Summary of Contents for Kamalu KS8000
- Page 1 INSTALLATION MANUAL KS8000...
- Page 2 3.2m m...
-
Page 3: Box Contents
Box Contents: [1] 2xHorizontal Rails. 1xLube. [2] 1xInstallation Instruction. [3] 2xHandle Sets. [4] 4xProfile Covers. 4x Covers. 4x Covers. 1xSpanner. [5] 8xScrews M5x16. 4xScrew Cover Caps. [6] 4xBottom Hooks. 4xScrews M4x8 4xScrew Cover Caps. [7] 6xWall Plugs. 6xFlat Screws M4x35. [9] 4xWater Deflectors. -
Page 4: Assembly Drawing
Assembly Drawing [15] [ ] 2 [ ] 3 [ ] 4 [ ] 6 [ ] 5 [ ] 7 [ ] 8 [ ] 9 [1] 6xWall Plugs [10] 4xUnder Rollers [2] 6xFlat Screws M4x35 [11] 4xScrews M4x8 [3] 2xWall Posts [12] 2xHandle Sets [4] 2xFixed Panels Wall Posts... - Page 5 Place the arc on the base of the showerhead and then customize the specific plastic components in order to properly implement the vertical profiles (as in figure 1 & 2) Level and screw the vertical profile as in Fig. Placez le profil arqué sur la base du receveur, puis ajuster les composants spéciaux en plastique pour mettre en œuvre correctement le profil vertical (comme dans la figure 1 &...
- Page 6 Place the fixed glass panel up to the horizontal guides and push them into the recess of the vertical profile. Placer les panneaux fixes à la hauteur des guides horizontaux et les pousser dans la cavité des profils verticaux. Posizionare il vetro fisso all’altezza delle guide orizzontali e spingerli nella cavità del profilo verticale. Legen Sie das Fest Glas bis zu den horizontalen Führungen ein und schieben Sie sie in die Aussparung des Vertikalprofils.
- Page 7 Step 4 Install the wheels and hang the doors. Adjust the wheels so that the doors to fit together perfectly and run smoothly. Placer les roues et accrocher les portes. Ajuster les portes afin qu’elles soient bien ajustées ensemble et le mécanisme de libération rapide fonctionne. Mettere le ruote e appendere le porte.
- Page 8 Apply silicone around. Silikon einsetzen. Appliquer autour de la silicone. Εφαρμόστε σιλικόνη περιμετρικά. Applicare silicone attorno.
