Movon MDAS-3LFFHD User Manual

Driver assistance system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

User Manual

MDAS-3LFFHD

Table of Contents

Need help?

Do you have a question about the MDAS-3LFFHD and is the answer not in the manual?

Questions and answers

Summary of Contents for Movon MDAS-3LFFHD

Page 1 User Manual MDAS-3LFFHD...
Page 2 • Do not modify nor disassemble the product and cables. It can cause explosion or fire resulted in injury or property damages. • Operating temperature is 4 ℉ ~ 158℉ (-20 ℃ ~ 70℃). MDAS-3LFFHD may not operate properly and be damaged in excess of the temperature.
Page 3: Table Of Contents
Contents 1. About MDAS-3LFFHD …………………….… 1) About Product 2. Specification …………………………….…….. 3. Components …………………………….…….. 4. Part description ……………………….……. 5. Button description …………………….…… 6. Operating LED status ………………………. 7. Indicator …………………………………………. 1. Cabling overview ………………………..…. 2) Installation 2. Installing ………………………………...…… 1. OBD-II Adaptor 2.
Page 4 1. About Product 1.1 Product Overview Movon Advanced Driver Assistance System ( MDAS ) helps to drive safely by using a machine vision recognition technology to prevent drowsy or reckless driving. [ Main functions ] Forward Collision Warning (FCW) Assists the driver to keep the safe distance from the front vehicle as the driver’s preset distance as well as It warns the driver of an impending crash with audio and visual warnings.
Page 5 1. About Product Cortex A7 Dual-Core Audio Out Speaker Camera 1080p ( Sony IMX322 ) Input Range DC 10V ~ 36V Power Power 200mA @ 12V Max Consumption 0.3mA @ 12V Idle State Video AVI (h.264 codec: VGA / 30fps) Format Audio Storage...
Page 6: Components
1. About Product 1.3 components [ 6pin Power cable ] [ User Manual ] [ Micro SD card ] [ Main Unit ] [ Analog Cable ] ■ Option Accessory [ GPS Module ] [ Video Out cable ] [ OBD-II Adapter ] [ Anti Temper Cover] [ indicator ] [ Wi-Fi Dongle ]...
Page 7 1. About Product 1.4 Part names Speaker Main cable Double side sticker Angle adjustment lever 5pin USB port Video out port GPS port Micro SD card slot Volume down Left LDW sensitivity setting Panic Recording Camera lens FCW sensitivity setting Volume up Right LDW sensitivity setting...
Page 8 1. About Product 1.4 Main Cable Port Indicator connecter Or RS232 for FMS 4pin Analog connecter 6pin CAN/Power connecter...
Page 9: Button Description
Change Left “Lane Departure Warning” sensitivity. ◎ Left LDW setting. Sensitivity Change (Level 1~5) ○ Volume Up Volume up (Increasing sound) ○ Volume Down Volume down (Decreasing sound) ◎ ◎ ◎ Factory Reset Restore MDAS-3LFFHD to factory settings. Defaulting MDAS system. (Rebooting)
Page 10: Operating Led Status
- If USB port is used Default MDAS system to the factory setting Defaulting MDAS system. Default the system Amber Amber Amber MDAS-3LFFHD can not read a Vehicle’s CAN CAN-related Error Amber data. MDAS-3LFFHD can not receive video from a Camera-related Error Amber camera.
Page 11 1. About Product The color in LED is changing left to right NOTE: Icons indicate 1.6 Operating Status The color in LED is blinking LED buttons Mode Description Voice Guidance LDW/FCW While driving *Safe Following Distance, Safe Distance Alarm, When front cars are detected and it is in the One short-beep sound Car detection &...
Page 12: Indicator
1. About Product 1.7 Indicator Volume/Sensitivity Down Mode setting Volume/S LDW Active ensitivity Up LDW is enabled. LDW Unavailable LDW is not active. Left Departure Alert When the vehicle departs the left lane. Right Departure Alert When the vehicle departs the right lane. Front Vehicle Detection When the vehicle ahead is in the host vehicle’s lane.
Page 13 1. About Product Recording without voice DVR function is working and voice is not being recorded. Recording with voice DVR function is working and voice is being recorded. Camera Error Camera connection is not good. Contact your local distributor/installer. CAN Communication Error CAN Communication has a problem.
