Esco PW1 User Manual
Version A - Released November 2013
User
Manual
Powder Weighing Balance Enclosure
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for ESCO Technologies Powdermax PW1 Series
- Page 1 Esco products. User Manual For Technical Service, contact North America Esco Technologies, Inc. 2940 Turnpike Drive, Units 15-16 • Hatboro, PA 19040, USA Toll-Free USA and Canada 1-877-479-3726 Tel 215-441-9661 • Fax 215-441-9660 us.escoglobal.com • usa@escoglobal.com Rest of World Esco Micro Pte.
- Page 2 Copyright Information © Copyright 2013 Esco Micro Pte Ltd. All rights reserved. The information contained in this manual and the accompanying product is copyrighted and all rights are reserved by Esco. Esco reserves the right to make periodic minor design changes without obligation to notify any person or entity of such change.
-
Page 3: Table Of Contents
INTRODUCTORY PAGES Table of Contents Manual Revision History Warranty Terms and Conditions Introduction 1. Products Covered 2. Safety Warning 3. Limitation of Liability 4. European Union Directives on WEEE and RoHS Declaration of Conformity USER SECTION Chapter 1 – Product Information 1.1 Quick View Chapter 2 –... -
Page 4: Manual Revision History
MANUAL REVISION HISTORY DATE SERIAL # OF 1 UNIT REV. NO. DESCRIPTION OF CHANGE REFERENCE RELEASED FOR IMPLEMENTATION... - Page 5 Esco products come with a limited warranty. The warranty period will vary depending on the product purchased, beginning on the date of shipment from any Esco international warehousing location. To determine which warranty applies to your product, refer to the appendix below. Esco's limited warranty covers defects in materials and workmanship.
- Page 6 These Terms and Conditions shall be governed by and construed in accordance with the laws of Singapore and shall be subject to the exclusive jurisdiction of the courts of Singapore. Technical Support, Warranty Service Contacts USA: 1-877-479-3726 Singapore: +65 65420833 Global Email Helpdesk: support@escoglobal.com Visit http://www.escoglobal.com/ to talk to a Live Support Representative Distributors are encouraged to visit the Distributor Intranet for self-help materials.
-
Page 7: Products Covered
1. Products Covered Esco PowderMax Powder Weighing Balance Enclosure Electrical Rating 0.9 meters (3 feet) PW1-3A1 220-240 V AC, 50Hz, 1Φ PW1-3A2 110-130 V AC, 60Hz, 1Φ 220-240 V AC, 60Hz, 1Φ PW1-3A3 100 V AC, 50/60 HZ, 1Φ PW1-3A7 2. - Page 9 Declaration of Conformation In accordance to EN ISO/IEC 17050-1:2010 Esco Micro Pte. Ltd. 21 Changi South Street 1 Singapore, 486777 Tel: +65 6542 0833 Fax: +65 6542 6920 declare on our sole responsibility that the product: Category : Powder Weighing Balance Enclosure Brand : PowderMax Model...
- Page 10 viii...
-
Page 11: Chapter 1 - Product Information
Chapter 1 - Product Information 1.1Quick View 1. Sash Window 4. Sentinel Control System 2. Baffle 5. Service Opening 3. ArmOpening 6. Mobile Cart (Optional) Powder Weighing Balance Enclosures... -
Page 13: Chapter 2 - Control System
Chapter 2–Sentinel Control System 2.1 Sentinel Control System Menu Down Button Button Button Button Lamp Socket UV/AUX Button Button Button Button Display 1. Fan Button Turns on and turn off the fan. 2. Lamp Button Turns on and turn off the fluorescent lamps. 3. -
Page 14: Menu Options
2.2 Menu Options Please refer to the following diagram for complete reference to all menu options available. SET TIME HH:MM WARM UP XX MIN POST PURGE XX MIN SETTINGS EXP TIMER HH:MM:SS VELOCITY UNIT M/S | FPM TEMP UNIT CELCIUS | FAHRENHEIT SET CONSTANT CALIBRATION ZERO SENSOR... - Page 15 2.2.1.3 PostPurge Time After the user switches off the enclosureblower, there will be a post-purge period, to ensure that all contaminants are purged from the work zone. The default setting is zero minute (disable) and user can set it between 0 to 15 minutes. However, it is recommended to purge the enclosure for around 3 minutes after the work is complete.
- Page 16 2.2.3.1 New ADMIN PIN (default 0009) ADMIN PIN restricts access to some of the more delicate menu functions, namely admin and field calibration, which should only be accessed by a qualified personnel. User must enter four digits ADMIN PIN before accessing these menus.
-
Page 17: Chapter 3 - Basic Enclosure Operation
Chapter 3 – Basic Enclosure Operation 3.1 Starting and Shutting Down the Enclosure 3.1.1 Turning on the Enclosure 1. Turn on the fan by pressing the FAN button. Input the Fan PIN if asked (if PIN ≠ 0000). This will start the warm up procedure (default: 3 minutes). - Page 18 Therefore you should pay careful attention to the following guidelines in order to achieve comfortable and healthy working conditions: Always ensure that your legs have enough legroom. • Keep your lower back comfortably supported by your chair. Adjust the chair or use a pillow behind •...
-
Page 19: Chapter 4-Service And Maintenance
Chapter 4–Service and Maintenance 4.1 Scheduled Maintenance Proper and timely maintenance is crucial for trouble free functioning of any device and your Esco enclosureis no exception to this rule. We strongly recommend that you follow the maintenance schedule suggested hereunder in order to obtain optimal performance from your Esco enclosure. Maintenance to be carried out every Description of Task to Perform Week... - Page 21 APPENDIX...
- Page 22 Cabinet : _______________________________________________________________ Serial Number : _______________________________________________________________ Person in Charge : _______________________________________________________________ 1. This log record should be used by the operator to record any new agent/virus/bacteria/germs that has been introduced to the cabinet during its operation, problems encountered, etc. 2.
