WRO-100
Wireless Router
OPHIT CO., LTD.
USER MANUAL
Model: WRO-100
Rev.1.0
1
OPHIT CO., LTD.

Advertisement

Table of Contents
loading

Summary of Contents for Ophit WRO-100

  • Page 1 WRO-100 Wireless Router OPHIT CO., LTD. USER MANUAL Model: WRO-100 Rev.1.0 OPHIT CO., LTD.

  • Page 2: Table Of Contents

    2. Operation Mode 3. Internet Settings 4. Wireless Settings 5. Firewall 6. Administration 7. Product Specification and port list of TCP/IP 8. Environmental Conditions for operation 9. Trouble shooting guide & Cleaning Instruction 10. Warranty & Warning 11. Parts OPHIT CO., LTD.
  • Page 3 Please contact the manufacturer or other authorized disposal company to decommission your equipment. IEC60601-1 (EN60601-1, Safety of Medical Equipment) - IEC60601-1-2 (EN60601-1-2, Electromagnetic Compatibility Requirements) * Class A for Noise-emission, and Level B for Noise-immunity OPHIT CO., LTD.
  • Page 4 Important but hazard related if ignored. *This device is built to connect a medical device to medical facilities router/routers or to network system for data transferring. WRO-100 can be connected to medical devices wirelessly and also using LAN cable. OPHIT CO., LTD.
  • Page 5 WRO-100 Wireless Router 1. Connecting to WRO-100 Setting Page Open Windows explorer and connect to 10.10.10.254 (WRO-100 default IP address) Input User name/ Password User name: admin / Password: admin Initial Setup screen will appear as below. OPHIT CO., LTD.

  • Page 6: Operation Mode

    WRO-100 Wireless Router 2. Operation Mode Default Value is Gateway Mode and normally changing Mode is not recommended except for Technicians or Engineers. OPHIT CO., LTD.

  • Page 7: Internet Settings

    3. Internet Settings Configured when using VDSL/ADSL (Dynamic IP) or Cable modem. NOTE DHCP(Auto configuration) Configured when VDSL, LAN, Cable, ADSL Service. Dynamic IP is automatically configured form Modem, and you can check WAN IP at Administration/Status menu. OPHIT CO., LTD.
  • Page 8 (ID and Password is needed when connecting to Internet) NOTE PPPoE Setting On PPPoE setting you need ID and Password. ID and Password is delivered form ISP (Internet Service Provider). ISP may provide IP address to connect. In this case you can input IP Address OPHIT CO., LTD.
  • Page 9 WRO-100 Wireless Feature Description You can select SSID (Ophit) in Windows98, Me, 2000, vista, 7, 8 in the Wireless setup driver on your PC. (Mostly you can find it on the lower right corner of you window screen, double click to configure and...
  • Page 10 Wireless LAN or in some LAPTOP PC you can set it on by function Key. Control Panel  Network and Internet  Network Connection  Wireless Network Connection (Wi-Fi), Click Mouse Right button  Click Connect / Disconnect  Click/Select ‘Ophit’  Click Connect Button OPHIT CO., LTD.
  • Page 11 WRO-100 Wireless Router IP Address: WRO-100 IP setting. Factory default setting Gateway is 10.10.10.254. DHCP Type: Automatic setting for IP address for PC. Select Default value. Range of IP Address: Automatic IP address setting by server and configures the range of IP address.
  • Page 12 Input Network address and Net mask to destination. Input Gateway address of LAN to Routing table of Dedicated NET. Click "Apply" and then Routing table for NET. Table Initialization If you click "Initialization" button, all the value setting will go back to default value. OPHIT CO., LTD.

