- Page 1 User Manual 505U-K Radio Telemetry Module for 505K-2-E, -B, refer to separate User Manual ELPRO Technologies Pty Ltd, 9/12 Billabong Street, Stafford Q 4053, Australia. Tel: +61 7 33524533 Fax: +61 7 33524577 Email: sales@elpro.com.au Web: www.elpro.com.au...
- Page 2 505U-K Radio Telemetry Module Thank you for your selection of the 505U-K module for your telemetry needs. We trust it will give you many years of valuable service. ATTENTION! Incorrect termination of supply wires may cause internal damage and will void warranty.
- Page 3 User Manual WARNING For 505K modules, a radio licence is not required in most countries, provided the module is installed using the antenna and equipment configuration permitted. Check with your local 505U distributor for further information on regulations. For 505U modules, operation is authorised by the radio frequency regulatory authority in your country on a non-protection basis.
-
Page 4: Table Of Contents
505U-K Radio Telemetry Module 505U-K Radio Telemetry Module USER MANUAL OVERVIEW ------------------------------------------------------------------------------------------ 6 ....................6 NPUT IGNALS ....................7 OWER UPPLY ..................7 ADIO RANSMITTER ....................7 ONFIGURATION OPERATION ---------------------------------------------------------------------------------------- 9 ..................9 ORMAL PERATION ? ........9 HAT INFORMATION IS TRANSMITTED OVER THE RADIO ? ........ - Page 5 User Manual 3.5.2 Shaft Encoder Connections..............29 3.5.3 Analogue input ..................29 3.5.4 RS232 serial port..................30 CONFIGURATION------------------------------------------------------------------------------- 32 I/O M ....................33 APPING ................. 34 PDATE RANSMISSION IMES ....................34 IGITAL NPUTS .................... 35 NALOGUE NPUT ..................36 NALOGUE ETPOINTS ...................
-
Page 6: Overview
Note: Please refer to the separate 505U-2 User Manual for the 505U-2-E and 505U-2-B products. The 505U-K product will be referred to as the “505K” for the rest of this manual to clearly delineate it from the other 505U products. -
Page 7: Power Supply
User Manual Analogue continuously variable signals (0-20mA, 4-20mA, 0-10mA, 0-10V) Examples: measured tank level, measured process temperature Some internal signals may also be transmitted to outputs in the network: • Setpoint Status (digital signal set or reset depending upon the value of the analogue signal compared to a high and a low setpoint value configured in the 505K) •... - Page 8 505U-K Radio Telemetry Module 505K configuration software is required and is provided with each order. Configuring a module requires the entering of “input mappings” and setting operating parameters for each input. An “input mapping” links an input signal to an output channel at a remote module (or a “destination address”).
-
Page 9: Operation
User Manual 2 OPERATION 2.1 Normal Operation Once configured using the 505K configuration software, the 505K module will normally be in “sleep” mode to conserve power. During sleep mode, the microprocessor controller powers down, and the analogue loop supply is turned off. The microprocessor will automatically “wake up”... -
Page 10: Inputs
505U-K Radio Telemetry Module this. Depending on the type of input signal (digital, pulse or analogue), the 505K must determine what type of signal change is required to send a transmission: 2.4 Inputs 2.4.1 Digital Inputs A digital input can be an external digital input or an internal status input (setpoint status or low voltage alarm). - Page 11 User Manual count. In addition, an update transmission of the pulse count will be transmitted if the pulse count has not been transmitted for the update time. If an update time of zero is selected, then no update messages will be sent. The maximum pulse input is: 300Hz for contact or NPN inputs (1 msec minimum on-time and off-time), or 10KHz (30 µsec minimum on-time and off-time) for TTL inputs.
