Ralph Christian VX9J User Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

WATCH USER INSTRUCTIONS
&
WARRANTY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX9J and is the answer not in the manual?

Questions and answers

Summary of Contents for Ralph Christian VX9J

  • Page 1 WATCH USER INSTRUCTIONS & WARRANTY...

  • Page 2: Setting The Time

    WATCH MOVEMENT: THREE HANDS WATCH MOVEMENT: THREE HANDS WITH DATE MINUTE HAND HOUR HAND MINUTE HAND HOUR HAND CROWN - FIRST POSITION DATE WHEEL SECOND HAND SECOND HAND THREE HANDS SETTING THE TIME FEATURES Pull out crown to fi rst position. Rotate the crown to adjust. Once set, push the Hour, minute and second hands, date crown back to the starting position.
  • Page 3 WATCH MOVEMENT: VX9J ADVANCED SETTING TECHNIQUE 1. The 24-hour hand moves correspondingly with the hour hand. 2. When setting the hour hand, check that the 24-hour hand is correctly set. 3. When setting the minute hand, advance it 4 to 5 minutes ahead of the desired BUTTON A time and then turn it back to the exact time.

  • Page 4: Time Setting

    WATCH MOVEMENT: VD37 ADJUSTING THE DUAL TIME OF 24 HOUR REGULATOR, DUAL TIME OF 12 HOUR REGULATOR AND DUAL TIME OF 60 MINUTE REGULATOR HANDS POSITION Before setting the time, check that the dual time of 24 hour regulator, dual time of 12 DUAL TIME 24-HOUR HAND hour regulator and dual time of 60 minute regulator hands are in the "0"(12o'clock) BUTTON A...

  • Page 5: Setting The Day

    WATCH MOVEMENT: ISA 9238 1970 SETTING THE DAY 1. Pull the crown out to the first click position. 2. Turn the crown clockwise and advance the hands through 24 hours. The day will advance once 04:30AM is reached 3. After the date has been set, push the crown back to the normal position. BUTTON A SETTING THE SECOND TIME ZONE DAY HAND...

  • Page 6: Using The Stopwatch

    WATCH MOVEMENT: JS15 USING THE STOPWATCH This stopwatch is able to measure and display time up to maximum of 30 minutes. The stopwatch will stop automatically after running continuously for 30 minutes. BUTTON A 24 HOUR DIAL 1. Press button “A” to start the stopwatch. 2.
  • Page 7 WATCH MOVEMENT: JS25 USING THE STOPWATCH This stopwatch is able to measure and display time up to maximum of 30 minutes. BUTTON A The stopwatch will stop automatically after running continuously for 30 minutes. 1. Press button "A" to start the stopwatch. 2.
  • Page 8 WATCH MOVEMENT: YM92 SETTING THE TIME: Pull the crown out to the 2nd ‘click’ position when the second hand is at the 12 o’clock position. SPLIT SECOND STOPWATCH HAND BUTTON A Note: When the stopwatch is or has been measuring or is stopped, if the crown is pulled out to the 2nd ‘click’...

  • Page 9: Battery Life Indicator

    USING THE STOPWATCH This stopwatch is able to measure and display time up to maximum of 30 minutes. The stopwatch will stop automatically after running continuously for 30 minutes. 1. Press button “A” to start the stopwatch. 2. The stop watch can be started and stopped each time button “A” is pressed. 3.

  • Page 10: Measuring Speed

    HOW TO USE A TACHYMETER MEASURING SPEED To use a tachymeter-equipped watch for measuring speed, start the chronograph at a starting marker of a known distance. At the next marker, the point on the scale adjacent to the second hand indicates the speed (in distance between markers per hour) of travel between the two.

  • Page 11: Measuring Distance

    DEPLOYMENT BUCKLE MEASURING DISTANCE A tachymeter-equipped watch can be used to measure distance by timing the travel over the distance while the speed is held constant. The tachymeter scale is rotated to align with the second hand at the start of the length to be measured. When the second hand reaches the point on the scale where the speed indicated equals the speed of the vehicle, one unit of distance (miles if speed is miles per hour, kilometres if kilometres per hour, etc.) has been covered.
  • Page 12 HIDDEN CLASP FOLD OVER CLASP WITH DOUBLE PUSH BUTTONS A fold over clasp simply folds out to put the watch on and then folds back in to close the watch onto your wrist. It locks with a latch underneath the clasp and is released by a small button(s) that you push in and In the hidden butterfly clasp the straps fold over and meet in the middle to close, the fold over opens up.
  • Page 13 FOLD OVER CLASP WITH DOUBLE PUSH BUTTON AND SAFETY ADJUSTING YOUR WATCH BAND Back Side Lift up Slide the clasp to the Push back down to desired slot to adjust the secure the clasp length of the band MESH STRAP SLIDING CLASP On the reverse of the strap you should see a succession of ridges.
  • Page 14 THE RALPH CHRISTIAN 24 MONTH WATCH WARRANTY WATER TIGHTNESS AND SHOCK RESISTANCE This watch is protected against shocks when in normal use. However it should not be subjected to extremely heavy shocks as will occur when it falls on to a hard ground, for ADJUSTING YOUR WATCH BAND instance.
  • Page 15 We recommend that any adjustments are made by a reputable jeweler. Any repairs must be completed by our workshops or your warranty is invalidated MPORTANT. NOT COVERED BY WARRANTY: Case, glass and band. Damage cause through accident, misuse, neglect or inexpert repairs. Any discoloration or wear.