Page 14 1. About Product 1.8 Indicator Setting Display Turning Off : Press the center button until the display turns off (Even if the display turns off, it gives a warning sound) Display Turning On : Press the center button. Mode Selection 1) Working Mode When it turns on, working mode operates.
Page 15 1. About Product 4)Right LDW Sensitivity Control Mode Press the center button once it changes to Right LDW sensitivity control mode. Press the (-) and (+) button to decrease or increase the right LDW sensitivity and save the n ew settings. The right LDW sensitivity level appears in numbers. Press the center button again, it goes to FCW sensitivity control mode.
Page 16 2. Product Installation 2.1 Installation overview - Attaching MDAS-3LFFHD and organizing wires Overview of placing and wiring MDAS-3LFFHD Step 1: Remove the lens cap and the double-sided tape off the product.
Page 17: Obd-Ii Adaptor
2. Product Installation * NOTE Clean any foreign matter and moisture from the where the product will be installed. Step 2: Attach the product to the windshield as close as to the center of the vehicle widthwise. To enhance the performance of the product, it is recommended to install the product between left 5cm(10inch) and right 5cm(10inch) in the center.
Page 18 2. Product Installation Step 4: Initial Setting. Please follow setup procedures carefully. Description Voice guidance Setting announcement and camera angle level Starting Initial Setting. adjustment Please make sure the white line is level with the ground. Adjust aligns the horizontality with using the adjustment knob of the product.
Page 19 2. Product Installation 2.2 Installation with OBD-II adaptor NOTE – Follow OBDII cable instruction below only the car is available with CAN-BUS signals. Step 1: Connect the OBDII adaptor with 6 pin power connector from the camera unit. [6Pin Power connector] [6Pin Cord of OBDII Adaptor] Step 2: Connect the OBDII adaptor to the OBD (On board Diagnostics System) port of the vehicle.
Page 20 2. Product Installation 2.3 Installation with using analog cable Step 1 : Connect the 4 pin analog cable to the 4 pin cord of the main cable. [4Pin connector] [4Pin Analog Cable] Step 2 : Connect the Right & Left turn signal of 4 pin analog cable to the analog turn indicator of the vehicle. Step 3 : Connect the speed signal of 4 pin analog cable to the analog turn signal indicator of the vehicle.
Page 21 “ADAS Setting” can be installed via Play Store and App Store for Android phones and iPhone respectively. Step 2 : How to connect MDAS-3LFFHD and your phone Plug Wi-Fi Dongle into MDAS-3LFFHD micro 5PIN USB port. (Wi-Fi Dongle and cable is optional) ADAS Setting Icon...
Page 22: Pc Calibration
3. PC Calibration STEP 1 : PC Connection • Connect the product to the PC by using the Micro USB cable with 5 pins and start the engine. And, access to the http://10.0.0.1/ in an internet web browser. (Recommended Chrome, Above Explorer 9, Firefox, Safari) •...
Page 23 5km/h, it can be to the next page. modified through the speed correction button. •Note: Select Analog(GPIO) if MDAS-3LFFHD is wired to the car’s speed and turn signals directly • Note: Select “GPS” if you want to use GPS...
Page 24 3. PC Calibration STEP 3 : Vehicle Information Check STEP 4 : Camera Angle Setup I • Check the turn signal indicated in PC • Adjust the camera angle to locate the calibration mode and the cluster of the vehicle. horizon between the red guide lines.
Page 25 3. PC Calibration STEP 4 : Camera Angle Setup II STEP 5 : Hood Line Setup • Locate the red line on the hood line of • For better accuracy of LDW, locate the yellow vehicle to remove the useless area under dotted line in the horizon.
Page 26 3. PC Calibration STEP 6 : Camera Location Setup STEP 7 : LDW Sensitivity Setup Take a measurement and enter the exact value. (Select unit: cm, or inch) • Setup the sensitivity of LDW warning. 1. Camera Height: From the road to the camera lens. The distance between the wheel and lane 2.
Page 27 3. PC Calibration STEP 8 : FCW Sensitivity Setup STEP 9 : Extra feature setup • Repeating FCW alarm: • Setup the sensitivity of FCW warning. Only alert: Alert once according to FCW sensitivity FCW warning sensitivity will be changed as Safety Always: Alert continuously until out of range of FCW Distance Alarm(TTC) sensitivity changes.