-
Page 12: Shaft Encoder Inputs
505U-K Radio Telemetry Module • After each transmission, another transmission for that input is disabled for the paralysis time (0 – 127.5 sec). • PI2 can be scaled by a configurable divider. The diagnostics functions of the 505K allow the user to manually set the counter values to any value (refer section 5 of this manual). -
Page 13: Analogue Inputs
User Manual pulse inputs are used, then 0% analogue signal will correspond to zero pulse rate (0Hz). The pulse rates are treated as analogue inputs and follow the rules for an analogue input as described below. 2.4.5 Analogue Inputs The analogue input can measure from 0 – 24mA or 0 – 10VDC. Current or voltage input can be selected by an internal selector (refer Installation section of this manual). -
Page 14: Setpoint Status
505U-K Radio Telemetry Module to sleep mode. The loop voltage available for a transducer is approx. 24VDC. If the warm-up time is set to the same or more than the sample time, then the analogue loop will be on continuously, and the 505K will measure the signal based on the sample time. For example, if the sample time is 10 seconds, and the warm-up time 20 seconds, then the analogue loop will be continuously active and a measurement made every 10 secs. -
Page 15: Supply Voltage
User Manual value. The high setpoint percentage must always be greater than, or equal to, the low set point. The internal setpoint status will be determined every time an analogue measurement is taken. The setpoint status is treated as a digital signal and its value is transmitted according to the rules for a digital input. -
Page 16: How To Design A Remote Monitoring System
505U-K Radio Telemetry Module consecutive update messages - it is possible to miss one update message because of random noise, but two consecutive failures means that there is a system failure. For example, if you wish to have a failure alarm within 10 minutes of a system failure, set the output reset time at the 105U to 10 minutes and the update time at the 505K to 4.5... -
Page 17: How Far Will The Radio Transmit
User Manual Probability of successful transm ission 100% T ransmissions per message 10 % 1000 2000 3000 M essages Per Hour This assumes that the radio path is reliable and that there is no other radio users on this radio channel. -
Page 18: Calculating Power Consumption
505U-K Radio Telemetry Module Calculating Power Consumption The following information may be used for calculating power consumption. Voltage Supply BU-5 Battery ∆ volts (6 – 30) Pack mAHr Quiescent constant regardless of voltage 0.14 3.4 per day Each radio Transmission time 42msec 0.005... - Page 19 User Manual No. of “off” update messages per year 364 (approximately) No. of “on” update messages per year 2 (twice per year) * 16 (4 hours @ 15 min update) Total messages for digital input 4 + 364 + 32 Pulse input Update time 1 day...
- Page 20 505U-K Radio Telemetry Module Total power consumption per year = 15 + 526 + 0 + 1241 1782 mAHr Expected battery life is 1700/1782 = 0.95 year Note that battery life is shortened during configuration or diagnostics. When the serial cable...
-
Page 21: Hardware Installation
User Manual 3 HARDWARE INSTALLATION WARNING! 110/220/240V mains power must NOT be connected to any input terminal of the 505K module! The 505K module is housed in a weatherproof enclosure with external power and input signals connected via a weatherproof connector at the bottom of the module. Wires of up to 0.75 sqmm may be connected by soldering to the female connector supplied with the unit. -
Page 22: Antenna Installation
505U-K Radio Telemetry Module lug in the mounting screw connection and secure the other end of the wire to a good earth. 3.2 Antenna Installation The 505K module will operate reliably up to 5km. The distance that may be reliably achieved will vary with each application - depending on the type and location of antennas, the degree of radio interference, and obstructions (such as hills or trees) to the radio path. -
Page 23: Dipole Antenna
User Manual the cable loss. For example, a 3 element Yagi with 10 metres of Cellfoil cable has a net gain of 2dB (5dB – 3dB). Connections between the antenna and coaxial cable should be carefully taped to prevent ingress of moisture. Moisture ingress in the coaxial cable is a common cause for problems with radio systems, as it greatly increases the radio losses. -
Page 24: Yagi Antenna
505U-K Radio Telemetry Module Dipole antennas should be mounted vertically, at least 1 metre away from a wall or mast for maximum performance. 3.2.2 Yagi antenna. Yagi antennas are directional. That is, they have positive gain to the front of the antenna, but negative gain in other directions. -
Page 25: Collinear Antenna
