Installation Instructions for the P3Pro Projector Impact Screen
Before installation begins, locate the area in which the Projector Impact Screen is to be installed. Keep
in mind that the Projector Impact Screen measures 9 feet tall by 10 feet wide and requires a minimum
room width of 13 feet. Also keep in mind that you must have adequate space after installation to swing
your clubs as well as suspend your projector from the ceiling. Depending on which projector you have
purchased, you will usually need between 12 to 20 feet from the installed Projector Impact Screen to
obtain the full maximum viewing size. The Projector Impact Screen is designed for ceiling heights
over 7 feet 6 inches. For any ceiling less than 7 feet 6 inches this screen should not be used. For any
ceiling over 9 feet tall the Projector Impact Screen needs to be suspended in some manner ensuring
that the top of the net is hung no more than 9 feet from the ground.
Contents:
1 Projector Impact Screen
4 Packages containing 2 each of ceiling hooks and hardware
1 Package of 4 short bungee cords
Tools Required for Installation:
Drill
Required drill bit sizes (see enclosed ceiling hook packages)
Tape measure
Pencil
Installation Notes:
• Remember to maintain the same distance from the back wall for all ceiling hook placements.
• You will need to make a total of at least 4 marks on the ceiling a minimum of 18 inches away
from the back wall to hang the projection part of the screen.
• The elastic bands sewn into the top of the Projector Impact Screen are spaced every 16 inches
to allow for attachment into wood supports in the ceiling if available. The enclosed hardware
allows for either attachment into wood or drywall. We have included extra elastic bands sewn
into the Projector Impact Screen in the event that 1 breaks or more support is required.
• If more ceiling hooks are required they can be purchased at your nearest Home Depot.
• Pulling the Projection Impact Screen from the sides can remove wrinkles in the screen to
provide a better image quality.
1
Advertisement
Table of Contents
Summary of Contents for Sports Vision Technologies P3Pro Swing
- Page 1 Installation Instructions for the P3Pro Projector Impact Screen Before installation begins, locate the area in which the Projector Impact Screen is to be installed. Keep in mind that the Projector Impact Screen measures 9 feet tall by 10 feet wide and requires a minimum room width of 13 feet.
- Page 2 Projector Impact Screen Layout Installation Instructions • Locate the area where the Projector Impact Screen will be installed. It needs to be hung a minimum of 18 inches from the back wall and a minimum of 18 inches from any side wall. (Recommended distance of 2 feet from any wall) •...
- Page 3 • Note: If more support is required, install additional hooks as described in the previous instructions. Suspending the Netting • To suspend the netting material you will need to install at least 3 more white ceiling hooks. The best way to locate the position of these ceiling hooks is to attach 3 of the enclosed bungee cord, 1 to each of the corners and 1 in the middle of the netting and pull each of the bungees out 1 at a time tight along the ceiling.
- Page 4 The installation of the Projector Impact Screen is now complete and ready to use. Safety Requirements: When using the Projector Impact Screen follow these simple safety rules to reduce the chance of personal injury or property damage. Failure to follow these warnings may result in serious injury or damage.
- Page 5 • Ensure that the side netting and back screen hang loosely on the ground as shown to reduce the chance of a ball getting under the Projection Impact Screen.
