- Page 1 CULTIVATOR IE – 101 中耕管理機 使用保養說明書 Operation and Maintenance Manual (www.ietw.com.tw) IE-IE CORPORATION MADE IN TAIWAN 使用前請務必詳細閱讀本說明書 2012 年 1 月製...
- Page 2 目 錄 Table of Contents 一. 各 部 位 名 稱 ----------------------------- 3~4 Machine Structure 二. 安 裝 步 驟 -------------------------------- 5~8 Set up 三. 潤 滑 ------------------------------------ 9~11 Lubrication 四. 作業前檢查 ---------------------------------- 12 Check before operation 五. ~ 八. 調 整...
- Page 3 二. 各部位名稱 (變速桿側) Machine Structure (Parts Location - Gear shift side ) 汽油引擎 Gasoline engine 變速桿 Gear lever 加油頭 Accelerator handle 尾輪調整把手 Guide Wheel adjustment handle 駐車腳架 Packing rack 尾輪 Guide 覆土側蓋 Side Cover 行走輪 Moving wheel...
- Page 4 三.安裝步驟 Set up 1. 開箱前先裝入把手 Install the handle prior to open the container. 2. 裝入把手架後抬出機體 Move out of the machine after the handle installed...
- Page 5 3. 將套管及輪胎裝入行軸 Fix the wheel and the connection pipe on the shaft of the Gearbox 單輪式樣 Single wheel 雙輪式樣 Twin wheel (八角軸心 Octagonal shaft) (八角軸心 Octagonal shaft) 4. 再將尾輪裝入,順時針轉動旋把 Install the Guide Wheel, and turn the guide wheel handle clockwise.
- Page 6 5.鎖緊呼吸管(GM291/GM301 專用套件) Tighten the respiratory tube (GM291/GM301 Special kit) 6. 雙面耕犁裝卸方法(穿過膠板) Install Two-sided plow (Through the plastic cover)
- Page 7 7. 裝入培土刀,注意旋回方向 Install the banking up blade, check the rotating direction. 8. 裝入耕耘刀,注意旋回方向 Install the Tillage blade, check the rotating direction. 旋回方向 9. 插入保險桿旋緊固定螺絲 回方向 Insert the protector and tighten the screw& Nut.
- Page 8 四. 潤 滑 Lubrication 1. 引擎 Engine : #30 機油 engine oil (1) 引擎潤滑油更換時機：第 1 次使用 15 小時潤滑油更換 , 之後每操作 80 個 小時更換 1 次 。 Engine oil periodic change schedule： Initial change for the first 15 hrs operation, after each 80 hrs operation, the engine oil must be changed。 (2) 更換方式...
- Page 9 be changed. (2) 更換方式 : 添加時機身放平 ,放鬆耕耘及行走部本體之洩油孔螺絲使油完 全漏掉後鎖上螺絲 , 由注油孔螺栓注入至探油窗 6 分滿位置即可。 How to change: Place the cultivator on a level surface and hold it in an upright position. Loose the oil drain screw on the Run body and tillage part to drain all the oil.
- Page 10 皮帶側 變速桿側 濾清器油杯 油孔 油孔 引擎 柱油孔 (油尺) 洩油孔 (引擎) 注油孔 油孔 探油窗 油孔 行走部本體 耕耘部本體 油孔 油孔 卸油孔 Belt side Gear shift side Filter oil cup enter hole Oil filler cap 油孔 (dipstick) Oil drain screw(Engine) Oil filler cap Oil check window 油孔...
-
Page 11: Check Before Operation
五 . 作業前檢查 Check before operation 1. 各部位螺絲 , 螺帽等有無鬆動現象 Check all part for loose screws and nuts. 2. 把手架有無鬆動現象 Check the handle bracket for any looseness. 3. 各潤滑部位是否依照指示適時加入潤滑油 Check if each Parts for lubrication in accordance with instructions. 4. 機械稍作運轉移動 , 檢查有無異常的聲音及異常發熱的地方 Start the engine and moving the machine to check for any abnormal noise and heat. - Page 12 六. 調 整 Adjustment 1. 把手高低調整 Handle height adjustment 把手可作上下五段高低調整 , 將高低調整握把壓入至定位銷分離狀態 , 依個人 使用狀況調至適當操作位置 , 再將握把放鬆即可定位固定 The adjustable handle provide 5 section height adjustment, press down the Handle height adjustment lever until the adjusting pin detached. Adjustable the handle height to a suitable operation position, release the Handle height adjustment lever can lock this suitable position.