  • Page 13: Wireless Settings

    WRO-100 Wireless Router 4. Wireless Settings Basic You can configure basic wireless settings including Network Name (SSID), etc. OPHIT CO., LTD.
  • Page 14 With Windows 98, ME, 2000, driver installed on PC should support WPA2-PSK password. If there are other APs near WRO-100, 2.4GHz frequency channel may be interrupted and with other Aps. Normally WRO-100 uses channel 6, if you find out channel 3~9, you’d better change channel as below.
  • Page 15 You must remember this Key1~4 value If you want string, you can change Hex to ASCII at the drop box on the right side of WEP Key input box. You can input 5 digit letter or 13 digit numeric. OPHIT CO., LTD.
  • Page 16 On Windows Control Panel  Network and Internet  Network Connection  Wireless Network Connection (Wi-Fi), Click Mouse Right button  Click Connect / Disconnect  Click ‘Ophit’ Click Connect Button Input network Key password  Click Connect If ‘Connected” message shows up, you are successfully connected (Do not forget network key)
  • Page 17 WRO-100 Wireless Router WPA-PSK Security Security Mode Setting Select WPA / TKIP - > Input Network Key  “Click Apply” Network Key is determined by User. (Do not forget Network Key.) OPHIT CO., LTD.
  • Page 18 Set IP as 10.10.10.xxx on connecting device (setting IP of the device in the same network area but different IP with WRO-100 for connection) and open Internet Explorer. After getting connected to WRO-100 AP on wireless, type 10.10.10.254 on explorer and then press enter to be connected on setting page. (User name/Password: admin/admin) Go to Wireless Distribution System Setting page by clicking WDS on Menu Default value is set as “Disable”.
  • Page 19 When setting WDS there are CCK, OFDM, HTMIX, GREENFIELD in “Phy Mode” CCK : 802.11b OFDM : 802.11g HTMIX : 802.11b/g/n GREENFIELD : 802.11n Phy Mode and Encryp Type needs to be set same on connecting AP. OPHIT CO., LTD.
  • Page 20 WRO-100 Wireless Router On “AP Mac Address” input AP Mac Address of device you will connect. After setting is done click “Apply” and then reboot, Device must be rebooted for WDS function to operate. OPHIT CO., LTD.
  • Page 21 Master AP Slave AP IP : 10.10.10.254 IP : 10.10.10.253 F8:97:CF:00:35:07 F8:97:CF:00:35:08 1. Check LAN IP, MAC Address and DHCP Type: Disable after connecting to each AP. Master AP and Slave AP must use different IP addresses. OPHIT CO., LTD.
  • Page 22 If Encrype key is needed use same PIN. Input AP MAC Address of connecting device.(Input Salve AP MAC Address in Master AP, Input Master AP in Slave AP MAC Address) Same data needs to be inputted on MASTER AP and SLAVE AP. OPHIT CO., LTD.
  • Page 23 After internet has been reconnected click “Rebooting” button in Settings Management page. *Both device need to be rebooted even when only AP setting of one device have changed. Internet will be ready to use after AP rebooting. OPHIT CO., LTD.

  • Page 24: Firewall

    You can input TCP/UPT port Number to protect protocol. To delete the settings, you can click “reset”. Save Settings To save the setting, you can click the “Save”. If you do not save, the settings are lost with power restart of AP. OPHIT CO., LTD.
  • Page 25 WRO-100 Wireless Router Port Forwarding Save Setting To save the setting, you can click the “Save”. If you do not save, the settings are lost with power restart of AP. OPHIT CO., LTD.
  • Page 26 This is the features to protect certain IP or PC’s string web connection. If you want to protect certain PC or IP , you can input IP or MAC address of PC. You can input the string of Web site address to protect. OPHIT CO., LTD.
  • Page 27 The meaning of DMZ Setting is all the packets received by TCP/UDP port are transferred to dedicated IP. The PC or Server dedicated as DMZ can be operated as FTP server, HTTP server, Mail Sever without any other manipulation. OPHIT CO., LTD.

  • Page 28: Administration

    You can protect the users by setting log-in Password. You can change Password by input new Password and click “Apply” to apply. The default account name is "admin". NTP Setting You can set different time by different country. (The default value is Korean.) OPHIT CO., LTD.
  • Page 29 In this case you have to do it again for the process of Update firmware. Caution Once Upgrade, all settings are back to default value. You can click” Search…” and find the firmware and click “ Apply” Once the upgrade begins, you can see the screen as below. OPHIT CO., LTD.
  • Page 30 WRO-100 Wireless Router Caution Never Power off during Upgrade process. OPHIT CO., LTD.

