Summary of Contents for latch LC9368-HTV
- Page 1 2MP Dome Camera Installation Guide...
-
Page 2: Table Of Contents
Table of contents Things you should know Included in the box Product details Installation Specifications Document number 770-00017 Requirements for compliance Revised on 07/19/2020... -
Page 3: Things You Should Know
The Latch Camera must be installed and protected in Included in the Box a location that is not easily accessible and away from • Latch Camera 2MP - Indoor & Outdoor Dome Camera possible impacts or heavy vibrations. • Screw pack and cable exit cover For example, look to install in a location where the •... -
Page 4: Product Details
Product Details Details and recommendations for power, wiring, and product specifications. Camera Installation Guide Version 1.0... - Page 5 When using a non-PoE switch The Latch Camera is PoE-compliant, allowing transmission of Use a PoE power injector (optional) to connect between the Latch power and data via a single Ethernet cable. Connect the camera Camera and a non-PoE switch.
- Page 6 Product Details Outer View Inner View Dome cover IR LEDs Lens MicroSD card slot RJ45 Ethernet connector Reset button LEDs Camera Installation Guide Version 1.0...
-
Page 7: Installation
Installation Follow these steps to proceed with installation. Camera Installation Guide Version 1.0... - Page 8 Open the top cover by loosening the TR10 Torx security screws. Camera Installation Guide Version 1.0...
- Page 9 256GB A MicroSD card is included. To replace, continue reading. Remove the existing MicroSD card and replace with a new card (256GB is recommended). Slide the lid forward. A clicking sound Optional: To replace the existing MicroSD card, open the SD should be heard to indicate that the lid and the SD card are card socket lid by sliding backward and flip open the lid.
- Page 10 Alignment Sticker Hole Diameter 1 - 1.5 inch Use the alignment sticker to drill mounting holes on the wall or ceiling. Drill a cabling routing hole if preferred. Route an Ethernet cable through the cabling hole. Camera Installation Guide Version 1.0...
- Page 11 Pass an Ethernet cable through the waterproof cable gland components and through the rubber seal. Connect the Ethernet Install the seal ring and twist and tighten to secure the waterproof cable to the camera’s RJ45 connector. components. Camera Installation Guide Version 1.0...
- Page 12 Incorrect Correct Secure the camera to the wall using the included anchors and screws. Seal side opening with cable exit cover. Note that if a routing hole through the wall is not possible, you can also route Note: We recommend forming a drip loop of cables to help avoid the cable through the side opening.
- Page 13 Old desiccant New desiccant Rotate or tilt the Latch Camera for desired optimal field of view. Replace the desiccant from the inside of the dome cover. Camera Installation Guide Version 1.0...
- Page 14 Install the dome cover and fasten with the TR10 Torx security Scan the QR code on the label with the Latch Manager App and screws. follow the steps in the app to configure. Camera Installation Guide Version 1.0...
-
Page 15: Specifications
• Built-in MicroSD/SDHC/SDXC card slot for on-board storage or network failed • Built-in microphone Red LED off Power off System Information • Model: LC9368-HTV Green LED off Network is disconnected • CPU: Multimedia SoC (system-on-chip) • Flash: 128MB Steady Red and Green LED blinks Connected to network •... - Page 16 Part 15 of the FCC Rules. These limits are designed to provide reasonable the Camera within Latch Manager again. Upon successful restore, the LED will blink Green protection against harmful interference in a residential installation. This equipment generates, and red during normal operations.
