1000 Device

    Networking mode The SAG-1000 device is connected to the switch through one-arm mode. This means it can connect local clients to Alibaba Cloud without changing the current network topology. 3.2 Install an SAG-1000 device This topic describes how to install an SAG-1000 device. The SAG-1000 device can be installed on a workbench or in a cabinet.
  • Page 31 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions • The workbench is stable and is correctly grounded. • Sufficient spacing is reserved around the SAG-1000 device to ensure good heat dissipation. • No heavy loads are placed on the SAG-1000 device. Install an SAG-1000 device in a cabinet You can install the SAG-1000 device on the cabinet shelf, or attach the device to the cabinet.
  • Page 32 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions Before the installation, you must purchase the installation assemblies from the specified manufacturer. 1. Attach one side of the adapter holder to the SAG-1000 device, as shown in the following figure. 2. Attach the cover to the adapter holder by using screws, as shown in the following figure.
  • Page 33 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions 3. Attach the other side of the adapter holder to the SAG-1000 device, as shown in the following figure. 4. Use screws to attach the SAG-1000 device to the cabinet horizontally. Issue: 20200611...

  • Page 34: Web Configurations For Sag-1000 Devices

    3.3 Web configurations for SAG-1000 devices This topic describes the steps that you must follow to complete Web configurations for SAG-1000 devices. Before you access Alibaba Cloud through Smart Access Gateway (SAG) devices, you must complete Web configurations for the SAG devices.
  • Page 35 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions addresses, for example, 192.168.0.99. You do not need to configure the gateway and DNS. 6. Click OK. • Mac client configuration 1. On the desktop, click the System Preferences icon, and then click Network in the Internet and Network section.
  • Page 36 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions IP addresses, for example, 192.168.0.99. You do not need to configure the router and DNS. Step 2: Set the password upon your first logon After you power on the SAG device for the first time, you must go to the Web console and set a logon password.
  • Page 37 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions 2. Configure the service IP address and management IP address according to the following information, and then click OK. Configuration Description Configure Service The service IP address is used to establish the VPN tunnel. Notice: Make sure that the specified service IP address can access the Internet.
  • Page 38 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions Configuration Description Next Hop: If you choose to isolate the service port from the management port, specify the next hop of the management port. Step 4: Configure ports and routes There are six ports on an SAG-1000 device. Port 0 and Port 1 are SFP optical ports, and Port 2 to Port 5 are RJ45 electrical ports.
  • Page 39 智能接入网关 Smart Access Gateway /  3 SAG-1000 usage instructions 2. Configure the ports of the SAG device according to the following information, and then click OK. Configuration Description Connection Type Select whether to access the switch by using static routes or dynamic routes.
