IDenticard 9000 Series Converting Instructions

Converting Series 9000™ Hardware for Use with PremiSys™ Systems
Determine the type and revision of your Series 9000 hardware and follow the instructions that apply to your panel, board or card.
Rev M Panels
DANGER – Disconnect all power from the
panel before replacing any chips. Be certain
to remove the lithium battery from the panel.
Unplug the back-up battery.
Firmware Replacement
1. Remove the Firmware EPROM chip from
socket U2.
2. Hold the new EPROM chip, labeled
"PREM 1-4-1 FW" so the notch in the chip
is on the left.
3. Align the rightmost pair of pins on the chip
with the rightmost pair of socket holes in
socket U2. There must be four open
socket holes (two pairs) at the left end
of the socket.
4. Carefully press the new EPROM chip into
socket U2.
Application Chip Replacement
1. Remove the App EPROM chip from socket
U5.
2. Hold the new EPROM chip, labeled
"PREM 1.2 App (512)" so the notch in the
chip is on the left.
3. Align the notch in the chip with the notch
on socket U5.
4. Carefully press the new EPROM chip into
socket U5. There should be no open
socket holes.
If you have a Reader Expansion Card follow the
instructions on the other side titled "Reader
Expansion Cards."
Rev L Panels
DANGER – Disconnect all power from the
panel before replacing any chips. Be certain
to remove the lithium battery from the panel.
Unplug the back-up battery.
Firmware Replacement
1. Remove the Firmware EPROM chip from
socket U2.
2. Hold the new EPROM chip, labeled
"PREM 1-4-1 FW" so the notch in the chip
is on the left.
3. Align the rightmost pair of pins on the chip
with the rightmost pair of socket holes in
socket U2. There must be four open
socket holes (two pairs) at the left end
of the socket.
4. Carefully press the new EPROM chip into
socket U2.
Application Chip Replacement
1. Remove the App EPROM chip from socket
U5.
2. Hold the new EPROM chip, labeled
"PREM 1.2 App (256)" so the notch in the
chip is on the left.
3. Align the notch in the chip with the notch
on socket U5.
4. Carefully press the new EPROM chip into
socket U5. There should be no open
socket holes.
If you have a Reader Expansion Card follow the
instructions on the other side titled "Reader
Expansion Cards."
IMPORTANT! See other side for critical
instructions to clear memory on reader
boards after you replace these chips.
See other side also to convert Reader
Expansion Cards and RI/O Boards.
Pre-ETL Panels ("Old-Style" Panels)
DANGER – Disconnect all power from the
panel before replacing any chips. Be certain
to remove the lithium battery from the panel.
Unplug the back-up battery.
Firmware Replacement
1. Remove the Firmware EPROM chip from
socket U4.
2. Hold the new EPROM chip, labeled
"PREM 1-4-1 FW" so the notch in the chip
is on the left.
3. Align the rightmost pair of pins on the chip
with the rightmost pair of socket holes in
socket U4. There must be four open
socket holes (two pairs) at the left end
of the socket.
4. Carefully press the new EPROM chip into
socket U4.
Application Chip Replacement
1. Remove the App EPROM chip from socket
U29.
2. Hold the new EPROM chip, labeled
"PREM 1.2 App (256)" so the notch in the
chip is on the left.
3. Align the notch in the chip with the notch
on socket U29.
4. Carefully press the new EPROM chip into
socket U29. There should be no open
socket holes.
If you have a Reader Expansion Card follow the
instructions on the other side titled "Reader
Expansion Cards."
Rev K Panels:
If you must upgrade this panel contact
IDenticard Tech Support @ 1-800-220-8096.
