SGM SYNTHESIS WASH 700 User Manual

SGM SYNTHESIS WASH 700 User Manual

Professional moving head
Hide thumbs Also See for SYNTHESIS WASH 700:
Table of Contents

Advertisement

Quick Links

Download this manual
S Y N T H E S I S
W A S H 7 0 0
P R O F E S S I O N A L
M O V I N G
H E A D
GB
I
D
F
E
P
www.audiovias.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYNTHESIS WASH 700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SGM SYNTHESIS WASH 700

Summary of Contents for SGM SYNTHESIS WASH 700

  • Page 1 S Y N T H E S I S W A S H 7 0 0 P R O F E S S I O N A L M O V I N G H E A D www.audiovias.com...
  • Page 2 Nell’ottica di qualità SGM, è possibile che l’Azienda apporti migliorie ai suoi prodotti, per cui consigliamo di alle- gare il manuale al prodotto stesso e di trascrivere il numero di serie nell’ultima pagina della copertina: utilizzando il presente manuale con un apparecchio fabbricato prima o dopo la sua stampa, potrebbero esserci discrepanze fra l’apparecchio e quanto riportato nel Manuel stesso.

  • Page 3: Table Of Contents

    SGM Technology for Lighting Sommario ..................... 2 YMBOLS ..................2 CHANGES TO THIS MANUAL ....................3 GENERAL WARNINGS ................4 GENERAL WARRANTY CONDITIONS ........................5 NTRODUCTION 1.1 M ..........................5 EATURES ...................................5 ..................................5 FFECTS .................................5 OVEMENT ..............................5 LECTRONIC BALLAST ..................................6 PTIC ............................6...

  • Page 4: Symbols Used

    SURFACE TO BE LIT MUST BE NO LESS THAN 1.5 METRES. Changes to this manual SGM has an on-going product development policy, so the information printed in this manual may not be completely up to date. If any doubts arise regarding the topics covered in this manual or should any further help be required, our online services (internet-server www.sgm.it ) are available 24 hours a day.

  • Page 5: General Warnings

    THIS UNIT IS NOT FOR HOME USE, ONLY PROFESSIONAL APPLICATIONS AFTER HAVING REMOVED THE PACKAGING, CHECK THAT THE FIXTURE IS NOT DAMAGED IN ANY WAY.IF IN DOUBT, DON'T USE IT AND CONTACT AN AUTHORIZED SGM TECHNICAL SERVICE CENTRE. PACKAGING MATERIAL (PLASTIC BAGS, POLYSTYRENE FOAM, NAILS, ETC.) MUST NOT BE LEFT WITHIN CHILDREN'S REACH, AS IT CAN BE DANGEROUS.

  • Page 6: General Warranty Conditions

    Your supplier can give details of local arrangements for the disposal of SGM products. Protect the environment: don't throw packing material into your garbage can return it to your SGM retailer or take it to the nearest special waste collection point. www.audiovias.com - 4 - User’s Manual 1.00...

  • Page 7: Introduction

    NTRODUCTION 1.1 Main Features Synthesis Wash is the SGM new professional moving head thought to be used in big show events, theater, television and entertainment venues in general. Developed by SGM tenth years experience in the mechanical and electronic engineering, for its advanced performances Synthesis is at the top of the best worldwide production.

  • Page 8: Optic

    SGM Technology for Lighting PTIC Optic with high luminous efficiency 1 Projection angle linear regulation - PC 7° ÷37° - FRESNEL 8° ÷40° - WIDE A. 60°÷80° 8 bit motorised focus ISPLAY ICROCOMPUTER Long lasting rechargeable buffer battery supplied as standard to modify the display settings by...

  • Page 9: Electrical Specifications

    (neutral detachment or fluctuating low voltage). For this reason SGM has developed a system able to protect Synthesis from the common problems of the electrical installation, making everything transparent to the end user. The protections are: 1.
  • Page 10 SGM Technology for Lighting LAMP SPECIFICATIONS Synthesis Wash is fitted with Osram HTI 700W SE/75 lamp. This lamp is able to generate a color temperature of 7200°K, alternatively the same lamp is available but with color temperature of 5600°K with a life of 750h.

