SMARTdesks 5100-BLK Installation Manual

Standing desk converter

Enlarged version

WARNING

Pinching Hazard

Strut moves during adjustment. Please do not

place hands, wires or other objects on or near the

strut during adjustment as it may cause pinching.

Please ensure all equipment/accessories are firmly

attached to the table, a nd do not hang over table

edge as t his may cause harm or damage.

A dhesive buckle is provided for cable management.

Please ensure adequate cable length allows for the

desired range of table adjustment/movement.

Please adjust t able to full height position prior to

removing the unit from tabletop or desk to avoid

harm or damage.

Two people should be used to move this unit. P lease

do not attempt t o move unit by yourself, as t his may

result i n harm or damage.

- 8-

CAUTION

Please DO N OT put hands, w iring or other objects

on or near the support bars, a s t hey move while

adjusting table, a nd may cause injury or damage.

CAUTION

www.smartdesks.com | 800 770 7042

Standing Desk Converter

INSTALLATION GUIDE

Item No.: 5100-BLK

CAUTION

Please read all instructions carefully and thoroughly before using this

product. P lease keep this manual and all instructions for future reference.

The specifications for this product may vary s lightly from the illustrations

and are subject t o change without prior notice.

Table of Contents

Need help?

Do you have a question about the 5100-BLK and is the answer not in the manual?

Page 1 Please read all instructions carefully and thoroughly before using this product. P lease keep this manual and all instructions for future reference. www.smartdesks.com | 800 770 7042 The specifications for this product may vary s lightly from the illustrations and are subject t o change without prior notice.
Page 2 Technical D ata ASSEM BLY STEP 5 DO N OT exceed the maximum load- bearing capacity Self- adhesive ties are used for clean W A RNING cable management. 35.0in 23.2in Nylon ties A: 6.6~33lbs 5.9~19.7in B:<=4.4lbs A+B=6.6~33lbs 31.1in 22.3in 24.0in ≤...
Page 3 A SSEMBLY STEP 4 ASSEMBLY STEP 1 Please put the devices onto the top of the workstation. Please take the packaging carton apart, t ake out t he product and place it Install equipment and devices onto the workstation. one the table. Remove all contents from the packaging and place onto sturdy table.
Page 4 ASSEMBLY STEP 2 A SSEMBLY STEP 3 a : A ttach decorative cover to the connecting arm. To operate the workstation, press t he two handle grips ( one each side) b : U sing a Philips head screwdriver, a ttach the junction simultaneously and raise or lower the top to desired height.
