Contents Checklist
1.
Please check the components after unpacking. If any are missing, please contact the dealer.
Part
E700
AC Power Adapter
AC Power Cable
Thermal Paper Roll
Quick Setup Guide
2. Product Description
Printer Button， Finger Print， Printer Paper Exit， Power & Printer Indicator， Power Button，
Light Sensor，Cashier Facing Scanner，LCD Display
Hybrid Card Reader，Customer-facing Scanner，Contactless Area
Front View
Q20 view
Qty
1
1
1
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for PAX Computer Technology E700
- Page 1 Contents Checklist Please check the components after unpacking. If any are missing, please contact the dealer. Part E700 AC Power Adapter AC Power Cable Thermal Paper Roll Quick Setup Guide 2. Product Description Printer Button， Finger Print， Printer Paper Exit， Power & Printer Indicator， Power Button，...
- Page 2 Host Port，USB-OTG，LAN，Battery Cover Volume+，Volume- Side View 3. Terminal Ports The following ports are accessible on the back of the E700: • Power – Connect AC power supply to E700 • Cash Drawer – Insert the cable from cash drawer to connect with cash register •...
- Page 3 Select Power off. The terminal turns off after a few seconds. (See page 1 for the location of the Power button.) 5. Hybrid Card Reader The Q20 on the consumer-facing side of the E700 includes a reader that can be used as a Magnetic Stripe, EMV, and NFC/Contactless card reader. •...
- Page 4 CPU: Quad-core Cortex™-A63，1.8GHZ Operation System: Android 7.1 Memory: 2GB DDR+16GB eMMC Main Display: 12.5 inch, 1920x1080 resolution, capacitive touch screen Printer: 3" high-speed thermal printer with auto-cutter, printing speed 150mm/s, paper width 80mm, diameter 80mm Audio: Built-in speaker, support headphone output Camera with scan window: (coverage of 30mm-120mm) for 1D/2D scan ...
- Page 5 In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate Hereby, PAX Computer Technology (Shenzhen) Co., Ltd. declares that the radio equipment measures.
- Page 6 Icon shows The mains plug is used as the disconnect device, The socket-outlet shall be installed near the equipment and shall be easily accessible. This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
- Page 7 compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
- Page 8 PAX TECHNOLOGY LIMITED Manufacturer: PAX Computer Technology (Shenzhen) Co.,Ltd. Address:4/F, No.3 Building, Software Park, Second Central Science-Tech Road, High-Tech Industrial Park, Shenzhen, Guangdong, P.R.C. Tel: 0755-86169630 Fax: 0755-86169634 Website: http://www.pax.com.cn Responsible Party: PAX Technology, Inc. 8880 Freedom Crossing Trail, Building 400, 3rd Floor Suite 300, Jacksonville , Florida,...