ANALOGUE ANALOGUE IN - LOOP SUPPLY 505U-K NOTE: VIEW FROM SOLDER CONNECTION SIDE OF PLUG External supply connection is not required when using the BU-5 battery pack. For additional protection, we recommend that the plug is wrapped with waterproofing tape. -
Page 26: Pl1-K Plug Lead
505U-K Radio Telemetry Module 3.3.1 PL1-K Plug Lead The PL1-K plug lead assembly is a 1 metre cable pre-terminated to the connector plug. The connector connections are: Supply voltage + Blue DIN1 Green DIN2 Yellow Analog loop supply White AIN + Black AIN –... -
Page 27: Power Supply
User Manual 3.4 Power Supply 3.4.1 Battery Pack BU-5 The BU-5 can be installed underneath the 505K or beside it. The BU-5 uses the same type of enclosure as the 505K and is mounted in the same way. The BU-5 has a “cable tail” which plugs into the 505K. The input wiring is then connected to a socket on the BU-5. -
Page 28: External Power
505U-K Radio Telemetry Module typically -10 to 50 degC. Special “industrial” batteries, such as Eveready EN91, have a wider temperature range, -30 to 55 degC. Operation of the 505K will stop during battery change, however configuration of the module will not be lost when batteries are removed, so no special procedure is required when changing batteries. -
Page 29: Shaft Encoder Connections
TTL voltage signal (ON < 1.5 volt DC, OFF > 3.5 volts DC). DIN1 ⊂ DIN2 ⊂ 505U-K ⊂ Inputs can be voltage free contact or open-collector transistor Inputs do not have any surge protection. If the sensor or switch is mounted a long way from the 505K module, external isolation such as a relay may be required for surge protection. -
Page 30: Rs232 Serial Port
505U-K Radio Telemetry Module electrical noise environments, or if the analogue signal cable runs for a long distance underground before connecting to the 505K module. Voltage Input Voltage inputs are connected to the AI+ and AI- connections. The maximum voltage signal ⊂... - Page 31 User Manual Communication is via standard RS-232 signals. The 505K is configured as DCE equipment with the pinout detailed below. Name Dirn Function Not Used. Receive Data - Serial Data Output (High = 0, Low = 1) Transmit Data - Serial Data Input (High = 0, Low = 1) Data Terminal Ready - used by 505K as a "wake-up"...
-
Page 32: Configuration
505U-K Radio Telemetry Module 4 CONFIGURATION The 505K module is configured by creating a configuration file on a PC and downloading to the 505K via the RS232 serial port. You will require the configuration software, and a serial cable - refer to the previous section for details on the cable. -
Page 33: I/O Mapping
User Manual 4.1 I/O Mapping Enter I/O mappings as DIN1 DO1 (DIN1 from #14) 505U per the 105U manual. 105U AO2 (AIN from #14) following example, a digital input at a 505K is mapped to DO1 of 105U#13. The DO3 (SP inv from #14) analogue input of the 105U AO1 (AIN from #14) -
Page 34: Update Transmission Times
505U-K Radio Telemetry Module 4.2 Update Transmission Times Each input signal has an update time. If a change has not occurred for this input within this time, then a transmission is set for this input after the update time has expired. Each input... -
Page 35: Analogue Input
User Manual A paralysis time is useful in large systems when a lot of inputs can change at the same time. Once a 505K has transmitted a message, it cannot transmit another message during the paralysis time - this is to prevent overcrowding of the radio channel. An example could be a system monitoring environmental alarms. -
Page 36: Analogue Setpoints
505U-K Radio Telemetry Module time. If the sample time is zero, then a measurement will be taken every 0.5 sec. The analogue loop supply will be always on, so this situation is not suitable for a battery power supply. Consider the above example, with 505K #14. -
Page 37: Supply Voltage
User Manual than the high setpoint, then the setpoint status is "off". When the input is between the low and high setpoints, then the setpoint status remains unchanged. The setpoint values may be set between 0 and 100% of the calibrated range. The low setpoint may be set to the same value as the high setpoint, however the low setpoint should not be set to a higher value than the high setpoint. -
Page 38: Pulse Inputs
505U-K Radio Telemetry Module 4.7 Pulse Inputs Each 505K has two pulse inputs. Each pulse input has 2 x 16 bit counters and a calculated pulse rate value. The 2 x 16 bit counters are a base counter which increments on each pulse, and an “HI”... - Page 39 User Manual Example 1: A turbine meter is connected to a 505K with a pulse signal of 15 pulses per 100 litres. The normal flow rate is 300 l/sec - that is, the normal pulse signal is 45Hz (15/100x300). Each Kilolitre (Kl) corresponds to 150 pulses.
