Summary of Contents for RHOMBUS MDC450
- Page 1 FCC ID: P27MDC450 IC : 5604A-MDC450 MDC450 Full HD PoE Mini Dome Camera Installation Guide Version: 1.0 Copyright 2019. All Rights Reserved. All trademarks and trade names are the properties of their respective owners...
-
Page 2: Package Contents
FCC ID: P27MDC450 IC : 5604A-MDC450 Package Contents The following items should be included: If any of these items are damaged or missing, please contact your service provider immediately. 1. Mini Dome Camera 2. L Tool 3. Mounting Screws: M3*16(5.5*16mm) *3... - Page 3 This Chapter provides details of the Mini Dome Camera's features, components and capabilities Overview The MDC450 is a weather-resistant, HD mini dome camera. It comes with an IP66 rated housing, with a F1.8 large aperture lens, high sensitivity imaging sensor and high power IR LED illumination. The MDC450 displays high quality colorful images in low light conditions, enabling it to view distances of up to 20 meters at night.
- Page 4 FCC ID: P27MDC450 IC : 5604A-MDC450 Physical Details - Mini Dome Camera Front Panel - Mini Dome Camera Figure 1: Camera Components IR LEDs These are used to provide illumination for night time viewing. Ensure that the two IR LEDs are not obstructed beneath the transparent dome bubble.
- Page 5 FCC ID: P27MDC450 IC : 5604A-MDC450 Status LED On (Green) - Power on. (Green, Amber, Off - No power. Blue) Slow Blinking (Green) - The LED blinks during start Fast Blinking (Green) - Download mode. On (Blue) - Network connection is available.
-
Page 6: Basic Setup
FCC ID: P27MDC450 IC : 5604A-MDC450 Chapter 2 Basic Setup This Chapter provides details on how to setup and mount the Mini Dome Camera. Installation Remove Bubble and Protective Foam a. Use the L tool to remove the three retaining screws and bubble. - Page 7 FCC ID: P27MDC450 IC : 5604A-MDC450 Figure 4: Connecting Ethernet Cable with the Caps Check the Status LED The Status LED turns on solid green during startup, which takes 60 to 90 seconds. After startup is completed, the LED begins to blink green.
-
Page 8: Ceiling Mounting
FCC ID: P27MDC450 IC : 5604A-MDC450 Mounting the Mini Dome Camera *Note: Please ensure the Mini Dome Camera is configured and added to the network before permanent mounting. Ceiling Mounting Identify the location where you would like to mount the camera. - Page 9 FCC ID: P27MDC450 IC : 5604A-MDC450 Figure 6: Routing the Cable Attach the bubble to the camera, and then secure it with the three screws by using the L tool. Note: Use the alignment marks to properly align the camera and bubble while attaching them together.
-
Page 10: Appendix A Specifications
FCC ID: P27MDC450 IC : 5604A-MDC450 Appendix A Specifications Mini Dome Camera Dimensions (DxH) 4.33” x 3.62” (110mm x 92mm) Lens F1.8. DFOV 75 Video H.264 and MJPEG Compression Image Resolution 1080p Operating -4F to 122F (-20C to 50C) Temperature Storage -40F to 158F (-40C to 70C) - Page 11 FCC ID: P27MDC450 IC : 5604A-MDC450 guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ‐Reorient or relocate the receiving antenna. ‐Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from thatto which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. If protective earthing is used as a safeguard, the instructions shall require connection of the equipment protective earthing conductor to...
