Bromley Ghost Hunter Operation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
WARNING
Be sure to read this Operation Manual before use.
Bromley Incorporated in conjunction with Universal Space.
420-Crossen Avenue
Elk Grove IL 60007
847-427-0639 Service Dept.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ghost Hunter and is the answer not in the manual?

Questions and answers

Summary of Contents for Bromley Ghost Hunter

  • Page 1 WARNING Be sure to read this Operation Manual before use. Bromley Incorporated in conjunction with Universal Space. 420-Crossen Avenue Elk Grove IL 60007 847-427-0639 Service Dept.
  • Page 2 1．Specifications (1) Rated power supply :AC 110V±5% 60Hz or :AC 220V±5% 50Hz; (Note: As the actual voltage, please refer the label of the machine.) (2) Power Consumption :Min power consumption：250W； :Max power consumption：300W； (3) Dimensions :W2.49×D5.06×H6.68(inch)； (4) Weight :441lbs； 2.49 6.68 5.06 Note: Game parameters are subject change without notice.

  • Page 3: Package Contents

    2 Package Contents (1) Body Assembly: 1 unit (2) Accessories： When transporting the machine, make sure that the following parts are supplied: No. Part Number Component Specification Illustration Note G101-401-000 Power cord 1．5m 6A For G101-402-000 Fuse φ5-20mm 110V G101-403-000 2222 Keys G101-404-000...
  • Page 4 Synchronous G101-414-000 670XL×8 Belt 16 G101-415-000 Fire 1set 17 G101-702-000 Score Sticker With magnetic 1set 18 G101-101-000 Trip Spring 19 G101-102-000 Spring 20 G101-103-000 Trigger Spring 21 G101-104-000 Limit Spring 22 G101-301-000 L-Wrench...
  • Page 5 (3) The following parts you can oder if you need for it: Parts No. Component Specification Illustration Note 12/20W G101-405-000 Fire Ghost light Yellow(Big) 12V/20W G101-406-000 Fire Spotlight White(small) Console 12V/1W(White G101-407-000 Spotlight G101-408-000 LED spotlight G101-409-000 Sensor YENOX NO Micro-SW Epecially G101-410-000...
  • Page 6 G101-103-000 Trigger Spring Limit Spring G101-104-000 G101-416-000 Transformer DK2-60VA G101-417-000 Elentromagnet G101-418-000 G101-001-000 Gun Ogran Assy G101-002-000 Gun Cover Gun Hold G101-003-000 G101-004-000 Bridge Assy Wheel Ghost G101-005-000 Assy Gargoyle Target G101-006-000 Assy Boss Target G101-007-000 Assy Fire Trarget G101-008-000 Assy...

  • Page 7: Maintenance Zone

    3. Installation WARNING ● For indoor use only! 3.1 Play Zone Space for Operation and Maintenance This machine requires space for playing the game(play zone) and for maintenance( maintenance zone) as shown below. Also for maintenance. Be sure to leave enough space when installing the machine. Maintenance Zone Play...
  • Page 8 3.2 Locations to avoid installing: WARNING This machine is designed for indoor only. Never install this machine outdoor or at any of the following: ● Locations exposed to direct sunlight. ● Locations subjected to rain or water leakage. ● Damp、dust or hot places. ●...
  • Page 9 3. Hold the machine in the specified position on the sides of the Main Assy and lift the machine. While keeping its balance, carry the machine. 4. This machine must be carried by 6 or more persons. 4.2 Transport WARNING ・Be careful not to damage the machine during transport.
  • Page 10 When transporting this machine, must use bubble wrap cove on the machine, care for the Playfield glass, sand or other hard substances may scratch the surface. Avoid to crack up the machine, please set down the lever adjustor while in packing. NOTICE ●...
  • Page 11 5.2 The Power socket: This power socket is fixed to the underside of the machine Assy. 1. This machine’s supply voltage is 110V±5% 60Hz, or 220V±5% 50Hz”, for actual supply voltage, please refer the label of the machine. 2. Fuse specifications 110V 60Hz use 110V 6Aφ5-20mm 220V 50Hz use 220V 3Aφ5-20mm.
  • Page 12 1. The Signboard The Display panel 3. The Playfield 4. The coin shooter 5. The front door The machine cabinet: It is manufactured with wood, and get some stickers on. 6.2 The Components of each part: 1. The Signboard: It is manufactured with fiberglass, colors on, it made the machine more vitality.

