Linergy DU239P13EGS Manual

WATERPROOF NON MAINTAINED EMERGENCY LUMINAIRES
TECHNICAL CHARACTERISTICS
DU239P13EGS
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Pb)
BATTERY PROTECTION
INDICATIONS - CONTROLS
CHARGING TIME
MINIMUM AUTONOMOUS DURATION
LIGHT SOURCE
EMERGENCY ILLUMINATION
DEGREES OF COVER PROTECTION
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
GENERAL
These luminaires are used where emergency
light is needed. Each luminaire must be
permanently connected to mains power
supply. In normal operation the power and
charge indicators are ON to indicate that the
battery is charging. In case of a mains power
supply failure the power and the charge
indicators turns off and the luminaire will light
the spot lamps automatically in emergency
mode. When the mains power supply is
restored the device turns to normal operation.
INSTALLATION
To install the luminaire follow the installation
instructions οn page 3.
OPERATION
When the device is powered from the mains,
and the battery(ies) is(are) connected, the
'power' and 'charge' indicators are ON. The
'charge' indicator indicates the battery
charging operation. If it does not light,
probably, the batteries are disconnected. If it
does not light and the batteries
connected, then contact the technician. The
power indicator confirms the proper
connection to the mains. The TEST button,
has a dual use. If pressed instantlly while the
device is connected to the mains, the device
simulates the power interruption, by lighting
Page 1 from 3
LINERGY S.R.L.
VIA ALCIDE DE GASPERI, 9
ACQUAVIVA PICENA (AP) 63075 ITALY
TEL.: +39 0735 5974
FAX: +39 0735 597474
www.linergy.it info@linergy.it -
(for LED MODULE Specifications see page 2)
DU239P30EGS
220-240V AC/50-60Hz
13W/13.6VA
12V/7Ah 2x12V/7Ah
From overcharge and deep discharge
Power indicator, battery charge indicator, TEST button
24h
90 min 180 min
White power LEDs
3200lm
IP65
o
5 to 40 C
Up to 95%
Aluminum, ABS/PC, PC
307 x 100 x 350 mm.
4250gr. 6440gr.
3 years (1 year for the battery)
the lamps for 3''. In that way, we can control
the driver circuit of the lamps and the lamps as
indicated in paragraph 3 in the text below.
DIMMING OPTION
When the luminaire is in emergency mode, with
corresponding pressings of the button, we can
choose the illumination of 100%, 50%, 33% or
turned off, either to increase the autonomy time
or not to consume the battery
unnecessarily. This option is canceled when the
network is restored.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance or
testing must be done by authorized
personnel only.
2. The device must be connected to the
mains power supply through a fuse
dependent by the total amount of the line's
power load.
3. It is suggested to check every month the
indication LED for battery charging, and by
pushing instantly the TEST button to check
are the emergency circuit and the lamps. If the
luminaire does not light contact the
installer.
4. It is suggested to check every 6 months
the minimum autonomy duration by
disconnecting the mains power supply.
Count the time that the lamps light and in
ISTDUALLED_V2-R2
GB
power