  • Page 11: Mechanical Features

    SGM Technology for Lighting 1.4 Caratteristiche Meccaniche CORPO: Fusione in alluminio, carter in Termopolicarbonato PESO: 39,5 KG DIMENSIONI IN mm: 530° SGM T ECHNOLOGY FOR LIGHTING SI RISERVA IN QUALSIASI MOMENTO DI APPORTARE MIGLIORIE E MODIFICHE AI PROPRI PRODOTTI IFERITE SEMPRE IL MANUALE ALLA MACCHINA A CUI VIENE ABBINATO PER...

  • Page 12: Installation

    SGM Technology for Lighting NSTALLATION 2.1 Equipment During unpacking, make certain that all the necessary parts have been received and that the fixture has not been damaged during transport. Should there be any problems, contact the local authorized SGM distributor immediately.

  • Page 13: Installing The Fixture On A Support Structure

    SGM Technology for Lighting 2.3 Installing the fixture on a support structure Read the following safety information before proceeding with the installation of the fixture: • FIXTURE NOT FOR DOMESTIC USE. • DO NOT INSTALL THE FIXTURE NEAR SOURCES OF HEAT.

  • Page 14: Fitting Clamps

    SGM Technology for Lighting 2.5 Fitting clamps Always use two clamps to hang the fixture. Attention : if the fixture is suspended from a truss suspended above ground or floor level, fix the fixture with a steel safety cable. Fix the fixture to the support structure using two safety chains fixed to the clamp (PICT. 2) Don't fix the safety chain to the handles, use the safety chain fixing point located in the center of the base.

  • Page 15: Construction Of The Signal Cable

    SGM Technology for Lighting ONSTRUCTION OF THE SIGNAL CABLE Synthesis Spot has a DMX 512 input fitted which uses standard XLR 5 Pins connector. For the connection use screened cables having the EIA RS-485 specifications with the following features: 2 conductors plus screen 120 ohm impendance- low capacity Max transmission speed 250 Kbaud.

  • Page 16: Construction Of The Dmx Termination

    SGM Technology for Lighting ONSTRUCTION OF THE DMX TERMINATION The termination avoids the risk of DMX 512 signals being reflected back along the cable when they reaches the end of the line: under certain conditions and with certain cable lengths, this could cause them to cancel the original signals.

  • Page 17: Rs-232 Connection

    1. Install the USB-DMX driver on the PC you will use to download the software. The driver and the instructions to install it will be available in our web site www.sgm.it 2. Connect the USB-DMX cable from the PC to the fixture.

  • Page 18: Access To Internal Components

    SGM Technology for Lighting 2.7 Access to internal components All work must ALWAYS be carried out by qualified technical personnel. ATTENTION!! make certain that the fixture is switched off and that there is no risk of burns due to high component temperature (wait at least 30 minutes after...

  • Page 19: Installing / Replacing The Lamp

    SGM Technology for Lighting NSTALLING REPLACING THE LAMP ATTENTION! This fixture is designed exclusively for use with Osram HTI 700W/SE/75 lamps. NEVER USE ANY OTHER TYPES OF LAMPS. DISCONNECT THE POWER SUPPLY BEFORE CARRYING OUT ANY WORK ON THE FIXTURE.

  • Page 20: Lamp Alignment

    SGM Technology for Lighting AMP ALIGNMENT When replacing the lamp with a new one, align the lamp with the optical system to obtain the max uniformity and luminous performance by the projection. 1. Install the new lamp close the fixture and switch it on 2.

  • Page 21: Installing / Replacing The Color Filters

    SGM Technology for Lighting NSTALLING REPLACING THE COLOR FILTERS Note: on the image the color filters are 4; the following procedures are the same. Choose, in the color or effect wheel, which dichroic filters is to be replaced. Color filter removal: 1) Widen the disks fitted in the color wheel as indicated in picture A1 2) Grip the dichroic filter between your fingers and slide the filter out as indicated in picture A2.

