- Page 1 SmartScreen Motorized 4” and 5” Roll Tube Recessed Measuring and Installation Instructions...
- Page 2 Table of Contents Measuring for the 4” and 5” Roll Tube Pages 3 to 8 Before Installing 4” and 5” Roll Tube Pages 9 to 10 Installing U-Channel and Brackets Page 11 Installing 4” and 5” Roll Tube Pages 12 to 16 Appendices Pages 17 to 20 ...
- Page 3 4” and 5” Roll Tube Recessed SmartScreen Motorized Measuring These measuring instructions cover both the 4” and 5” Roll Tube Recessed SmartScreen Motorized Minimum width of the SmartScreen Motorized is 3’ wide (necessary to accommodate the motor within the roll tube) Maximum width is 30’ wide (25’...
- Page 4 2. Determine what material you will be fastening the unit to a. Different types of fasteners may be necessary depending what material the unit is being fastened to 3. Determine the dimensions of the unit by using the 3 point measuring system *a laser measuring tool is useful a.
- Page 5 iii. Please note the cavity height should not be so tall that the positioning of the brackets and roll tube is difficult to reach and install b. The interior of the cavity must remain clear of any gas, water, air or power conduits and any building finishes to ensure enough space for installation of the roll tube and screen material and function of the screen is not impeded *If the opening is arched, please provide drawings of the arch with dimensions to your rep prior to sale of the screen to...
- Page 6 Outside of the area of where the brackets will be located 5. Determine motor size a. All SmartScreen Motorized come with the Somfy Maestria motor with obstacle detection b. 5” roll tube will use a Somfy 550 motor c. 4” roll tube will use a Somfy 525 motor d.
- Page 7 The space where the u-channel and brackets will be placed will remain clear 9. Place order through Wizard’s online ordering system for u-channel and brackets a. The length and colour of u-channel as well as the size of brackets necessary (5” for 4” roll tube or 7” for 5”...
- Page 8 Once you have confirmed the final width of the unit, place the order for the remaining pieces (tube, slide bar, motor, etc.) through Wizard’s online ordering system d. Please ensure to make a note of any and all special requests when filling out the recessed order form Including: ...
- Page 9 4” and 5” Roll Tube SmartScreen Motorized Recessed Installing These installation instructions cover both the 4” and the 5” roll tube SmartScreen Motorized Recessed *Motorized screen installations require at least 2 people, more may be necessary for wider screens. Please plan...
- Page 10 If the packages are damaged the unit may still be free of damage b. Take care opening the packages to ensure unit is not damaged while opening c. Inspect unit and pieces and if there is any damage report to Wizard immediately with pictures 4. Remove the units from packaging a.
- Page 11 Installing U-Channel and Brackets (prior to placing the order for the remaining pieces) 1. Install the brackets a. The brackets can be attached through the top in to the header and/or through the sides in to the unfinished jamb b. Ensure the brackets are square and level and located at equal points within the cavity on either end c.
- Page 12 Installing the Roll Tube, Screen, Slide Bar, Track and Track Clips 1. Install the roll tube a. Insert the pivot in to the corresponding bracket and compress b. Move the motor end of the tube to line up with the crown on the corresponding bracket i.
- Page 13 *Important – when cutting the power cord leave a minimum of 18” of cord between the motor and the end of the power cord. The antenna for the motor is within those 18” and if cut it will limit the usage of the remote b.
- Page 14 b. Pick up the slide bar and with the bottom seal facing down slide the slide bar on to the zipper by moving the screen bottom tag to the side and sliding the zipper through the rounded hole on the slide bar c.
- Page 15 8. Install the tracks on to the screen a. Take one side of tracks and feed the zipper in to the groove of the track through the beveled end of the track i. Use needle nose pliers to hold on the tab beside the slide bar to help guide the zipper in to the groove b.
- Page 16 engaging by using the 9 in 1 painters tool to carefully pry the clip in towards the center of the opening on both tracks Only pry 1 click on either side at a time until screen reaches desire effect where is runs smoothly 10.
- Page 17 126" Additional mesh options may be available Additional costs and limitations may apply Please speak to your Wizard representative to discuss options Hard Power Reset 1. Cut power to motor for 10 seconds 2. Turn on power to motor for 10 seconds 3.
- Page 18 Adjusting Screen Limits 1. To adjust the upper limit a. Press the up button on the remote to send the screen up to the upper limit b. Press and hold the up and down buttons on the remote until the screen jogs up and down c.
- Page 19 16. Carefully slide the screen all the way across the roll tube taking care not to damage the screen 17. When you reach the other side of the roll tube ensure there are equal number of zipper teeth on both ends of the roll tube so that the screen will be centered 18.