- Page 13 六. 離合器調整 Clutch Adjustment 1. 當離合器握把放鬆時 , 使張力輪往上壓皮帶下方使皮帶壓緊產生傳動作用 , 如 圖示 A-3 引擎皮帶兩端皮帶呈平行狀態為最適當 When release the clutch lever , make the tension pulley turn upward to press the bottom of the belt and then belt become tightly to produce transmission action . As the Figure (A-3).
- Page 14 安全扣 Protector Press (Stop) 壓緊 ( 停止 ) 8 ~ 15mm 放鬆 ( 傳動 ) Release (Transmission) 離合握把 圖 A-3 Clutch lever 2~3mm 2~3mm 2~3mm 引擎皮帶輪 Belt pulley 圖 A-4 離...
- Page 15 八. 加油調整 Accelerator 加油推桿向右則引擎轉速高 , 輸出馬力 , 加油推桿向左則引擎轉速低 , 成待速狀 態 , 加油座 , 加油索調整 , 須使引擎於低轉速下調整並使調速器(GOVERNOR ROD) 於低轉速時使可調整 , 如圖 A-5 Accelerator to the right for higher speed running, result in powerful operation; Accelerator to the left for lower speed running, allow the engine in idle. When adjust the accelerate base and wire, the engine and the governor should be at the low rotational speed.
- Page 16 九. 操作使用方法 Operation Remarks 1. 行走部變速前進 2 段 , 後退 2 段耕耘部刀具轉速 2 段依作業適用選擇變速 The speed change for the Run Body has 2 forward and 2 reverse speed . The rotational speed for the Till Part, total is 4 speeds. Depend on the operating condition to select the speed 2.
- Page 17 5. 中耕或培土作業方式 : 將耕耘部裝上中耕刀 , 或培土刀 , 必須注意耕刀回旋 方向 (請參照三.安裝步驟 : 7 和 8 圖 ) , 將耕耘覆蓋 , 側蓋 , 塑膠擋泥板掀起 , 依需要作落土點之調整 , 先裝上中耕刀將土翻鬆 , 拆下中耕刀裝上培土刀及培 土鐵輪 , 即可進行培土作業 , 若需要作單邊培土作業 , 請將左邊培土刀拆下裝 上單邊培土刀(刀架為紅色) , 右邊培土刀不必拆 , 使土噴向右邊 ,操作時人站在 把手方向...
- Page 18 十. 安全警示 / 警告標誌 Safety Warning / warning signs 1. 作業前機器檢查 Check before operation : 檢查機器時 , 必須在引擎完全停止的安全狀況下檢查 Always check the machine while the engine is fully stopped to ensure a safety situation. 2. 作業刀具的各部螺絲 , 螺帽必須確實鎖緊 Fully tighten each part of screw and nut for operation blade. 3.
- Page 19 operation. (4) 操作者不可於刀具前進之前方操控作業 , 以確保人身安全(即嚴禁操作者以 後退行走方式操控作業) 若須使用後退檔時 , 先暫時停止刀具運轉 , 並降 低油門觀察後方及將障礙排除 , 確保後方安全無慮之後 , 再以低速檔小心 倒退(非必要時 , 勿使用後退檔) For personal safety, the operator should not control and operation in front of the blade when it move forward (It is strictly prohibit the way of walk back for operation).
- Page 20 十一. 保養(長期放置) Maintenance (long-term storage) 1. 各部清洗乾淨後 , 檢查各部位螺絲是否有鬆動 , 漏油 , 損壞 After cleaning all parts, to check if there is any looseness or oil leak or damages for all parts bolts. 2. 本機易生銹部分 , 在使用後 , 清洗乾淨並必須塗抹防銹油或噴漆以防生 銹 For the easily rusted parts of the machine: after using the machine, should be clean and wash and daub with the anti-rust oil or spray paint to prevent rust.
- Page 21 十二.隨機配件清單 Accessories 1. 4 聯耕耘刀 (一組) 4-rotary tillage blade (1 set) 2. 培土刀 (一組) Banking up blade (1 set) 3. 雙面犁 (一支) Two-sided plow (1 pc) 4. 鐵輪 (一組) Iron wheel (1 set) 5. 工具袋 (一個) Tool bag (1 bag) 內含：拆火星塞工具一組、插銷...
- Page 22 宜益有限公司 IE-IE CORPORATION 電話 Tel：886-2-2628-1660 傳真 Fax：886-2-2628-2263 地址 Add：新北市淡水區忠山里後坑子 13-2 號 No.1 Tan-Chin Rd., Sec.1, Tamshui Dist, New Taipei City, Taiwan, R.O.C.