  • Page 22: Icro Omputer Ontrol

    SGM Technology for Lighting ICRO OMPUTER ONTROL 3.1 Microcomputer “Control” Synthesis is fitted with a microcomputer that enables the best fixture customization to the type of installation. It is possible: To assign the starting address Receive data on lamp elapsed time and fixture operating time...

  • Page 23: Structure Of The Menu

    SGM Technology for Lighting 3.4 Structure of the menu Here below are indicated the options composing Synthesis menu. Menu Options Description ADDRESS XXX Range 001-456 Fixture addressing NORMAL Normal PAN control of left to right PAN movement. PAN MOVE REVERSE Inverted PAN movement control (from right to left).
  • Page 24 SGM Technology for Lighting SHUTTER Enables shutter closure in the event of pan/tilt loss of position. COLOSE=EN FACTORY=SET Enables to set default parameters. FACTORY FACTORY=OFF Value during normal operation. Enables to restore the values of the parameters set immediately PREVIOUS=SET PREVIOUS before FACT=SET procedure.
  • Page 25 SGM Technology for Lighting INPUT Shows the Processor-in board software version. Shows the Processor-pan board software version. TILT Shows the Processor-tilt board software version. VERSION GOBO Shows the Processor-gobo board software version. ZOOM Shows the Processor-zoom board software version. Shows the CMY board software version.

  • Page 26: Starting Channell Assignment (Addressing)

    SGM Technology for Lighting 3.5 Starting Channell Assignment (addressing) To receive the necessary instructions for its functionning, it is necessary to ADDRESS=XXX assign to each projector a starting address from a controller. This address indicates the first channel used (starting channel) and can be assigned in a different way from the one used to connect the signal line.
  • Page 27 SGM Technology for Lighting Setting Pan movement starting angle Synthesis has a Pan movement range of 530°. If the entire excursion doesn't have to be used, two parameters allow to set the starting angle (MIN) and ending angle(MAX), which 4°. To limit pan movement, proceed as follows: PAN POS MAX=004 1.
  • Page 28 SGM Technology for Lighting Pan/Tilt inversion This function also allows to optimize Synthesis moving head in relation to PAN TILT SWAP=OFF the operator’s position, in order to simplify all positioning procedure. When SWAP is enabled (ON), this means that the lighting console sends the data regarding Pan to the Tilts controls and vice versa.
  • Page 29 SGM Technology for Lighting Lamp strike meter Synthesis microcomputer stores various data, including those related to the LAMP STRIKE number of lamp strikes. This information is important because the ‘unuseful’ lamp strikes cause stress to the components, so they can contribute to reduce the lamp life.
  • Page 30 SGM Technology for Lighting Wireless Synthesis Spot is the first fixture worldwide to be fitted with the DMX WIRELESS Wireless connection as standard. It uses atechnology based on the idea of GSM, with a radius over 500 meters. It has been widely tested in environments with WiFi, bluetooth, GPRS-UMTS signals, with excellent results.
  • Page 31 SGM Technology for Lighting Pan/Tilt movement resolution This function allows to define the movement resolution (16 or 8 bit). The PAN TILT RES difference is in the number of steps in which the range of head movement is divided. In high res. (16bit) mode, 530° ofl pan and 250° of tilt are divided into 65.536 steps, ensuring very smooth precision even at very low speed.
  • Page 32 SGM Technology for Lighting Remote control lamp ignition Operators can decide if the ignition of Synthesis is to be controlled from a LAMP CONTROL=DS lighting console or be automatic. To access this function, proceed as follows: 1. Connect Synthesis to the power supply, wait till it has completed reset operations.
  • Page 33 SGM Technology for Lighting Display brightness Operators can select one of the brightness levels available for Synthesis BRIGHTNESS=40% display, which can be standard or very low. This option is intended for theatre and television use, where excessive brightness can be troublesome.
  • Page 34 SGM Technology for Lighting Locking/Unlocking the shutter This feature allows to disable or enable Shutter closure if Pan or TILT loose SHUTTER CLOSE=EN their position. 1. Connect Synthesis to the power supply, wait till it has completed SHUTTER CLOSE=DS reset operations.
  • Page 35 SGM Technology for Lighting Calibration of the PAN and TILT “home” position and of the color wheel “white” position On the setting menu it is possibile to calibrate the PAN and TILT’s “home” position and the color wheel’s ”white” starting position. To do the calibartion...
  • Page 36 SGM Technology for Lighting Temperature This menu allows to display the internal temperature detected in many TEMPERATURE points of the fixture and measured both in Celsius and Fahreneit degrees. Thanks to a sophisticated software, Synthesis is able to activate internal projections with the aim of avoiding overheating.