  • Page 13: The Display Panel

    When transport the machine, make sure to used the bubble-bubble wrap to protect, Sand or other hard substances may scratch the surface of it. 2. The Display Panel: 1. Castle Windows: There have lights on the back to lighted on the windows.
  • Page 14 hand to let the wheel rotate, at the same time to lay down the bridge which on the front of the boss, so that the player can challenge with the boss. At true, it is also a adorning of the game. It make the game more reality. 3.The Bonus LED: It shows the value of the bonus.
  • Page 15 1. Fire Ghost Target: This is the target for player to shoot on, it will be moved side to side, stop at a side while it has been shot, it is high-difficulty targetsof the game, so the player should take highly skill on shooting it to get more score.
  • Page 16 front has been shot, fully lay down while three targets all been shot. Shoot at the boss target while the bridge fully lay down as soon as you can, shoot on the Boss target you can get the Bonus prize. Or the bridge will be rise up in a interval, then you miss the chance.
  • Page 17 to used, as the adjusting method as following:...

  • Page 18: Front Door

    2. Front Door: Open it to install tickets r reclaim coins. 1). Speaker: Play out sounds on the game. 2). Ticket Dispenser: Pay out tickets that the player got. 3). Lock: Unlock it to replace the tickets, reclaim coins, and also can check or maintenance the machine.
  • Page 19 8.Adjustments ① Bonus Value: Adjust it to setting the Bonus Value of this game. There are 4 options for user to select. It is controlled by SW 11～12. Bonus Options SW11 SW12 Note Value Bonus value is 100 SW11 Bonus value is 200 ～...
  • Page 20 Bonus Options SW15 SW16 Note Time 20s for player to shoot on the boss target 30s for player to shoot on the SW15 boss target ～ 40s for player to shoot on the SW16 boss target 60s for player to shoot on the boss target ④...
  • Page 21 ⑥ The score for right Ghost: Setting it to confirm that how many score the player can get by hitting on the left ghost which seat on the playfield. It is controlled by SW23～SW24. Ghost-R Options SW23 SW24 Note score 20 score in hitting on the right ghost target.

  • Page 22: Error Indication

    controlled by SW27-SW28. Mercy Optio SW27 SW28 Note ticket No mercy ticket Player can get 1 ticket whether he SW27～ hit no target SW28 Player can get 2 ticket whether he hit no target Player can get 3 ticket whether he hit no target ※...
  • Page 23 1. Tilted Warning SW is on the “NC” state. 1. Repair or replace the Tilted 2. IC-U1 on the mainPCB was burnout. Warning SW. 3. The filter capacitance on the mainPCB 2. Replace a new IC. was burnout. 3. Replace a new capacitance. 1.
  • Page 24 The way to find out the Error: 1. Press the “Test button” on the MainPCB in three times. 2. The LEDs will display the error code. 3. Unplug the J011 connector on the MainPCB, If the error code disappear, it means the switch of this part was work out or the ciucuit was open;...

  • Page 25: The Test Button

    8.2 The Test Button Coin Counter Ticket Counter Ticket Reset 1 Coin counter 2 Ticket counter 3 Volume Control: Control the volume of the play music. 4 Ticket Reset: If the game experiences a ticket jam the game will hold the value of tickets owed and display them in the Bonus window, After the jam is cleared and the reset button is pressed the game will resume the ticket payout.
  • Page 26 9. The plane figure of main-board LED CS1 AC 110V LED CS2 LED 1 LED 2 OUT 37-40 LED CS3 LED CS4 LED 3 LED 4 IN 1-40 OUT 33-36 PLAY C8E OUT 25-32 RESET OUT 17-24 OUT 9-16 TEST OUT1-8 IN 41-80 MUSIC OUT...

