User Manual
Optical Headend
Ref. 4000 & 4001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Johanson 4000

  • Page 1 User Manual Optical Headend Ref. 4000 & 4001...

  • Page 2: Table Of Contents

    Package contents ....................3 2. I ............4 NSTALLATION OF THE HARDWARE General set-up ....................4 Combining the REF 4000 and the REF 4001 with the LOOPTHROUGH ....... 5 Cascading the Headends..................6 3. C ............7 ONFIGURATION OF THE MODULE REF 4000 internal product overview ..............

  • Page 3: Introduction

    NTRODUCTION Product description The 4000 Optical Compact Headend converts 2 wideband satellite inputs into 2 wavelengths (1310nm – 1330nm) and puts them on 1 optical feed. The output signal is strong enough to support huge installations, with up to 128 passive splits. The 4001 Optical Compact Headend converts 1 input to 1550nm optical wavelength.

  • Page 4: Installation Of The Hardware

    Optical Headend (Ref. 4000 & 4001) 2. I NSTALLATION OF THE HARDWARE General set-up REF 4000 REF 4001...

  • Page 5: Combining The Ref 4000 And The Ref 4001 With The Loopthrough

    Optical Headend (Ref. 4000 & 4001) Combining the REF 4000 and the REF 4001 with the LOOPTHROUGH...

  • Page 6: Cascading The Headends

    Optical Headend (Ref. 4000 & 4001) Cascading the Headends The optical output signal can be split passively up to 128 times, or even more when you cascade the headends.

  • Page 7: Configuration Of The Module

    Optical Headend (Ref. 4000 & 4001) 3. C ONFIGURATION OF THE MODULE • To configure the headend, remove the central bolt and lift the top lid • The settings will appear on the LED display. • Use the buttons (SET-DOWN-UP) in the top right corner of the device.

  • Page 8: Ref 4000 Internal Product Overview

    Optical Headend (Ref. 4000 & 4001) REF 4000 internal product overview REF 4001 internal product overview...

  • Page 9: Block Diagram

    Optical Headend (Ref. 4000 & 4001) 4. B LOCK DIAGRAM...

  • Page 10: Technical Specifications

    Optical Headend (Ref. 4000 & 4001) 5. T ECHNICAL PECIFICATIONS REF 4000 REF 4001 Inputs 2 RF 1 RF + 1 optical (loopthrough from ref. 4000) Outputs 1 Optical Optical wavelength 1310 - 1330 1550 Frequency range 5 - 2400...

  • Page 11: Safety Instructions

    Optical Headend (Ref. 4000 & 4001) 6. S AFETY NSTRUCTIONS Read these instructions carefully before connecting the unit To prevent fire, short circuit or shock hazard: • Do not expose the unit to rain or moisture. • Install the unit in a dry location without infiltration or condensation of water.

  • Page 12: Conditions Of Warranty

    Optical Headend (Ref. 4000 & 4001) 7. C ONDITIONS OF WARRANTY Unitron N.V. warrants the product as being free from defects in material and workmanship for a period of 24 months starting from the date of production indicated on it. See note below.