- Page 40 505U-K Radio Telemetry Module Example 2: A system of tipping bucket raingauges is installed to monitor rainfall in a catchment area. Each raingauge provides a pulse signal to a 505K - each pulse represents 0.2mm of rain. The user wants a transmission at each pulse. During dry periods or periods of light rain, the...
-
Page 41: Manually Setting Counter Values
User Manual 4.7.1 Manually Setting Counter Values The values in the counters can be manually set to any value - refer to section 5.3.2 of this manual. 4.7.2 Shaft Encoder Inputs If the pulse inputs are connected to a shaft encoder (incremental or quadrature types), then the Shaft Encoder Inputs option should be selected. -
Page 42: Number Of Transmissions
505U-K Radio Telemetry Module value. For example, if the normal pulse rate is 35Hz, you may decide that the maximum signal should be 50Hz. The 505K will then transmit 100% value at 50Hz. The maximum pulse rate can be configured from 0.02 Hz to 1000Hz. -
Page 43: Print Options
User Manual system address and unit address. We suggest that you first view the system address and unit address - you can do this via the “Unit Options” menu. Note these addresses before loading the configuration. When you upload the configuration, the program will check if you want to load the addresses from the module. -
Page 44: Diagnostics And Testing
505U-K Radio Telemetry Module 5 DIAGNOSTICS AND TESTING 5.1 System Problems Most problems relate to incorrect configuration, or radio path problems. Before installing the 505K module, "bench-test" its operation with the receiving 905U module alongside. If the 505K does not work properly in this test, it will not work properly installed. If problems are found, check the configuration. -
Page 45: Read Inputs
User Manual 5.3.1 Read Inputs This option provides a display of the measured input signals in the505K, both internal and external. Digital inputs (internal and external) are displayed as "ON" or "OFF", the pulse input accumulated count values are displayed and the analogue input value is displayed in mA or V. -
Page 46: Calibrating Analog Input
505U-K Radio Telemetry Module value required. Then select the green “ ” box beside counter #2. The new values will be written into the module. 5.3.3 Calibrating Analog Input The 505K will be calibrated for a 4-20mA signal in the factory. You can calibrate for a different input signal. -
Page 47: Tone Reversals
User Manual only be as accurate as the calibration. For high accuracy measurement, you will need to use a high accuracy mA or V meter to ensure that the high and low values are correct. If you wish to return to the factory-calibration, select “4-20mA” at the AIN Range Selection display, then “Clear Calibration”... -
Page 48: Specifications
505U-K Radio Telemetry Module 6 SPECIFICATIONS General EMC approval EN 300 683 89/336/EEC AS 3548 Radio approval EN-300-220 Housing 160 x 64 x 36mm Industrial-grade painted aluminium IP66 I/O & Power Connection Weatherproof bayonet Suitable for 0.75 mm conductors connector... - Page 49 User Manual modules as repeaters, Antenna Connector Female SMA coaxial Serial Ports RS232 Port DB9 female DCE 9600 baud, no parity, 8 data bits, 1 stop bit Inputs Digital/Pulse Inputs 2 inputs Suitable for voltage free contacts, NPN transistor or TTL signal Pulse Inputs Transmitted as 2 x 16 bit Share digital inputs.
-
Page 50: Warranty
505U-K Radio Telemetry Module 7 WARRANTY We are pleased that you have purchased this product. ELPRO products are warranted to be free from manufacturing defects for a period of 2 years from the effective date of purchase. The effective date of purchase is decided solely by ELPRO Technologies.
