Summary of Contents for ReptiZoo THC16
- Page 1 EZ THERMOSTAT TIMER CONTROLLER INSTRUCTION MANUAL THC16 Thanks for choosing REPTIZOO EZ thermostat timer controller. In order to use this EZ thermostat timer controller properly and ensure its service life, please read the instructions manual carefully before using it.
-
Page 2: Product Overview
It is an excellent intelligent management product in reptile pet feeding industry. Thank you for choosing the products of REPTIZOO. Please read this Manual carefully and follow the instructions before operation. PRODUCT LIST 1. - Page 3 The over-temperature alarm function can intuitively show the discomforts of pets arising from the temperature being too high or too low thus to better protect your pet. Relying on the power failure memory function, the parameters that have been set can be memorized in case of power off or sudden power failure so that the control box doesn’t need to be reset in such a circumstance.
- Page 4 3. Back of the control box. Temperature sensor Reset Memory battery slot SENSOR Default reset button Backlight switch CR2032 4. Power output box interface. Temperature control socket Temperature Timer Alawys ON Timer socket Power cord Fuse reset button A max. of 400W for each socket 5.
- Page 5 • Day and night temperature and temperature control modes are set and controlled separately. • When the temperature exceed the measurement upper limit, the LCD will display HH and make an alarm sound. • When the temperature exceed the measurement lower limit, the LCD will display LL and make an alarm sound.
- Page 6 3. Operation diagram: Alawys ON A. Heating lamp B. UV lamp 4. Operation description: • This product can turn on and off the devices on two-way power supplies by controlling two-way power outputs. As shown in the diagram above, control the heating lamp and UV lamp respectively at two ways. •...
-
Page 7: Operation Method
OPERATION METHOD Before using for the first time, make sure the power is plugged in and get familiar with the setting method according to the instructions below. (The diagram is for reference only) 1. Beginner (default setting) • Tropical mode: Long press " Tropical " for 3 seconds to directly call the preset temperature values in the Tropical mode. - Page 8 • Day and night temperature setting: Press the " " and " " in sequence. The corresponding day temperature and night temperature will flash in sequence on the LCD. When the number is flashing, you can adjust it by pressing "▲" or "▼", increasing or decreasing by 1 each time.
- Page 9 • Power-on and power-off time values for four time periods: Power-on and power-off time values for time period 1: Press the " " button in turn, and the hours, minutes, and seconds of the power-on and power-off time of pressing "▲" or "▼", increasing or decreasing by 1 each time. Long press to increase or decrease the value quickly.
-
Page 10: Safety And Maintenance
SAFETY AND MAINTENANCE Check if there is any damage, deformation or other defects of the device and sensor cables. If yes, it is suggested not to use, but report to the manufacturer or its service agent or relevant professional for detection and maintenance to avoid danger. -
Page 11: Troubleshooting
TROUBLE SHOOTING 1. The LCD does not display the time after the battery insulating strip is removed: • Check whether the battery (CR2032) is properly placed in the slot. • If it still does not work, try replacing the battery (CR2032). 2. - Page 12 Dongguan ETAN Pet Supplies Co.,Ltd. No.59,Liantang Road,Sanzhongcun,Qingxi Town, Dongguan,Guangdong,China,523651 Tel: 86- 769- 87841199 Tmall: reptizoo.tmall.com Overseas Sales: postmaster@repti-zoo.com China Sales: market_one@repti-zoo.com www.repti-zoo.com...