Page 28 3. PC Calibration STEP 10 : DVR(Dashcam) Setup STEP 9 : MDTG Setup • Time: Setup the current date and time. • DTG: Turn on/off MDTG usage. • Gravity sensory Sensitivity: • Transmit data via RS-232: Change sensitivity for event recording. Turn on/off RS-232 usage and save logs in •...
Page 29 3. PC Calibration • Click the “Complete” button to finish the calibration.
Page 30: Menu Description
4. Setting Modification 4.1 Menu Description • Update Firmware: The latest firmware published in website (http://info.mdas.co.kr/) can be updated here. • Default System: It can be cleared and reset to the installation default. • Recalibration: Change current settings from ”Vehicle Information Check” •...
Page 31 4. Setting Modification • Connect the product to the PC with using the • Click the “Browse” button and upload the latest firmware. Micro 5 Pin USB cable. • In the internet, access to the http://10.0.0.1. • Click the “Update Firmware” menu.
Page 32 4. Setting Modification • Click the “Update Firmware” menu. • If the firmware update is successfully completed, click the “OK” button. • The product will be automatically restarted again.
Page 33 4. Setting Modification 4.3 How to Default System • The system initialization is completed, • Click the “Default System” menu. click the “OK” button...
Page 34 4. Setting Modification 4.4 How to Change Current Settings 4.5 How to Change Warning, DVR, Time settings •If you only want to change settings about warning • Click the “Change the Current Settings” menu. The setup page will start from “Vehicle Information sensitivity, DVR, MDTG, please press this.
Page 35: Forward Collision Warning
3. Function – 1) Forward Collision Warning 5. Function 1) Forward Collision Warning 1. “Safety Distance Alarm(TTC)” and “Forward Collision Warning” warns drivers by the vehicle speed in accordance with distances between the front car and the host car. 2. “Safety Distance Alarm(TTC)” informs the driver with audible alarm when the vehicle reaches the preset distance(Level 1 ~ 8) in accordance the vehicle speed.
Page 36: Lane Departure Warning
35 mph(45km/h). 2. When MDAS-3LFFHD recognizes the lane markings in the environment while driving over 45km/h, the LCD of main body displays green lines when the car stays in tits lane and displays red lines when the car departs its lane.
Page 37 3. Function – 3) Dashcam (Dual dashcam ready) 5. Function 3) Digital Video Recorder (Dashcam) 1. Normal mode: Records front driving scenes in a loop. 2. Event mode: When the impact is detected by Gravity-force sensor, it names a file with _E. 3.
Page 38: Tachograph
Time and numbers of Forward collision warning occurred h. Time and numbers of Lane departure warning occurred 3. MDAS-3LFFHD can transmit data through RS-232C Serial port to a device(e.g., 3G modem). 4. Tachograph viewer can be downloaded in Notice board on www.mdas.co.kr.
Page 39 3. Function – 4) Tachograph 5. Function Caution & Note • In the initial calibration procedure, the distance between “Bumper to camera” must be input as exact as possible. Otherwise it could measure distance wrong or sounds a false alarm due to distance miscalculation.
Page 40 3. Function – 4) Tachograph 5. Function 5) Video out UI description– Optional cable required - Please plug “Video out” cable in a display with AV connector (RCA) Car in the driving lane: Green Green changes to red when FCW is activated Distance between the cars Cars in other lanes: Blue Horizontal line...
Page 41 The term of this product warranty is 1 year from the purchase date. We, Movon Corporation, provide the product warranty according to Consumer Dispute Settlement Regulations (drawn up by the Fair Trade Commission). Movon Corporation or designated partners will provide the service upon request.
Page 42 6. Product Warranty Consumer Injury Warranty For the loss of a product while in Exchange/Refund Refund after performance/ depreciation functional When repair is unavailable due to plus an additional 10% problems Repair lack of spare parts within the Maximum: purchase under normal component holding period price)
