1. Screw in the valve into the end of burner pipe. When you reach the end, turn the valve back
slightly so the copper pipe is over the burner (our logo facing up). Then, use a spanner to
secure the valve.
2. Connect the valve with LPG hose. Make sure to secure the hose clip safely to avoid gas leak.
MANUAL FOR
KB 5 / 7 / 8
Asia Machine Part Co.,Ltd.
Advertisement
Table of Contents
Summary of Contents for RT Champ KB 5
- Page 1 Asia Machine Part Co.,Ltd. MANUAL FOR KB 5 / 7 / 8 1. Screw in the valve into the end of burner pipe. When you reach the end, turn the valve back slightly so the copper pipe is over the burner (our logo facing up). Then, use a spanner to secure the valve.
- Page 2 3. Before turning on LPG gas tank, please make sure the valve knobs are at “Close” position. To light up pilot flame, turn on the right knob and use a lighter or a match to light it up. 4. Turn on the left knob to light up the burner. The burner is most efficient when the flame is blue as shown on Picture A.