  • Page 37: Error Messages

    SGM Technology for Lighting 3.6 Error Messages Error Messages Description NO SIGNAL No signal on DMX input. SIGNAL ERROR Signal on DMX input disturbed. PAN COM FAIL The Processor-in does not receive data by the processor pan board. TILT COM FAIL The Processor-in does not receive data by the processor tilt board.

  • Page 38: Aintenance

    Do not submerse in liquid! Servicing should only be conducted by qualified technicians and not by the user. If any liquid has been spilled on or into the fixture, contact SGM Technical Support before attempting to service the fixture. Exterior Surfaces: To clean the exterior surfaces proceed as follows: Wipe with a soft tissue or use a small vacuum to remove any builtup dust and dirt.
  • Page 39 SGM Technology for Lighting Mechanical Parts: ZOOM: Use a soft cloth and ACETONE to remove dust and dirt from the 2 shafts used for the zoom lens movement. Lubricate with Teflon spay grease. FOCUS: Use a soft cloth and ACETONE to remove dust and dirt from the 2 shafts used for the focus lens movement.

  • Page 40: Control Channels

    SGM Technology for Lighting ONTROL HANNELS Synthesis Wash is compatible with all the consoles using the standard USITT DMX512 signal and can operate in 2 different modes: V (20 Ch), T (19 Ch). The operating modes and therefore the total number of channels used by Synthesis Wash depend on the settings configured on the SPEED CONTROL menu.
  • Page 41 SGM Technology for Lighting Iris (Ch5) DMX V ALUE UNCTION 0 .. 255 Linear Variation Color(Ch6) ENTRAL DMX V ALUE UNCTION ALUE 0 – 22 WHITE 23 – 45 COLOR 1 red 46 – 68 COLOR 2 green 69 – 91 COLORE 3 blue 92 –...
  • Page 42 SGM Technology for Lighting Shutter / strobo (Ch8) ENTRAL UNCTION ALUE ALUE 0 -- 7 Closed 8 --15 Strobe at the frequence of 1Hz 16 -- 23 Strobe at the frequence of 1,38 Hz 24 – 31 Strobe at the frequence of 1,6 Hz 32 –...
  • Page 43 SGM Technology for Lighting Electronic Focus (Ch13) DMX V ALUE UNCTION 0 - 255 Linear Regulation 0 – 100% Frost (Ch7) DMX512 UNCTION 0—255 EVEL RANGE Frost disabled 0 – 255 Variazione lineare Full Frost inserted Cyan ( Ch15 )
  • Page 44 SGM Technology for Lighting Lamp reset On (Ch18) DMX512 UNCTION Level range 0—255 10 – 60 LAMP 61 – 129 Hysteresis 130 -- 179 180 – 239 Hysteresis RESET 240 – 255 Reset Macro (Ch12) DMX VALUE CENTRAL FUNCTION VALUE 0 –7...
  • Page 45 SGM Technology for Lighting MACROS DESCRIPTION MACRO DESCRIPTION CHANNELS Slow ramp opening on the dimmer – rapid closure Dimmer Shutter Slow ramp closing on the dimmer – rapid opening Dimmer Shutter Odd Fixtures perform slow ramp opening on the dimmer, even...
  • Page 46 SGM Technology for Lighting Conversion Table MSPEED MSPEED MSPEED MSPEED DMX V DMX V DMX V DMX V ALUE ALUE ALUE ALUE (in secondi) (in seconds) (in seconds) (in seconds) 0 -- 1 cross fade cross fade cross fade www.audiovias.com - 44 - User’s Manual 1.00...
