Gardener's Fern Quick Manual

Create a spa experience at home or at the office with the Fern Aroma Diffuser. This diffuser releases an ultra-fine water mist that
disperses the fragrance of your favorite essential oil. Three-button control allows you to easily change the setting of your mist and
light settings. Quiet, energy-efficient and safe, it even has an auto shut-off when the water level gets too low.
Note: Be careful when handling the diffuser; the ceramic cover
is fragile and is not attached to the plastic base. When moving
the diffuser, hold the base with one hand and hold the ceramic
cover with the other.
Assembly
Begin by using Figure 1 to identify all the parts.
Step 1. Carefully remove the ceramic cover and the water tank
cover (Figure 2). Place the diffuser base on a level surface
where you intend to use it. To prevent damage to the
machine, it's best not to move it after adding water.
Step 2. Use a cup to fill the water tank with regular tap water.
Do not fill it past the maximum water line. NOTE: Do not
use distilled, purified or filtered water. They prevent the
ultrasonic ionizer from working properly.
Step 3. Add 2 to 5 drops of an essential oil to the water tank.
Step 4. Place the water tank cover and the ceramic cover back
onto the diffuser. Make sure both pieces are fully in place.
Step 5. Plug the AC adapter connector into the adapter input on
the back of the diffuser's base. Plug the AC adapter into an
electrical outlet.
Important: Do not tip the machine after filling
with water; doing so may cause water to flow
into the internal parts of the machine, causing
damage. If this occurs, unplug and empty
the water tank (Figure 4). Allow it to air dry in
a well-ventilated place for three days before
refilling.
Over please
#8593462
Fern Aroma Diffuser
Figure 1
maximum
water line
Mist
button
Figure 2
Step 1
Step 4
ceramic
cover
water tank
cover
water tank
base
ON/OFF Light
button button
Step 2
Step 5
AC adapter
connector
Back View
adapter input
Step 3
0873V Rev 06/16