  • Page 31: Product Specification And Port List Of Tcp/Ip

    DRAM 16Mbytes FLASH 2Mbytes Temperature Celsius 0-50 degree Power Local power :DC5V,0.2A SNAT, DNAT, IP Masquerade Specification Protocol HTTP,DHCP,PPPOE Wireless IEEE802.11b,IEEE802.11g,IEEE802.11n Frequency 2.4GHz -65dBmat130Mbps,-74dBmat54Mbps, Sensitivity -84dBmat11Mbps Wireless Specification TX power 16dBm±2dB Modulation OFDM,CCK,BPSK,QPSK 64/128bitWEP,WPA-PSK,WPA2PSK Security Settings WPAPSK/WPA2PSK OPHIT CO., LTD.
  • Page 32 Network Game MSN Messenger 1863 Instant messenging Netscape Conference 6498, 6502 2327 Audio conference NNTPs Secure NNTP news (SSL) Palm Computing 14237 14238 Data synchronization Network Hotsync pcAnywhere 5631 5632 Remote control Post Office Protocol POP3 Version 3 OPHIT CO., LTD.
  • Page 33 Danish plug, to be inserted, to protect the AC circuit in specific medical settings. External equipment intended for connection to signal input, signal output or other connectors, shall comply with relevant IEC standard (e.g.,IEC60950 for IT equipment and IEC60601 series for medical OPHIT CO., LTD.

  • Page 34: Environmental Conditions For Operation

    Air conditioner and heater are required in the system room for the operational and storage conditions in order to maintain the temperature and humidity as described above. However the above values are standard values so the actual temperature and humidity should be adjusted according to the operation condition. OPHIT CO., LTD.

  • Page 35: Trouble Shooting Guide & Cleaning Instruction

    WRO-100 Can’t be connected to product ● Check if power is on ● Check if device connected to WRO-100 and WRO- IP.(IP : 10.10.10.254) 100s IP and Subnet mask is set on same IP range. ● Press reset button for 5seconds and reconnect after 2 minutes.
  • Page 36 Degree of safety in the presence of flammable anesthetics mixture with air or with oxygen or with nitrous oxide. Not suitable for use in the presence of a flammable anesthetics mixture with oxygen or with nitrous oxide. Mode of operation: Continuous. OPHIT CO., LTD.
  • Page 37 WRO-100 Wireless Router 10. Warranty We, OPHIT hereby warrant the final purchase of our product as follows. In the case of troubles on our products, please contact the seller purchased. One(1) year limited warranty Our customers have right to be served with free charge when there is trouble in this product during one(1) year from the day purchased.
  • Page 38 Reorient or relocate the receiving antenna. Increase the distance between this system and the subject of interference. Plug this system into a outlet on a different electrical circuit than \that to which the subject of interference is connected OPHIT CO., LTD.
  • Page 39 Compliance Compliance : The WRO-100 complies with the essential requirements in the standard. Not Compliance : The WRO-100 does not comply with the essential in the standard. N/A : The test was not applicable in the standard. NOTE : The measurement result and tested in accordance with measurement procedures Specified in ANSI C63.4-2003.
  • Page 40 - Bracket: Only used when placing WRO-100 on a rack with DAU Rack type product. Place bracket that’s bended 90 degrees on the left side (where two screw holes are) of WRO-100 and assemble it by turning the screw clockwise, and to disassemble turn screw counterclockwise, place the other bracket on the right side of WRO-100 and use screw to assemble.

  • Page 41: Parts

    User Manual NOTE Use only the accessories provided by your WRO-100 supplier and WRO-100 package. (Antenna, LAN cable, bracket, foot rubber, power adapter, power cable) If any of the provided accessories such as Antenna, LAN cable, bracket, foot rubber, power adapter, and power cable has to be replaced of consumption or defect, contact your supplier for replacement parts.
  • Page 42 3F Suntechnovil, 5-27, Mangpo-Dong, Yeongtong-gu, Suwon-City, Gyeonggi-do, 443-440, KOREA TEL: +82-31-205-4191 FAX: +82-31-205-4197 OPHIT CO., LTD. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Copyright ⓒ OPHIT 2013 all right reserved OPHIT CO., LTD.