  • Page 27: Maintenance And Inspections

    Maintenance and inspections Safty Check Be sure to check the following before operating the machine to prevent prevent accident or injury. (1). The warning labels clearly visible? (2). All the level adjusters fixed firmly? (3). Any foreign substance stuck in the gun? Functional Check (1).
  • Page 28 11. Cleaning: Run and check the machine before beginning service every day. (1). Use a vacuum cleaner to clean the inner of the machine. (2). When the machine’s surface is cover with dust, Wipe off dirt gently with a soft cloth. (3).
  • Page 29 12. Drawing 12-1 Overall...
  • Page 30 12-1 Overall Part No. Name Spec. Note G101-601-000 Fiberglass head G101-602-000 Ghost window Clear acrylic G101-419-000 Ghost light Φ3 red G101-603-000 Castle window Acrylic G101-703-000 Upper side graphic G101-604-000 Glass Clear G101-105-000 Glass bracket Q235-A G101-704-000 Bottom side graphic G101-705-000 Front door graphic G101-706-000 Front bottom graphic G101-420-000 Fire light Φ10Blue...
  • Page 31 12-2 The Coin Shooter:...
  • Page 32 12-2 The Coin Shooter Part No Name Spec. Note G101-103-000 Torsion spring 65SiMnA G101-108-000 Shaft sleeve 1 G101-109-000 Fix bracket G101-110-000 Position bracket G101-111-000 Position shaft Stainless steel G101-112-000 Top shaft Stainless steel G101-113-000 Main frame G101-114-000 Bottom shaft Stainless steel G101-115-000 Bottom fix shaft Stainless steel...
  • Page 33 12-3 The Fire Target: 12-3 The Fire Target: Part No Name Specification Note G101-608-000 Fire Target Clear acrylic G101-609-000 Spotlight Cover Clear acrylic G101-405-000 Spotlight 12V/20W G101-135-000 Fire Target Bracket Stainless steel G101-610-000 Bumper Rubber Black G101-136-000 Auxiliary Wheel Bracket Stainless steel G101-424-000 Linear Bearing with base LY-12 31mm...
  • Page 34 12-4 The Bridge Assy:...
  • Page 35 12-3 The Bridge Assy: Part No. Name Specification Note G101-418-000 Electromagnet TAU-1264 G101-141-000 Electromagnet Bracket Stainless steel G101-142-000 Bridge Assy bracket Stainless steel G101-143-000 Bearing Bracket Stainless steel G101-144-000 Rack Bracket Stainless steel G101-429-000 Bearing φ8 G101-145-000 Rack G101-146-000 Chain Wheel G101-147-000 Big Gear Wheel 10 G101-148-000 Shaft Stainless steel...
  • Page 36 12-4 The Castle Ghost Organ: 12-4 The Castle Ghost Organ: Part No. Name Specification Note G101-433-000 Motor TS03-347 15rmp G101-158-000 Motor Bracket Stainless steel G101-159-000 Ghost Support Stainless steel G101-160-000 Ghost Arm1 Stainless steel G101-161-000 Ghost Arm 2 G101-434-000 Joint bearing S110E G101-162-000 Wheel Q235-A...
  • Page 37 12-5 The Playfield:...
  • Page 38 12-5 The Playfield: Part.No Name Specification Note 1 G101-006-000 Ghost assembly 2 G101-614-000 Playfield Acrylic 3 G101-615-000 Playfield protected board Acrylic 4 G101-501-000 Wood Installation Board 5 G101-160-000 Fixed Board Q235-A 6 G101-161-000 Pitman Shaft Base (Up) Q235-A 7 G101-162-000 Shaft C Stainless steel 8 G101-163-000 Crank Stainless steel...
  • Page 39 12-6 Ghost Assembly Part No. Name Spec. Note G101-177-000 Motor fix bracket Stainless steel G101-178-000 Motor bracket Stainless steel G101-179-000 Connecting bar A Bronze G101-180-000 Eccentricity wheel Q235 G101-181-000 Sensor fix block Stainless steel G101-182-000 Connecting bar B Brass G101-183-000 Ghost bracket Stainless steel G101-616-000 Ghost Nylon...
  • Page 40 (3). Once the coin(s) that inserted is reach to 200. 12-7. Electronic part:...
  • Page 41 Part No. Name Spec. Note G101-437-000 BONUS Display LED23B3 G101-438-000 SCORE Display LED23B4 G101-439-000 Eye light Φ8 Blue S-150-12 G101-440-000 Power supply （12V/12.5A） G101-441-000 silicon controlled board JJJ14D G101-801-000 Main PCB PLAYC8F G101-802-000 Music board SY MUSIC01 G101-803-000 Dip SW board DIP08.PCB G101-804-000 Motor drive board M415-64V2.0B...
